Chassis Tightening Torques - Yamaha 2014 MT-07 Service Manual

EAS30017

CHASSIS TIGHTENING TORQUES

Item
Engine mounting nut (rear upper
side)
Engine mounting nut (rear lower
side)
Engine mounting bolt (left front side)
Engine mounting bolt (left upper
side)
Engine mounting bolt (right front
side)
Engine mounting bolt (right upper
side)
Engine bracket bolt (right)
Engine bracket bolt (left)
Clutch cable guide bolt
Rider seat bracket bolt
Battery terminal bolt
Rider seat bolt
Lean angle sensor bolt
Starter relay bolt
Battery box bolt
Rear side cover bolt (M8 × 25 mm)
Rear side cover bolt (M6 × 12 mm)
Tail/brake light bolt
Mudguard assembly bolt
License plate/turn signal light bolt
Center cover screw
Upper tail cover screw
Headlight assembly bolt
Headlight side cover bolt
Headlight center cover bolt
Meter assembly screw
Meter assembly bracket bolt
Fuel tank top cover bolt
Fuel tank cover bolt (M5 × 12 mm)
Fuel tank cover bolt (M5 × 16 mm)
Fuel tank center cover bolt
Air scoop bolt
Fuel tank front cover lower bolt
Fuel tank front cover upper bolt
Air scoop inner panel bolt
Electrical components tray 1 bolt
Thread
Q'ty
size
M10 1
M10 1
M12 1
M10 1
M12 1
M10 1
M8 2
M8 2
M6 1
M6 4
M6 2 2.2 Nm (0.22 m·kgf, 1.6 ft·lbf)
M6 2
M4 2 2.0 Nm (0.20 m·kgf, 1.4 ft·lbf)
M6 2 3.6 Nm (0.36 m·kgf, 2.6 ft·lbf)
M6 2
M8 2
M6 2
M6 2 3.3 Nm (0.33 m·kgf, 2.4 ft·lbf)
M6 4
M6 4
M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M6 2
M6 2
M6 4 0.8 Nm (0.08 m·kgf, 0.58 ft·lbf)
M4 3 1.3 Nm (0.13 m·kgf, 0.94 ft·lbf)
M6 2
M5 1 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M5 8 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M5 2 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M6 4
M6 2 4.0 Nm (0.40 m·kgf, 2.9 ft·lbf)
M5 2 2.5 Nm (0.25 m·kgf, 1.8 ft·lbf)
M5 6 1.5 Nm (0.15 m·kgf, 1.1 ft·lbf)
M6 2
2-20
TIGHTENING TORQUES
Tightening torque
55 Nm (5.5 m·kgf, 40 ft·lbf)
55 Nm (5.5 m·kgf, 40 ft·lbf)
75 Nm (7.5 m·kgf, 54 ft·lbf)
55 Nm (5.5 m·kgf, 40 ft·lbf)
75 Nm (7.5 m·kgf, 54 ft·lbf)
55 Nm (5.5 m·kgf, 40 ft·lbf)
25 Nm (2.5 m·kgf, 18 ft·lbf)
25 Nm (2.5 m·kgf, 18 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
16 Nm (1.6 m·kgf, 12 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
10 Nm (1.0 m·kgf, 7.2 ft·lbf)
10 Nm (1.0 m·kgf, 7.2 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
7 Nm (0.7 m·kgf, 5.1 ft·lbf)
Remarks
LT
