- Page 1 T 571 DVD / CD / MP3 Player Owner’s Manual...
-
Page 2: Introduction
- Consult the dealer or an experienced radio/TV technician for help. FCC WARNING: Changes or modifications not expressly approved by NAD Electronics Corporation could void the user’s authority to operate the equipment. INDUSTRY CANADA REQUIREMENT: This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. -
Page 3: Table Of Contents
Table of Contents Introduction Safety Precautions......2 Table of Contents......3 IMPORTANT SAFETY INSTRUCTIONS . -
Page 4: Important Safety Instructions
PAGE 4 INTRODUCTION IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS (Cont’d) 13. Accessories, Carts, and Stands Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. -
Page 6: Precautions
When the DVD player is not in use, be sure to remove the disc and turn off the power. If you do not use the DVD player for a long period, the unit may not function properly in the future. Turn on and use the DVD player occasionally. -
Page 7: Notes On Discs
About This Owner’s Manual This owner’s manual explains the basic instructions of this DVD player. Some DVD video discs have functions that may not be explained in this owner’s manual. Therefore, some instructions may differ from this owner’s manual, and there may be extra... -
Page 8: Identification Of Controls
PAGE 8 INTRODUCTION Identification of Controls Front Panel POWER indicator POWER button Display Window MP3 indicator Operating status indicator Disc 1-5 indicator Angle icon indicator RANDOM button REPEAT button Remote sensor Display window OPEN/CLOSE button Disc tray HDCD indicator CD indicator DVD indicator HD CD TITLE... -
Page 9: Rear Panel
12V TRIGGER INPUT jack By connecting this DVD player to another NAD audio component or system controller equipped with a 12V trigger output, you can remotely operate the T 571 power ON/OFF. POWER CORD Connect to an AC 120V, 60Hz outlet only. -
Page 10: Remote Control
PAGE 10 INTRODUCTION Identification of Controls (Cont’d) Remote Control You will find instructions for each of the remote control functions in the appropriate sections of this instruc- tion manual. POWER button REPEAT button SETUP button SUBTITLE button AUDIO button ***TITLE button SELECT/ENTER button DISPLAY button ZOOM button... -
Page 11: Preparing The Remote Control
Do not expose the remote sensor of the DVD player to a strong light source such as direct sunlight or illumination. If you do so, you may not be able to operate the DVD player with the remote control. Notes on the remote control Point the remote control at the remote sensor on the DVD player. -
Page 12: Connections
Refer to the owner’s manual of your audio system for operating instructions. Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections. -
Page 13: Enjoying Dolby Pro Logic Surround Sound
Warning Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output”... -
Page 14: Enjoying 2 Channel Digital Stereo Sound
Refer to the owner’s manual of your audio system for operating instructions. Before you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before making any connections. -
Page 15: Connecting To An Stereo System
Warning Do not set the Digital Audio Output of this DVD player to “Dolby Digital” unless you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers (Refer to “Selecting Digital Audio Output”... -
Page 16: Connecting To A Tv Equipped With Component Video Inputs
Refer to the owner’s manual of your TV for TV operating instructions. Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections. -
Page 17: Connecting To A Tv
Refer to the owner’s manual of your TV for TV operating instructions. Before you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall outlet before making any connections. -
Page 18: Initial Settings
PAGE 18 INITIAL SETTINGS Selection of initial settings Once the initial settings have been completed, the player can always be operated under the same conditions (especially with DVD discs). The settings will be retained in the memory until they are changed, even if the power is switched off. -
Page 19: Selecting Disc Languages
Selecting disc languages This is to select the audio soundtrack language, subtitle language and the language used in title menus or DVD menus which will always be used for every disc to be played back. When you play back a DVD video disc, the DVD player automatically displays the pre-selected subtitle language if it is included on the disc. -
Page 20: Password
DVDs with ratings higher than your selection will be blocked, unless the correct password is entered again. For example: if you change the level to “5”, the DVD player will not play discs with ratings of “6”, “7” or “8” unless the correct password is entered on the remote control. -
Page 21: Password
Selecting Parental Control Rating Levels and Password (Cont’d) POWER SETUP REPEAT AUDIO SUBTITLE TITLE 1, 2, SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP NEXT DISC PAUSE/STEP 2, 3 CLEAR To clear your 4-number password If you forget your password, to clear the current password, follow the procedure below. -
Page 22: Selecting Tv Aspect
PAGE 22 INITIAL SETTINGS Selecting TV Aspect Select the appropriate screen type according to your TV set; conventional size screen (4:3) or wide-screen (16:9). POWER SETUP REPEAT AUDIO SUBTITLE ANGLE TITLE 1, 2 SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP... -
Page 23: Selecting Menu Language
Selecting Menu Language Selects language for SETUP menus and displays on the TV. POWER SETUP REPEAT AUDIO SUBTITLE ANGLE TITLE 1, 2 SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP NEXT DISC PAUSE/STEP CLEAR At the SETUP screen, press “Menu Language”... -
Page 24: Selecting Progressive Scan
Off: If you are using the COMPONENT VIDEO OUT jacks, SKIP but are connecting the DVD player to a standard (analog) television, set the Progressive mode to “Off”. If you are using the COMPONENT VIDEO OUT jacks for connection to a TV that is compatible with a pro-... -
Page 25: Selecting Digital Audio Output
Selecting Digital Audio Output Each DVD disc has a variety of audio output options. Set the player’s Digital Audio Output according to the type of audio system you use. POWER SETUP REPEAT AUDIO SUBTITLE ANGLE TITLE 1, 2 SELECT ENTER DISPLAY ZOOM MARKER —... -
Page 26: Others
PAGE 26 INITIAL SETTINGS Others The DRC settings can be changed. POWER SETUP REPEAT AUDIO SUBTITLE ANGLE TITLE 1, 2 SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP NEXT DISC PAUSE/STEP CLEAR About DRC (Dynamic Range Compression) With the DVD format you have the opportunity to hear a program’s soundtrack in the most accurate and realistic presentation possible, thanks to the use of digital audio technology. -
Page 27: Table Of Languages And Their Abbreviations
Table of Languages and Their Abbreviations Enter the appropriate code number for the initial settings “Audio”, “Subtitle” and/or “Menu” (See page 19). Code Language Code 6565 Afar 7079 6566 Abkhazian 7082 6570 Afrikaans 7089 6577 Ameharic 7165 6582 Arabic 7168 6583 Assamese 7176... -
Page 28: Basic Operations
If you insert an audio CD, the CD indicator lights up on the display. The title number does not appear. After playing back all of the chapters in the title, the DVD player automatically stops and returns to the menu screen. - Page 29 Use the OPEN/CLOSE button on the remote control or DVD player to open and close the disc tray. Do not push the disc tray while it is moving. Doing so may cause the DVD player to malfunction. Do not push up the disc tray or put any objects other than discs on the disc tray.
-
Page 30: Stopping Play
The screen saver picture appears when you leave the DVD player in stop mode for about 5 minutes. Automatic power off function After the Screen Saver has been engaged for about 5 minutes, the DVD player will automatically turn itself off. Stopping Play Resume Play Last Scene Memory... -
Page 31: Skipping Discs
Basic Playback (Cont’d) POWER SETUP REPEAT AUDIO SUBTITLE ANGLE TITLE SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP NEXT DISC PAUSE/STEP SLOW NEXT DISC CLEAR PROGRAM Press NEXT DISC during playback or in the stop mode. Each time the button is pressed, the next disc tray is selected. -
Page 32: Special Playback
HDCD Indicator lights. No user intervention is required. To enjoy the benefits of HDCD, your DVD Player must be connected to your A/V receiver via the Analog Audio Outputs. However, if your A/V receiver or surround processor is... -
Page 33: To Scan At Fast Forward Or Fast Reverse Playback
To return to normal playback, press PLAY. PLAY Note The DVD player does not play back sound during the high SLOW speed reverse and forward playback of DVD video discs. However, the DVD player plays back sound during fast forward or fast reverse playback of audio CDs. -
Page 34: Operation Using Gui (Graphical User Interface) Menu Icons
PAGE 34 OPERATION USING GRAPHICAL USER INTERFACE (GUI) MENU ICONS General Information about GUI menu icons This unit features GUI Menu Icons showing disc information (title/chapter/track number, elapsed playing time, audio/subtitle language, angle, and sound) and player information (repeat play, play mode, marker, etc.). -
Page 35: Detailed Description Of Each Gui Menu Icon
OPERATION USING GRAPHICAL USER INTERFACE (GUI) MENU ICONS Detailed description of each GUI menu icon You can view information about a disc and its operational status on the TV screen. Press DISPLAY during playback. [TV screen] DVD GUI 0:16:57 1 ENG 6 CH NORM. -
Page 36: Advanced Operation
PAGE 36 ADVANCED OPERATION Using a title menu Some movie discs may contain two or more titles. If the disc has a title menu recorded on it, the TITLE button can be used to select the movie title. (The details of operation differ depending on the disc used.) Selecting a title may not be possible on certain DVD discs. -
Page 37: Changing Subtitle Language
Changing subtitle language It is possible to change the subtitle language to a different language from the one selected at the initial settings. (See page 19 for further info.) This operation works only with discs on which multiple subtitle languages are recorded. SETUP REPEAT 1, 2... -
Page 38: Viewing From Another Angle
PAGE 38 ADVANCED OPERATION Viewing from another angle Some DVDs may contain scenes which have been shot simultaneously from a number of different angles. For these discs, the same scene can be viewed from each of these different angles using the ANGLE button. (The recorded angles differ depending on the disc used.) POWER... -
Page 39: Repeat Play
Repeat Play Repeating viewing (listening) Press REPEAT during playback. Each time this button is pressed, the TV screen changes as shown below and the disc will repeat a chapter or title (DVD) or a track (CD). • DVD Repeat of chapter being CHAPT played... -
Page 40: Storing Markers In Memory To Be Viewed (Listened To) Again
PAGE 40 ADVANCED OPERATION Storing markers in memory to be viewed (listened to) again Storing a MARKER in the DVD memory is similar to marking your page in a book. It allows you to quickly return to any point on the disc. POWER OPEN/CLOSE SETUP... -
Page 41: Zoom Feature
Notes Random playback may not be possible on certain discs. If you press the SKIP button during random playback, the DVD player goes to another track randomly and starts playback. Random playback may not be possible on MP3 encoded discs. -
Page 42: Program Play
PAGE 42 ADVANCED OPERATION Program play The player plays the tracks on the disc in the order you specify. Note: Program play function is possible only with audio CDs. It does not work with DVD movie discs. POWER SETUP REPEAT AUDIO SUBTITLE ANGLE... -
Page 43: Playback With Mp3
Playback with MP3 SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP To play an MP3 file repeatedly If you press REPEAT once during play, the current MP3 file will play repeatedly. If you press REPEAT twice during play, all MP3 files on the disc will play repeatedly. -
Page 44: Playback With Mp3
PAGE 44 ADVANCED OPERATION Playback with MP3 (Cont’d) SELECT ENTER DISPLAY ZOOM MARKER — SEARCH SCAN PLAY STOP NEXT DISC PAUSE/STEP SLOW CLEAR PROGRAM To play an MP3 file repeatedly If you press REPEAT button once during play, the current MP3 file will play repeatedly. If you press REPEAT button twice during play, all MP3 files on the program list will play repeatedly. -
Page 45: Reference
Management Information that is recorded on a DVD disc. If the Region number described on the DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play that disc. The Region number of this DVD player is 1. -
Page 46: Before Calling Service Personnel
• A menu is on the TV screen. • The Rating level is set. The remote control • The remote control is not pointed at the remote sensor of the DVD player. does not work properly. • The remote control is too far from the DVD player. -
Page 47: Specifications
Specifications DVD player/Outputs/Supplied Accessories Power supply Power consumption Weight External dimensions (W X H X D) Signal system Laser Frequency range (audio) Signal-to-noise ratio (audio) Dynamic range (audio) Harmonic distortion (audio) Operating conditions Video output S-video output Component video output... - Page 48 P/NO: 3834RS0023W Printed in Korea...
