Summary of Contents for Safety Vision 48 Series

  • Page 1 48 SERIES IP CAMERA USER GUIDE...
  • Page 2 Safety Vision makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 3: Table Of Contents

    48 SERIES IP CAMERA Contents Features Parts Included Overview Cable Descriptions Installation Before you start Memory Card Camera Connecting the Camera Cables Connect Alarm Input/Output Cables Network Cable Waterproof Jacket (Optional) Configuration Camera Initialization Modify IP Address Accessing via Web Browser...
  • Page 4: Features

    • 3-axis gimbal provides flexible mounting opportunities • IP69K rating resists debris and sustained water jets • Long distance IR illuminators perfect for exterior environments Parts Included • 48 Series IP Camera with Lens Cover • Quick Start Guide • Mounting Template • Waterproof Connector •...
  • Page 5: Overview

    48 SERIES IP CAMERA Overview Gasket Lens Cover Fastener Anchors Side Cable Exit Camera Base Camera Cover Self-tapping Screws Locking Screw...
  • Page 6: Cable Descriptions

    48 SERIES IP CAMERA Cable Descriptions The following describes the different connectors that may be encountered on this camera series.
  • Page 7 48 SERIES IP CAMERA 1 - Power Input: Input power, connect to DC 12V power, and please be sure to power the device according to the instruction of device label. 2 - Alarm I/O: Input and output wires for alarm. Refer to “Alarm I/O” table for details.
  • Page 8: Installation

    48 SERIES IP CAMERA Installation Before you start • Ensure the camera is in good condition and all accessories were included. • Ensure the mounting surface is sufficient to support the weight of the camera. • Implement this step when it needs to use microSD card and there is a SD card slot for the device.
  • Page 9: Memory Card

    48 SERIES IP CAMERA Memory Card The 48 series IP cameras supports microSD card for local storage. Use the following procedure to mount the memory card. Remove camera dome cover. Using a T15 TORX™, loosen the 4 locking screws and remove dome cover.
  • Page 10: Camera

    It is also recommended to put a bead of silicone around the camera base to seal it as well. Connect 48 series camera to NVR. Connect the 48 series camera to one of the camera inputs on the NVR.
  • Page 11: Connecting The Camera Cables

    48 SERIES IP CAMERA 8. Configure 48 series camera. Using a laptop, access the camera’s live view as described in the Configuration section. Adjust camera angle and field of view. Use a small Phillips head screwdriver (pan rotation) and a T15 TORX (tilt rotation) to loosen the screws on the camera gimbal to adjust the camera angle to the desired field of view.
  • Page 12: Connect Alarm Input/Output Cables

    48 SERIES IP CAMERA Connect Alarm Input/Output Cables Connect alarm input device to the alarm input of I/O port. When the input signal is idle or grounded, the device can collect the different statuses of the alarm input port. When the input signal is connected to 3.3V or it is idle, the device collects the status “1”.
  • Page 13 48 SERIES IP CAMERA Mode B: Switch application. Alarm output is used to drive external circuit, max voltage is 12V and max current is 300mA (peak), it is recommended to add a relay when it exceeds the value. 3. Log into web interface, make corresponding settings upon alarm input and output on the interface of alarm setup.
  • Page 14: Network Cable Waterproof Jacket (Optional)

    48 SERIES IP CAMERA Network Cable Waterproof Jacket (Optional) If the camera is installed outdoors, a waterproof jacket on the connection is required for water resistance. Camera’s Network Interface Waterproof Rubber Gasket Socket Lock Nut O-Type Gasket Network Cable from Router/...
  • Page 15 48 SERIES IP CAMERA Feed the camera network cable through the lock nut, waterproof rubber gasket (the rubber gasket inset ridge must face the waterproof endcap), and the waterproof endcap in order. 2. Crimp an RJ-45 network plug onto the end of the cable, taking care to insert the twisted pairs of wires in correct order.
  • Page 16: Configuration

    48 SERIES IP CAMERA Configuration Quick Configuration The 48 series camera can be configured through the Tool software which must be accessed with a PC. The camera will need to be configured if it is the first time the camera is used or if it has been restored to factory default settings.
  • Page 17: Modify Ip Address

    48 SERIES IP CAMERA Modify IP Address Connect the PC to the NVR’s Ethernet LAN RJ-45 port with a standard Ethernet cable. 2. Ensure the NVR and PC are receiving power and have started up. 3. Run Quick Configuration Tool.
  • Page 18: Accessing Via Web Browser

    48 SERIES IP CAMERA Accessing via Web Browser In a web browser, navigate to the camera’s IP address. The default IP address is 192.168.1.108. The default login is: Username: admin Password: admin Enter username and password, click Login. 2. Install any plug-ins you are prompted to install. The main interface will be shown after all plug-ins are installed.
  • Page 19: Appendix A: Specifications

    48 SERIES IP CAMERA Appendix A: Specifications IMAGE SENSOR INFRARED ILLUMINATORS 1/3” 4MP progressive scan CMOS FOCAL LENGTH MINIMUM ILLUMINATION 2.8mm (3.6mm, 6.0mm optional) .08 lux (0 lux with IRs) FIELD OF VIEW IP RATING IP69K 104° (2.8mm), 83° (3.6mm), 55° (6.0mm) 55°...
  • Page 20: Appendix B: Dimensions

    48 SERIES IP CAMERA Appendix B: Dimensions...
  • Page 21: Fcc Compliance Statement

    48 SERIES IP CAMERA FCC Compliance Statement NOTE This device has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 22 48 SERIES IP CAMERA Memo...
  • Page 23 48 SERIES IP CAMERA Memo...
  • Page 24 CORPORATE HEADQUARTERS 6100 W. Sam Houston Pkwy. N. Main: 713.896.6600 Houston, TX 77041-5113 Toll Free: 800.880.8855 www.safetyvision.com Fax: 713.896.6640 Copyright © 2019 Safety Vision, LLC All Rights Reserved.
