AEG KMK721000M User Manual

Hide thumbs Also See for KMK721000M:
Table of Contents

Advertisement

Quick Links

Download this manual
KMK721000M
USER
MANUAL
EN
User Manual
Microwave Oven

Advertisement

Table of Contents
loading

Related Manuals for AEG KMK721000M

Summary of Contents for AEG KMK721000M

  • Page 1 KMK721000M User Manual Microwave Oven USER MANUAL...

  • Page 2: Table Of Contents

    14. TROUBLESHOOTING...................27 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 ENGLISH manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 •...
  • Page 4 Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal •...

  • Page 5: Safety Instructions

    ENGLISH Microwave heating of beverages can result in delayed • eruptive boiling. Care must be taken when handling the container. The contents of feeding bottles and baby food jars • shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns. Eggs in their shell and whole hard-boiled eggs should •...
  • Page 6 Make sure that there is • Do not use microwave function to access to the mains plug after the preheat the oven. installation. WARNING! • If the mains socket is loose, do not Risk of damage to the connect the mains plug.

  • Page 7: Product Description

    ENGLISH Contact the Authorised Service for household appliances. Do not use Centre. it for house lighting. • Make sure the cavity and the door are WARNING! wiped dry after each use. Steam Risk of electrical shock. produced during the operation of the appliance condensates on cavity walls •...

  • Page 8: Control Panel

    3.2 Accessories For cookware, cake tins, roasts. Wire shelf 4. CONTROL PANEL 4.1 Electronic programmer Use the sensor fields to operate the appliance. Sensor Function Comment field Display Shows the current settings of the appliance. ON / OFF To activate and deactivate the appliance.
  • Page 9 ENGLISH Sensor Function Comment field Up key To move up in the menu. OK / Microwave To confirm the selection or settings. To activate Quick Start the Microwave function. You can use it when the appliance is deactivated. Back key To go back one level in the menu.

  • Page 10: Before First Use

    Symbol Function Heat-up Indicator The display shows the temperature in the appliance. Heat + Hold The function is active. 5. BEFORE FIRST USE 5.2 First Connection WARNING! Refer to Safety chapters. When you connect the appliance to the mains or after the power cut, you have to 5.1 Initial Cleaning...
  • Page 11 ENGLISH Sym- Menu item Application Favourites Contains a list of favourite cooking programmes created by the user. Submenu for: Basic Settings Sym- Submenu Description Set Time of Day Sets the current time on the clock. Time Indication When ON, the display shows the current time when you deactivate the appliance.

  • Page 12: Microwave Mode

    6.5 Residual heat temperature to minimum 3 - 10 minutes before the end of the cooking time, When you deactivate the appliance, the depending on the duration of the display shows the residual heat. You can cooking. The residual heat inside the use the heat to keep the food warm.
  • Page 13 ENGLISH e.g. on handles . Moisture going into Defrosting fruit, vegetables: the holes can cause the cookware to • If fruit and vegetables should remain crack when it is heated. raw, do not defrost them fully in the Defrosting meat, poultry, fish: appliance but let them defrost •...
  • Page 14 Cookware / Material Microwave Grilling Defrost- Heating Cooking Baking tins, black lacquer or silicon- coated Wire shelf Browning cookware, e.g. crisp pan or crunch plate Ready meals in packaging 1) With no silver, gold, platinum or metal plating / decorations.
  • Page 15 ENGLISH 7.4 Microwave functions Functions Description Microwave Creates the heat directly in the food. Use it to heat pre-prepared meals and drinks, to defrost meat or fruit, and to cook vegetables and fish. Combi Use it to operate the heating function and the microwave mode to- gether.
  • Page 16 7.7 Setting the Quick Start 3. Touch to set the time for the function function: Duration. Refer to "Setting the clock functions". 1. If necessary, touch to deactivate 7.8 Examples of cooking the appliance. applications for power settings 2. Touch to activate the Quick Start function.

  • Page 17: Clock Functions

    ENGLISH 8. CLOCK FUNCTIONS 8.1 Clock functions table Clock function Application Minute Minder To set a countdown (max. 2 h 30 min). This function has no effect on the operation of the appliance. You can also activate it when the appliance is deactivated.

  • Page 18: Automatic Programmes

    8.4 Time Extension 1. When the cooking time ends, an acoustic signal sounds. Press any The function: Time Extension makes the symbol. heating function continue after the end The display shows the message. of Duration. 2. Press to activate or cancel.

  • Page 19: Additional Functions

    ENGLISH Small indentation at the top increase safety. The indentations are also anti-tip devices. The high rim around the shelf prevents cookware from slipping of the shelf. 11. ADDITIONAL FUNCTIONS 11.1 Favourites Activating the programme You can save your favourite settings, 1.

  • Page 20: Hints And Tips

    11.4 Set + Go Temperature (°C) Switch-off time (h) The function lets you set a heating function (or a programme) and use it 120 - 195 later with one press of any symbol. 200 - 230 1. Activate the appliance.
  • Page 21 ENGLISH CAUTION! Always grill with the oven door closed. Grilling Food Temperature Time (min) Shelf position (°C) 1st side 2nd side Roast beef, me- 210 - 230 30 - 40 30 - 40 dium Filet of beef, 20 - 30 20 - 30 medium Back of pork...
  • Page 22 Defrosting poultry Food Power Quantity Time (min) Standing Comments (Watts) (kg) time (min) Chicken 25 - 30 10 - 20 Turn halfway through, cov- er defrosted parts with aluminium foil. Chicken 0.1 - 0.2 3 - 5 10 - 15...
  • Page 23 ENGLISH Defrosting dairy products Food Power Quantity Time (min) Standing Comments (Watts) (kg) time (min) Quark 0.25 10 - 15 25 - 30 Remove alu- minium parts, turn halfway through. Butter 0.25 3 - 5 15 - 20 Remove alu- minium parts, turn halfway through.
  • Page 24 Food Power Quantity Time (min) Standing Comments (Watts) time (min) Bread rolls 4 rolls 5 - 8 5 - 10 Turn halfway through. Defrosting fruit Food Power Quantity Time (min) Standing Comments (Watts) (kg) time (min) Strawberries 8 - 12...
  • Page 25 ENGLISH Food Power Quantity Time (min) Standing Comments (Watts) time (min) Frozen ready 0.4 - 0.5 kg 4 - 6 Remove any meals aluminium lids, turn half- way through. Milk 1000 1 cup ap- 1:15 - 1:45 Put spoon in prox.
  • Page 26 Food Power Quantity Time (min) Standing Comments (Watts) time (min) Vegetables, 0.5 kg 14 - 20 Add approx. long cooking 50 ml water, cook cov- time, fresh ered, stir halfway through. Vegetables, 0.5 kg 18 - 24 Add approx.

  • Page 27: Care And Cleaning

    ENGLISH 13. CARE AND CLEANING 2. Pull the front end of the shelf support WARNING! away from the side wall. Refer to Safety chapters. 3. Pull the supports out of the rear catch. 13.1 Notes on cleaning Install the shelf supports in the opposite sequence.
  • Page 28 14.1 What to do if... Problem Possible cause Remedy You cannot activate or oper- The oven is not connected Check if the oven is correctly ate the oven. to an electrical supply or it is connected to the electrical connected incorrectly.
  • Page 29 ENGLISH We recommend that you write the data here: Model (MOD.) ......... Product number (PNC) ......... Serial number (S.N.) ......... 15. ENVIRONMENTAL CONCERNS marked with the symbol with the Recycle the materials with the symbol household waste. Return the product to Put the packaging in applicable your local recycling facility or contact containers to recycle it.
  • Page 30 www.aeg.com...
  • Page 31 ENGLISH...
  • Page 32 www.aeg.com/shop...
