使用说明书 Operating Instructions 电动剃须刀 (家用) Battery Shaver (Household) 型号 ES6500 Model No. 中文 English 在使用本产品前,请仔细阅读本说明书并妥善保 管,以备将来参考。 Before operating this unit, please read these instructions completely and save them for future use. ES6500_CH.indb 2009/12/25 18:29:37...
Failure to do so may result in an accident or injury. • Do not alter the appliance. Also, do not disassemble or repair it. It could result in injury. Contact an authorized Panasonic service center for repair. • Before use, always make sure that the foil has not become damaged or misshapen.
Parts identification 1 Protective cap 2 Tab 3 Outer foil Shaver head 4 Inner blade block 5 Switch lock button 6 0/1 switch 7 Battery cover 8 Cleaning brush Replacing batteries Turn off your shaver by the switching 0/1 switch to the “0” position. Remove the battery cover.
Page 9
If the shaver will not be used for a long time, please remove the batteries. • To maximize the lifetime of your shaver, Ask your dealers or Panasonic authorized service centers for maintenance and repair before disposing of it. • Make sure that the old batteries are disposed of at an officially assigned location.
Page 10
Using Remove the protective cap while pressing the tabs. Check that the outer foil is not deformed or damaged. Switch the 0/1 switch to the “1” position while pressing the switch lock button. Turn off the shaver and attach the protective cap to prevent the damage of the outer foil after use. Start out shaving by applying gentle pressure to your face. Stretch your skin with your free hand and move the shaver back and forth in the direction of your beard. You may gently increase the amount of pressure as your skin becomes accustomed to this shaver.
Page 11
Cleaning with the brush Fig. 1: Remove the outer foil and the inner blade block from the shaver. Fig. 2: Remove the inner blade block from the outer foil. • Remove the inner blade block by holding it firmly at its central shaft and pulling it vertically upward out of the shaver. If you cannot remove it with the method mentioned above, please first tilt the shaft slightly to one side and then pull it vertically upward out of the shaver.
• For the replacement method, refer to the removal and installation steps of cleaning shaver head. Specifications Product name Battery Shaver Product model ES6500 Motor voltage .0V Two AA LR6 alkaline dry-cell Batteries batteries (Sold separately) Place of origin China Date of production See engraving on the commodity.
