- Page 1 EN User Manual | Microwave combi-oven CME565060B CMK36506MM CMK56506MM KME565060B KMK565060B KMS365060M...
-
Page 2: Table Of Contents
FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Only a qualified person must install this appliance and replace the cable. • Do not use the appliance before installing it in the built-in structure. • Disconnect the appliance from the power supply before carrying out any maintenance.
- Page 5 • When heating food in plastic or paper containers, observe the appliance due to the possibility of ignition. • The appliance is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
-
Page 6: Safety Instructions
2. SAFETY INSTRUCTIONS 2.1 Installation Ventilation opening mini‐ 560x20 mm mum size. Opening placed WARNING! on the bottom rear side Only a qualified person must install this Mains supply cable length. 1500 mm appliance. Cable is placed in the right corner of the back side •... - Page 7 • The electrical installation must have an – be careful when you remove or install isolation device which lets you disconnect the accessories. the appliance from the mains at all poles. • Discoloration of the enamel or stainless The isolation device must have a contact steel has no effect on the performance of opening width of minimum 3 mm.
- Page 8 2.5 Glassware use • Concerning the lamp(s) inside this product and spare part lamps sold separately: Handling your glassware without an These lamps are intended to withstand appropriate degree of care could result in extreme physical conditions in household breakage, chipping, cracking or severe appliances, such as temperature, scratching: vibration, humidity, or are intended to...
-
Page 9: Product Description
3. PRODUCT DESCRIPTION 3.1 General overview Control panel Knob for the heating functions Display Control knob Heating element Microwave generator Lamp Shelf support, removable Shelf positions 3.2 Accessories Wire shelf For cookware, cake tins, roasts. Baking tray For cakes and biscuits. Microwave bottom glass plate To prepare food in microwave mode. -
Page 10: Control Panel
4. CONTROL PANEL 4.1 Retractable knobs functions to the off position to turn the appliance off. To use the appliance press the knob. The knob comes out. 4.2 Control panel overview Select a heating function to turn on the appliance. Turn the knob for the heating Timer Fast Heat Up Light... -
Page 11: Daily Use
5.1 Initial cleaning Before the first use, clean the empty appliance and set the time: 00:00 Set the time. Press 6. DAILY USE WARNING! Refer to Safety chapters. 6.1 How to set: Heating functions Step 1 Turn the knob for the heating functions and select a heating function. Step 2 Turn the control knob to set the temperature. - Page 12 If you open the door, the microwave function stops. To start it again, close the door. Press 6.3 How to set: Microwave combi functions Step 1 Remove all accessories. Insert microwave bottom glass plate. Put the food on the microwave bottom glass plate. Step 2 Turn the knob for the heating functions and select the function: The display shows: temperature and microwave power.
- Page 13 Heating function Application Defrosting meat, fish, cakes, power range: 100 - 200 W Defrost Heating up pre-prepared meals and delicate food, power range: 300 - 700 W Reheat Heating up, cooking, power range: 100 - 1000 W Microwave To enter the Menu: Assisted Cooking, Settings. Menu 6.5 How to set: Assisted Cooking The Assisted Cooking submenu consists of a set of additional functions and dishes with...
- Page 14 The display shows P and a number of the dish that you can check in the table. Grill + To cook food in a short time and to brown it. The function with MW boost, power range: 100 - 600 W. Dish Weight Shelf level / Accessory...
- Page 15 Dish Weight Shelf level / Accessory Lamb leg with bones 1.5 - 2 kg; 7 - 9 cm 1; roasting dish on baking tray thick pieces Fry the meat for a few minutes on a hot pan. Add liquid. Turn the meat after half of the cooking time. Whole chicken 1 - 1.5kg;...
-
Page 16: Clock Functions
Dish Weight Shelf level / Accessory Baked potatoes 1 kg 1; baking tray Put the whole potatoes with skin on baking tray. Wedges 1 kg 2; baking tray lined with baking paper Use your favourite spices. Cut potatoes into pieces. Grilled mixed vegeta‐... - Page 17 Clock Function Application Maximum is 23 h 59 min. This function has no effect on the operation of the oven. To turn on and off the Uptimer select: Menu, Settings. Uptimer Clock functions are available only for: True Fan Cooking, Conventional Cooking, Turbo Grilling, Pizza Function, Turbo Grilling + MW, True Fan Cooking + MW.
-
Page 18: Using The Accessories
How to set: Time Delay Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 The dis‐ play The display shows: the shows: time of day --:-- STOP Select the Press repeat‐ START Set the start Set the end heating Press: Press:... -
Page 19: Additional Functions
Microwave bottom glass plate: Use the microwave bottom glass plate only with microwave function. It is not suitable for combined microwave function (e.g. microwave grilling). Put the accessory on the bottom of the cavity. You can put the food directly on the microwave bottom glass plate. -
Page 20: Hints And Tips
10. HINTS AND TIPS 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Your appliance may bake or roast differently to the appliance you had before. The hints below show recommen‐ ded settings for temperature, cooking time and shelf position for specific types of the food. - Page 21 Cookware / Material Ovenproof glass and porcelain with no metal components, e.g. heat-proof glass Non-ovenproof glass and porcelain without any silver, gold, platinum or other metal decorations Glass and glass ceramic made of ovenproof / frost-proof material Ovenproof ceramic and earthenware without any quartz or metal compo‐...
- Page 22 500 - 600 W Defrosting and Cooking egg Heating one-plate Cooking vegetables Simmering stews heating frozen dishes meals meals 300 - 400 W Melting cheese, Cooking / Heating deli‐ Simmering rice Heating baby food Continuing cooking chocolate, butter cate food 100 - 200 W Defrosting cheese, cream, Defrosting bread...
-
Page 23: Care And Cleaning
Cake, 0.7 kg Conventional 23 - 27 Turn container around Cooking + MW by 1/4, halfway through the cooking time. Potato gra‐ True Fan 38 - 42 Turn container around tin, 1.1 kg Cooking + MW by 1/4, halfway through the cooking time. -
Page 24: Troubleshooting
Step 2 Carefully pull the shelf supports up and out of the front catch. Step 3 Pull the front end of the shelf support away from the side wall. Step 4 Pull the supports out of the rear catch. Install the shelf supports in the opposite sequence. 11.3 How to replace: Lamp Always hold the halogen lamp with a cloth to prevent grease residue from burning on the... -
Page 25: Energy Efficiency
The appliance does not turn on or does not heat up You cannot activate or operate the appliance. The appliance is correctly connected to an electrical supply. The appliance does not heat up. The automatic switch-off is deactivated. The appliance does not heat up. The fuse is not blown. -
Page 26: Menu Structure
Keep breaks between baking as short as cooking. The residual heat inside the possible when you prepare a few dishes at appliance will continue to cook. one time. Use the residual heat to warm up other Cooking with fan dishes. When possible, use the cooking functions Keep food warm with fan to save energy. -
Page 27: Environmental Concerns
15. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office. - Page 28 867370859-B-112023...
