Summary of Contents for Safety Vision 60-220003
- Page 1 60-220003 USER GUIDE...
-
Page 2: Important Notices
It is shared with your company for the sole purpose of helping you with the operation of the described equipment. Safety Vision makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. -
Page 3: Table Of Contents
60-220003 USER GUIDE Table of Contents Components Installation Configuration Connecting Audio Adjustment Live View and Image Adjustment Appendix A: Specifications Appendix B: Dimensions... -
Page 4: Components
60-220003 USER GUIDE Components Exterior 1 - Dome - Shields the camera lens while providing a wide viewing angle. 2 - Unit Cover - Protects the camera module from environmental hazards. Interior 3 - Camera Lens - Captures images. 4 - IR Illuminators - Provide clear images in low light conditions. -
Page 5: Installation
Do not use larger than a size #6 fastener to avoid damage to the camera housing. 6. Connect the 60-220003 to one of the camera inputs on front of the NVR. 7. Using a laptop, access the camera’s live view as described in the Live View and Image Adjustment section. -
Page 6: Configuration
60-220003 USER GUIDE Configuration The 60-220003 can be configured through the on-board web interface, which must be accessed with a PC and web browser. The interface can be accessed through a RoadRecorder® series NVR. Connecting Use the following procedure to access the 60-220003’s... -
Page 7: Audio Adjustment
After adjusting this field, click Save. If audio problems persist, contact Safety Vision Technical Support. Safety Vision does not recommend adjusting settings other than those described in this User Guide without the advice of Safety Vision Technical Support. -
Page 8: Live View And Image Adjustment
The Open Media window appears. In the Network URL field, enter rtsp://192.168.8.70:8XX/h264_2, where XX is the NVR port the 60-220003 is connected to. For example, if you want to view the 60-220003 connected to port 8, you would enter rtsp://192.168.8.70:808/h264_2. -
Page 9: Appendix A: Specifications
60-220003 USER GUIDE Appendix A: Specifications SPECIFICATIONS Image Sensor 1/2.8" Sony Progressive CMOS Effective Pixels 2048(H) x 1536(V) Minimum Illumiation Board 3.6 mm - 0.2 lux (Color) / 0.02 lux (B/W) Board 2.8 mm / Vari-focal 3~6 mm - TBD... -
Page 10: Appendix B: Dimensions
60-220003 USER GUIDE Appendix B: Dimensions... -
Page 11: Fcc Compliance Statement
When a product requires service, only the affected component must be returned. The customer must use proper packing Safety Vision, LLC (“SV”) makes the following limited warranty, material to ensure against damage during shipping. Any which is effective at the time of the original end-user shipping damage caused by improper packing is not covered purchase. - Page 12 CORPORATE HEADQUARTERS 6100 W. Sam Houston Pkwy. N. Houston, TX 77041-5113 Main: 713.896.6600 Toll Free: 800.880.8855 Fax: 713.896.6640 www.safetyvision.com 12/13...
