Introduction

Thank you for buying a MITSUBISHI OUTLANDER.

We are confident you will enjoy your vehicle. It has been engi-

neered for optimum performance, durability and comfort. By

thoroughly reading this Owner's Manual, you will gain an

understanding of the many features that are included in the

OUTLANDER. The Owner's Manual contains descriptions

and illustrations that will assist in the operation and mainte-

nance of your vehicle.

Your Authorized Mitsubishi Motors Dealer will be happy to

assist you with any further questions you may have regarding

the operation of your vehicle.

Please note that this manual applies to all OUTLANDER mod-

els and explains all features including options. Some features

explained in this manual may not be installed on your vehicle.

Please leave this Owner's Manual in the vehicle at the time of

resale. The next owner will appreciate having access to the

information contained here.

This manual includes instructions for standard and optional

equipment available at the time of printing. Mitsubishi Motors

Corporation reserves the right to make changes in design and

Specifications and to make additions or improvements in its

product without assuming any obligation to install these on

previously manufactured products.

Throughout this manual the words WARNING and

CAUTION appear.

N09200100556

These are reminders to be especially careful. Failure to follow the

instructions could result in personal injury or damage to your

vehicle.

WARNING

!

Indicates a strong possibility of severe personal injury or

death if instructions are not followed.

CAUTION

!

Points out hazards or unsafe practices that could cause minor

personal injury or damage to your vehicle.

You will see another important symbol:

NOTE Gives helpful information.

As with other vehicles of this type, failure to operate this vehicle

correctly may result in loss of control or an accident. Be sure to

read "on-pavement" and "off-road" driving guidelines in the

"Driving safety" and "Features and controls" sections.

WARNING

!

Engine exhaust, some of its constituents, and certain vehicle

components contain or emit chemicals known to the State of

California to cause cancer and birth defects and reproduc-

tive harm. In addition, certain fluids contained in vehicles

and certain products of component wear contain or emit

chemicals known to the State of California to cause cancer

and birth defects or other reproductive harm.

©2010 Mitsubishi Motors Corporation

Printed in Japan
