kW Phono
PHONO PREAMPLIFIER
INSTRUCTIONS FOR USE
Thank you for purchasing the Musical Fidelity kW Phono preamplifier.
Used properly and carefully, it should give many years of outstanding musical
reproduction.
Aesthetically, the kW Phono is a perfect match for the
kW 750 Power Amplifier, kW Hybrid Line Level Preamplifier
and kW SACD Player.
Together they form one of the finest hi-fi systems available.
Dust regularly with a soft duster or soft brush, but be careful when using cleaning
or polishing agents - they may harm the surface finish.
If you have any questions about your audio system,
please consult your dealer who is there to help and advise.
kW Phono Pre-Amplifier
Instructions for use
Page 1 of 7
Issue 1 : January 2005
Advertisement
Table of Contents
Related Manuals for Musical Fidelity kW 750
Summary of Contents for Musical Fidelity kW 750
- Page 1 Phono PHONO PREAMPLIFIER INSTRUCTIONS FOR USE Thank you for purchasing the Musical Fidelity kW Phono preamplifier. Used properly and carefully, it should give many years of outstanding musical reproduction. Aesthetically, the kW Phono is a perfect match for the kW 750 Power Amplifier, kW Hybrid Line Level Preamplifier and kW SACD Player.
-
Page 2: Safety Information
If connecting to a BS1363 plug, a 13 amp fuse must be used. WARNING: Any modifications to this product not expressly approved by Musical Fidelity who is the party responsible for standards compliance could void the user’s authority to operate this equipment. -
Page 3: General Advice
Do not remove any covers or try to gain access to the inside. There are no internal adjustments or fuses you can replace yourself. Refer all service work to an authorised Musical Fidelity agent. Note: Unauthorised opening of the equipment will invalidate any warranty claim. - Page 4 1 Illuminated feet with multi-colour indicator LEDs (see page 6) 2 POWER mains on/off push switch 3 Power on indicator LED 4 Moving Magnet / Moving Coil input selection button (see page 6) 10 Moving Coil input socket - right channel 11 Moving Magnet input socket - left channel 12 Moving Coil input socket - left channel 13 Mains inlet socket - IEC type (10 Amp)
-
Page 5: Input Connections
All input, output and power connections should be made with the mains power switched OFF. INPUT CONNECTIONS The rear panel of your kW Phono pre- amplifier has two pairs of phono input sockets, one pair for left and right moving magnet (MM) and the other pair for moving coil (MC) pickup cartridges. -
Page 6: Operation
BEFORE SWITCHING ON ..Plug the accessory IEC mains lead into the rear panel socket, then the other end into a convenient wall outlet. STARTING Press the POWER switch button on the preamplifier front panel - the blue LED just above the button will light indicating that power is applied to the unit. -
Page 7: Specifications
18.15Kg, 40 lbs unit only, unboxed 23Kg, 51 lbs in shipping carton IEC mains lead - 10 Amp type Musical Fidelity reserves the right to make improvements which may result in specification or feature changes without notice kW Phono Pre-Amplifier Instructions for use...
