- Page 1 C 715 DAB ® CD Receiver Owner’s Manual...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read instructions - All the safety and operating instructions should be read before the product is operated. 2. Retain instructions - The safety and operating instructions should be retained for future reference. 3. Heed Warnings - All warnings on the product and in the operating instructions should be adhered to. - Page 3 23. Battery Disposal - When disposing of used batteries, please comply with governmental regulations or environmental public instruction’s rules that apply in your country or area. 24. Safety Check - Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition.
- Page 4 Serial number : ........NAD is a trademark of NAD Electronics International, a division of lenbrook Industries limited...
-
Page 5: Table Of Contents
C 715. one more thing: We urge you to register your C 715 ownership on the NAD Worldwide Web site: http://NADelectronics.com/warranty... -
Page 6: Introduction
QUICK START In case you simply cannot wait to experience the performance of your new NAD C 715 CD Receiver, we provide the following “Quick Start” instructions to get you underway. Please make all the connections to your C 715 with the unit unplugged. -
Page 7: Identification Of Controls
1 POWER: Press this button to switch oN the C 715. The Standby lED indicator will turn from amber to blue and illuminate the Vacuum Fluorescent Display (VFD). Pressing the power button again turns the unit back to standby mode. If the disc tray is open and the C 715 is powered oFF, the disc tray will draw close and the unit powered oFF. - Page 8 IDENTIFICATION OF CONTROLS FRONT PANEL 9 TIME MODE: In conjunction with [TUNE/TIME] keys, toggle this button to cycle through the following timer modes: Current time on time Source select off time Refer to the sections “SETTING ThE CloCk” and “SETTING ThE oN/oFF TIMER”...
-
Page 9: Rear Panel
6 AUX IN: Input for additional line level input such as another CD player. Use a twin RCA-to-RCA lead to connect the auxiliary unit’s left and right “Audio output” to this input. -
Page 10: Sr 7 Remote Control
IDENTIFICATION OF CONTROLS SR 7 REMOTE CONTROL Press in and lift tab to remove battery cover out of recess. 1 ON : Power oN C 715. 2 LED indicator : Flashes when a command is sent. 3 CD, USB, TUNER, TAPE, VIDEO, AUX, MP : Select a Source. 4 TIMER : Access timer modes. SLEEP : Set sleep mode timer. -
Page 11: Operation
CD-R AND CD-RW AUDIO DISCS Aside from normal CD audio discs, the C 715 can play back CD-R or CD- RW audio discs that have been recorded on a computer or CD recorder. The quality of CD-R, CD-RW audio discs varies widely which may affect playability. - Page 12 OPERATION USING THE C 715 – CD MODE REVIEW PROGRAM LIST 1 Initiate review of your programmed entries by pressing [PRoGRAM] at SToP mode. 2 The VFD will show the first Program Number. 3 Press [PRoGRAM] repeatedly to step through the program sequence. you will have reached the end of the program sequence when “P-End” is displayed at the VFD.
-
Page 13: Using The C 715 - Usb Mode
The C 715 can play back MP3/WMA files stored in external USb (Universal Serial bus) devices. The following are the C 715’s capabilities with respect to USb device playability. 1 Playback of MP3/WMA files recorded in various USb devices such as USb flash memory, MP3 or hDD. -
Page 14: Recording To Usb
OPERATION USING THE C 715 – USB MODE RECORDING TO USB With an external USb device, the following procedures will allow you to record as MP3/WMA file a source of CD, MP3/WMA disc, cassette deck, radio broadcast or other auxiliary devices. 1 Connect the external USb device to the front panel’s USb input. 2 Press [SoURCE] to select the source you want to record. -
Page 15: Using The C 715 - Tuner Mode
LISTENING TO AM/FM The C 715’s internal AM/FM tuner offers very high quality sound from radio broadcasts. The reception and sound quality will always be dependent to a degree however on the type of antenna(s) used as well as proximity to the broadcast origin, geography and weather conditions. -
Page 16: Choosing The Fm Modes
OPERATION USING THE C 715 – TUNER MODE AUTOMATIC PRESET (AM/FM ONLY) Preset stations may also be programmed automatically for the entire FM (or AM) band. 1 Toggle the [bAND] button to select AM or FM band. 2 Press and hold SR 7’s [MEMoRy] key. Release [MEMoRy] key when “Auto Memory”... -
Page 17: Program Type (Pty)
PROGRAM TYPE (PTY) A major benefit of RDS is its ability to encode broadcasts with Program Type (PTy) codes that indicate the type of material being broadcast. 1 Toggle the [bAND] button to select FM band. 2 Press and hold [RDS MoDE] until ‘RDS PRoGRAM TyPE” is shown in the VFD. -
Page 18: Listening To Dab
OPERATION USING THE C 715 – TUNER MODE LISTENING TO DAB Until now, analogue radio signals such as FM or AM have been subject to numerous kinds of interference on their way from the transmitter to your radio. These problems were caused by mountains, high-rise buildings and weather conditions. -
Page 19: Function Control
SECONDARY SERVICE Secondary service is a part-time program transmitted as a side channel of the primary station. Check broadcasting schedule if you want to listen to secondary stations. When you listen to primary stations that include secondary services (stations), “SECoNDARy” blinks in the VFD. When you listen to the secondary station, the “SECoNDARy”... -
Page 20: Manual Tune
OPERATION USING THE C 715 – TUNER MODE 2 Toggle [TUNE/TIME] until “DRC value” is displayed in the lower line of the VFD. Press [TUNE MoDE/SElECT]. 3 Toggle [TUNE/TIME] until the desired DRC level is displayed. 4 Press [TUNE MoDE/SElECT]. MANUAL TUNE This option allows you to manually tune in a channel and view a continuously updated display of the strength of the signal. -
Page 21: Using The C 715 - External Sources And Timer
LISTENING TO EXTERNAL SOURCES When appropriately connected to the applicable C 715 input, one can listen to external sources such as a VCR, Media Player (MP), Tape Recorder and other auxiliary components. Toggle the [SoURCE] button to select [TAPE], [VIDEo], [AUX] or [MP] mode. Refer to the above sections about “Identification of Controls –... -
Page 22: Activate Timer Operation
OPERATION USING THE C 715 – EXTERNAL SOURCES AND TIMER ACTIVATE TIMER OPERATION When pressed, the TIMER button in the SR 7 remote control will activate several timer modes. Toggle [TIMER] to step through the following modes: Timer off Timer daily Timer REC daily Timer REC once TIMER DAILY 1 After setting up “on time”... -
Page 23: Using The C 715 - Other Features
TONE/BALANCE/DIMMER Toggle this button to adjust tone, balance and dimmer settings in combination with [VolUME] knob. Toggle [ToNE/bAl/DIMMER] to step through the following modes: bASS TREblE bAlANCE DIMMER Select the feature you want to adjust and within 3 seconds, turn [VolUME] clockwise or counterclockwise to change the level settings. -
Page 24: Random Play
OPERATION USING THE C 715 – OTHER FEATURES RANDOM PLAY Press [RANDoM] key during playback or stop mode. “Random Play” is shown in the VFD. Playback of the first randomly selected track or file automatically begins. Press [RANDoM] again to return to normal playback. TIME During playback mode, toggle [TIME] button to alternatively display the elapsed time or remaining time of the current track/file. -
Page 25: Reference
CONDITION No power. No sound. No sound one channel. Weak bass/diffused stereo image. The C 715 does not start playback. Disc playback sound inadvertently skips. Noisy reception, hiss. Reception with whistling, buzzing noise. C 715 does not respond to SR 7 remote control. -
Page 26: Specifications
REFERENCE SPECIFICATIONS AMPLIFIER SECTION Power output Stereo Mode IhF dynamic power (6 ohms) Total harmonic distortion at rated power Input sensitivity and impedance (Tape IN) TUNER SECTION AM SECTION Total harmonic Distortion FM SECTION Total harmonic Distortion, MoNo Total harmonic Distortion, STEREo DAB SECTION Adjacent Channel Rejection CD SECTION... - Page 27 REFERENCE NOTES...
- Page 28 ©2007 NAD ELECTRONICS INTERNATIONAL A DIVISION OF LENBROOK INDUSTRIES LIMITED All rights reserved. No part of this publication may be reproduced, stored or transmitted in any form without the written permission of NAD Electronics International C 715 DAb Manual 09/07...
