Summary of Contents for HIKVISION 64 Series

  • Page 1: Network Camera

    Network Camera Installation Manual (5.0.8) UD.6L0201A1187A01...
  • Page 2 Installation Manual of Network Camera 64xx Series Camera Installation 6.1 Overview 13 14 9 10 11 VIN1 AUDIO AUDIO LAN(PoE) RXD TXD GND IN1 1B 1A DC 12V RESET 16 17 Figure 6-1 The Overview of Covert Camera with Cylindrical Sensor Unit 13 14 9 10 11 VIN1...
  • Page 3: Installation Of Main Unit

    Installation Manual of Network Camera Table 1-8 Table 1 1 Description of the Camera Description Description Main Unit STATUS Indicator LED Mounting Rail LINK Indicator LED Block-Shaped Sensor Unit Audio Interface Cover RJ-12 Interface Straight Mounting Bracket Micro SD Card Slot Cylindrical Sensor Unit RESET Button RJ-12 Cable...
  • Page 4: Installation Of Block-Shaped Sensor Unit

    Installation Manual of Network Camera  For cement surface mounting, you need to use the expansion screw to fix the camera.  For wooden surface mounting, you can just use the self-tapping screw to fix the camera. 2. Hang the hook which is on upper-side of the main unit onto the rail, press a little harder on the lower part of the main unit, and then the elastic clasp will be automatically buckled.
  • Page 5: Concealed Mounting

    Installation Manual of Network Camera Concealed Mounting Please make sure that the mounting surface is suitable for adhesive pasting. Steps: 1. Drill on the mounting surface. As shown in Figure 6-6. Figure 6-6 Drill on the Surface Make sure the drilling hole is big enough for the camera lens. 2.
  • Page 6: Exposed Mounting

    Installation Manual of Network Camera Figure 6-8 Insert the Block-shaped Sensor Unit Exposed Mounting Steps: 5. Fix the Block-shaped sensor unit on the mounting surface with screws. As shown in Figure 2-7. Figure 6-9 Fix the Block-shaped Sensor Unit  For cement surface mounting, you need to use the expansion screw to fix the camera.
  • Page 7: Installation Of Cylindrical Sensor Unit

    Installation Manual of Network Camera Figure 6-10 Hood the Cover 6.2.3 Installation of Cylindrical Sensor Unit This series of camera only support concealed mounting. Please make sure that the mounting surface is suitable for adhesive pasting. Steps: 1. Drill on the mounting surface. As shown in Figure 6-11. Figure 6-11 Drill on the Surface Make sure that the drilling hole is big enough for the camera lens.
  • Page 8 Installation Manual of Network Camera Figure 6-12 Paste the Bracket 3. Install the cylindrical sensor into the mounting hole in the round rail bracket. 4. Turn the locking sleeve to fix the sensor. As shown in Figure 6-13. Figure 6-13 Install the Cylindrical Sensor...
  • Page 9 Installation Manual of Network Camera...
