Draytek Vigor2820 Series Quick Start Manual page 11

Interface Description
Wireless LAN Press "Wireless LAN ON/OFF/WPS" button for 2 seconds to wait for client device
ON/OFF/WPS making network connection through WPS.
Press "Wireless LAN ON/OFF/WPS" button once to enable (WLAN LED on) or
disable (WLAN LED off) wireless connection.
Factory Reset Restore the default settings. Usage: Turn on the router (ACT LED is blinking). Press
the hole and keep for more than 5 seconds. When you see the ACT LED begins to
blink rapidly than usual, release the button. Then the router will restart with the
factory default configuration.
Phone 1/2 Connecter for PSTN phone.
Line Connector for PSTN life line.
LAN (1-4) Connecters for local networked devices.
DSL Connecter for accessing the Internet through ADSL2/2+.
WAN 2 Connecter for remote networked devices.
USB Connecter for a USB device (for 3G USB Modem or printer).
Connecter for a power adapter.
PWR
Power Switch.
ON/OFF
7
