EN
User Manual
Microwave Oven
KR8403001
KR8403021
KR8403101

Advertisement

Table of Contents
loading

Related Manuals for AEG KR8403001

Summary of Contents for AEG KR8403001

  • Page 1 User Manual KR8403001 Microwave Oven KR8403021 KR8403101...

  • Page 2: Table Of Contents

    14. TROUBLESHOOTING....................27 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.
  • Page 4 Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal •...

  • Page 5: Safety Instructions

    ENGLISH Eggs in their shell and whole hard-boiled eggs should • not be heated in the appliance since they may explode, even after microwave heating has ended. The appliance should be cleaned regularly and any • food deposits removed. Failure to maintain the appliance in a clean condition •...
  • Page 6 2.3 Use appliance. It is not a defect in the sense of the warranty law. WARNING! • Use a deep pan for moist cakes. Fruit Risk of injury, burns and juices cause stains that can be electrical shock or explosion.

  • Page 7: Product Description

    ENGLISH • Disconnect the appliance from the WARNING! mains supply. Risk of electrical shock. • Cut off the mains cable and discard it. • Remove the door catch to prevent • Before replacing the lamp, disconnect children and pets to get closed in the the appliance from the power supply.

  • Page 8: Control Panel

    4. CONTROL PANEL 4.1 Electronic programmer Use the sensor fields to operate the appliance. Sensor Function Comment field Display Shows the current settings of the appliance. ON / OFF To activate and deactivate the appliance. Grilling or Assis- Touch the sensor field once to choose a heating ted Cooking function or the menu: Assisted Cooking.

  • Page 9: Before First Use

    ENGLISH Sensor Function Comment field Time and addi- To set different functions. When a heating func- tional functions tion operates, touch the sensor field to set the timer or the functions: Function Lock, Favourite Programme, Heat + Hold, Set + Go. Minute Minder To set the function: Minute Minder.

  • Page 10: Daily Use

    Refer to "Care and the display brightness and the time of cleaning" chapter. the day. Clean the appliance before first use. 1. Press to set the value. Put the accessories and the removable 2.

  • Page 11: Energy Saving

    ENGLISH Sym- Submenu Description Set + Go When ON, in the Select Options window you can choose the function: Set + Go. Heat + Hold When ON, in the Select Options window you can choose the function: Heat + Hold. Extra Time Activates and deactivates the time extension function.

  • Page 12: Microwave Mode

    The residual heat inside elements deactivate automatically the oven will continue to cook. 10% earlier. The fan and lamp – Use the residual heat to warm up continue to operate. other foods. • Cooking with the lamp off - •...
  • Page 13 ENGLISH microwave if they are expressively (e. g. remove the metal cover and designated as suitable for use in the pierce the plastic film). microwave. Tips for the microwave • You must follow the manufacturer's instructions printed on the packaging Result Remedy You cannot find details for the amount...
  • Page 14 Cookware / Material Microwave Grilling Defrost- Heating Cooking Baking tins, black lacquer or silicon- coated Baking tray Browning cookware, e. g. crisp pan or crunch plate Ready meals in packaging 1) With no silver, gold, platinum or metal plating / decorations 2) Without quartz or metal components, or glazes which contain metals 3) You must follow the manufacturer’s instructions about the maximum temperatures.

  • Page 15: Setting The Microwave

    ENGLISH 7.3 Setting the Microwave To deactivate the Microwave function function, touch 1. Activate the appliance. If you touch or open the 2. Touch to activate the Microwave door, the function stops. To function. start it again, touch . 3. Touch . The function: Duration is set to 30 seconds and the 7.4 Setting the Combi function microwaves starts to operate.

  • Page 16: Clock Functions

    Power setting • 600 Watt • Defrosting and heating frozen meals • 500 Watt • Heating one-plate meals • Simmering stews • Cooking egg dishes • 400 Watt • Continuing to cook meals • 300 Watt • Cooking delicate food •...

  • Page 17: Automatic Programmes

    ENGLISH 8.2 Setting the clock functions • The function: Duration is set. The function: Heat + Hold keeps prepared food warm at 80 °C for 30 • Before you use the minutes. It activates after the baking or functions: Duration, End roasting procedure ends.

  • Page 18: Using The Accessories

    When you use the function: Manual, the appliance uses the automatic settings. You can change them as with other functions. 10. USING THE ACCESSORIES WARNING! Refer to Safety chapters. • All accessories have small indentations at the top of the right and left side to 10.1 Inserting the accessories...

  • Page 19: Using The Child Lock

    ENGLISH 11.4 Set + Go The next letter flashes. 9. Do step 7 again as necessary. The function lets you set a heating 10. Press and hold to save. function (or a programme) and use it You can overwrite a memory position. later with one press of a sensor field.

  • Page 20: Hints And Tips

    10 PM and 6 the display goes back to the night brightness. • Day brightness: 11.7 Cooling fan – when the appliance is activated. – if you touch a sensor field during When the appliance operates, the...

  • Page 21: Microwave Cooking

    ENGLISH 12.2 Microwave cooking tables Defrosting meat Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Whole cuts 10 - 12 10 - 15 Turn halfway of meat through. Steak 3 - 5 5 - 10 Turn halfway through, re- move defros- ted parts.
  • Page 22 Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Duck 2000 45 - 60 20 - 30 Turn halfway through, cov- er defrosted parts with aluminium foil. Defrosting fish Food Power Quantity (g) Time (min) Standing Comments...
  • Page 23 ENGLISH Defrosting cakes / pastries Food Power Quantity Time (min) Standing Comments (Watts) time (min) Yeast dough 1 piece 2 - 3 15 - 20 Turn plate halfway through. Cheesecake 1 piece 2 - 4 15 - 20 Turn plate halfway through.
  • Page 24 Cooking / melting Food Power Quantity (g) Time (min) Standing Comments (Watts) time (min) Chocolate / 2 - 3 Stir halfway Chocolate through. coating Butter 2 - 4 Stir halfway through. Defrosting heating Food Power Quantity Time (min) Standing...
  • Page 25 ENGLISH Cooking table Food Power Quantity Time (min) Standing Comments (Watts) time (min) Whole fish 500 g 8 - 10 Cook cov- ered, turn container several times during cook- ing. Fish fillets 500 g 6 - 8 Cook cov- ered, turn container several times during cook-...

  • Page 26: Care And Cleaning

    Food Power Quantity Time (min) Standing Comments (Watts) time (min) Rice 1000 300 g + 600 4 - 6 Cook cov- ered, stir halfway through. Popcorn 1000 3 - 4 Put the pop- corn on a plate on the bottom level.

  • Page 27: Troubleshooting

    ENGLISH To clean the appliance, remove the shelf WARNING! supports. Danger of electrocution! 1. Pull carefully the supports up and out Disconnect the fuse before of the front catch. you replace the lamp. The lamp and the lamp glass cover can be hot. CAUTION! Always hold the halogen lamp with a cloth to prevent...

  • Page 28: Environmental Concerns

    Problem Possible cause Remedy The oven does not heat up. The fuse is released. Make sure that the fuse is the cause of the malfunction. If the fuse releases again and again, contact a quali- fied electrician. The lamp does not operate.
  • Page 29 ENGLISH...
  • Page 30 www.aeg.com...
  • Page 31 ENGLISH...
  • Page 32 www.aeg.com/shop...

This manual is also suitable for:

Kr8403101Kr8403021Kr8473121
