SYSTEM SPECIFICATION
System capacity
Keypads
Programming
User Codes
Communications
Audible warning devices
Other facilities
SCANTRONIC 9100 (3000)
16 zones plus Entry/Exit, PAB, 24 Hour,
-
Auxiliary zone
2 remote keypads maximum
-
16 programmable zones
-
1 access code
-
1 engineer code
Plug on 9058 digital communicator
-
Plug on STU (Redcare)
-
Onboard sounder as standard
External bell/strobe
Internal sounder
Soak test
-
Double knock
Chime
Exterminator circuit
Part set
60 event alarm log
Written By Paul Wright
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Scantronic 9100
Summary of Contents for Scantronic 9100
- Page 1 SCANTRONIC 9100 (3000) SYSTEM SPECIFICATION System capacity 16 zones plus Entry/Exit, PAB, 24 Hour, Auxiliary zone Keypads 2 remote keypads maximum Programming 16 programmable zones User Codes 1 access code 1 engineer code Communications Plug on 9058 digital communicator Plug on STU (Redcare)
-
Page 2: Part Setting The System
USER OPERATING GUIDE SETTING THE SYSTEM Ensure the red DAY LED is on. Enter the code number. The DAY LED will extinguish. The exit tone will start. Leave the premises by the correct exit route closing the exit door after leaving Ensure that the exit tone stops after the preset exit time expires. -
Page 3: Tamper Reset
WALK TEST Press the number 5 (Walk Test) square then ENTER followed by the user code. The panel will give a continuous tone. When a zone is violated the relevant zone number to return to the UNSET state. CHANGING THE USER CODE The user's code can only be changed by an engineer. -
Page 4: Resetting The System
RESETTING THE SYSTEM Following am alarm activation the CALL ENGINEER LED and the alarm LED will be illuminated. The activated zone will be flashing in the display. The system can be reset either by an engineer visiting the premises or by the use of a remote reset keypad if fitted. The monitoring station or ARC should not perform a remote reset if the system requires any corrective maintenance, if the police have been notified or if the customer does not know the exact cause of the activation. - Page 5 DISPLAYED CODES AND THEIR MEANINGS AND ALARM LIGHT LIT ACTIVATION WAS ON THIS ZONE Zone No'' AND TAMPER LIGHT LIT TAMPER WAS ACTIVATED ON THIS Zone No'' ZONE ENGINEER REQUIRED AND TAMPER LIGHT LIT PANEL/BELL OR TAMPER LOOP ACTIVATED ENGINEER REQUIRED AND TAMPER LIGHT LIT CUSTOMER HAS ENTERED INCORRECT CODE THREE TIMES...
