- Page 1 KTC-D500E DIGITAL TV TUNER INSTRUCTION MANUAL C B64-3808-00/00 (E)
-
Page 2: Table Of Contents
List of Accessories Installing the Digital TV Tuner Installing and Connecting the Remote Control Receiver Inserting Pay Card Connection Specifications KTC-D500E Notes Displaying EPG Viewing the Program Guide Channel Search and Channel List Searching for currently available station (Auto Scan) -
Page 3: Safety Precautions
Safety precautions 2WARNING • Mounting and wiring this product requires skills and experience. For safety’s sake, leave the mounting and wiring work to professionals. 2CAUTION • Make sure to ground the unit to a negative 12V DC power supply. • Use only the screws provided or specified for installation. -
Page 4: Notes
How to reset your unit • If the unit fails to operate properly, press the Reset button. KTC-D500E This Product is not installed by the manufacturer of a vehicle on the production line, nor by the professional importer of a vehicle into an EU Member State. -
Page 5: Getting Started
Getting Started Lets view some digital broadcasts. Switching to Digital TV Screen Press [V.SEL] on the monitor to switch to Digital TV Broadcasting. Preset 3 TV TV1 AUTO1 Mode : F u l l AUTO1 ⁄ • When you first switch to digital TV broadcasting, a Welcome Menu appears and Auto Scan starts. -
Page 6: Functions During Digital Tv Screen Ç
[List of abbreviations] Channel Electronic Program Guide On Screen Display Picture in Graphic KTC-D500E Touch Operation Menu Control Screen appears by touching the area shown below. 1 Shows EPG Screen (page 10). 2 Shows DVB Menu Screen (page 11). -
Page 7: Basic Operation (When Connected With Ddx7029 Å)
Basic Operation (When connected with DDX7029 Å) Various control screens appear in the Digital TV Source mode. (You can only operate Digital TV with the optional accessory Digital TV Tuner connected.) Functions When Displaying the Easy Control Panel Displays a floating control panel in the screen. Mode : F u l l Mode :... -
Page 8: Basic Operation (When Connected With Ddx6029 I)
• The Easy Control Panel display is hidden when you touch a central area of the monitor. • Buttons other than mentioned above are disabled in DVB mode. KTC-D500E (When connected with DDX6029 ı) Displaying the TV Control screen You can tune in a TV station using various functions. -
Page 9: Basic Operation (When Connected With Lz-760R Ç)
Basic Operation (When connected with LZ-760R Ç) Various control screens appear in the Digital TV Source mode. (You can only operate Digital TV with the optional accessory Digital TV Tuner connected.) Functions While Displaying the Control Screen You can tune in a TV station using various functions. -
Page 10: Displaying Epg
[2] or [3]. Touch [Return] ( ) when you are finished ⁄ • A "no data" message will be displayed if the selected channel does not provide EPG data. • It can also be displayed from the Menu Control screen. KTC-D500E... -
Page 11: Channel Search And Channel List
Channel Search and Channel List The available stations (TV/Radio) are saved in the Channel List. Searching for currently available station (Auto Scan) Search for currently available stations and save them in the Channel List. Show DVB Menu by pressing [MENU] key Touch [5] or [∞], select [Channel Search] Touch [3] Touch [5] or [∞], select [Auto Scan]... -
Page 12: Selecting A Station From Channel List
When you move the cursor down the channel list, the PIG screen will change accordingly. Touch [Enter] ( The received channel is switched. KTC-D500E Erasing Channel List Erase channels registered in the Channel List. Show DVB Menu by pressing [MENU] key Touch [5] or [∞], select [CH Manager]... -
Page 13: Setup
Setup Setting this unit's behavior and clock. System Setup Set the behavior of this unit such as the display language and aspect ratio. The following items can be set: OSD Language User could select the desired language. This function provides 4:3 and 16:9 two ratio for user to select. -
Page 14: Setting The Clock
⁄ • Real-time data (Year, Month, Date, and Hour) will automatically be downloaded when the Clock Setting Menu is shown. KTC-D500E Updating the Software Download the new software from the network and update the software installed in this unit. Show DVB Menu by pressing [MENU] key Touch [5] or [∞], select [Setup]... -
Page 15: Restoring To Factory Default
Restoring to Factory Default Restore this unit's settings to factory default. Show DVB Menu by pressing [MENU] key Touch [5] or [∞], select [Setup] Touch [3] Touch [5] or [∞], select [Factory Default] A confirmation message appears. Touch [2] or [3] to show [OK] Touch [OK] English... -
Page 16: Information And Conax
Touch [3] Touch [5] or [∞] to select the information to display Touch [2] or [3] The selected information is displayed. KTC-D500E Setting CA Control Set channel access control (CA Control) for channels broadcasting programs of specific genre. Show DVB Menu by pressing [MENU] key Touch [5] or [∞], select [Info &... - Page 17 ⁄ • This function is not available unless a card is inserted. • You can change the [Card Level] by touching [2] or [3]. However, you must enter a password when [Enter CA PIN:] appears to change the Card Level setting. •...
-
Page 18: Remote Control Unit
TV/Radio mode (i.e. not when a menu is opened). MENU Press once to enter Main Menu. The Main Menu consists of 4 sub-menus. – CH Manager – Channel Search – Setup – Info & Conax. KTC-D500E INFO MUTE POWER S U B MENU TITLE TV/RADIO EXIT... - Page 19 Page up a. TV/radio mode b. Page down LANG Switches language. TIMER Sleep timer. Press to set different times. AUDIO Audio modes. Switches to teletext. 0 – 9 a. Selects a channel to watch. Press two numbers one after the other to go beyond 9 (e.g.
-
Page 20: List Of Accessories
1 Digital TV Tuner ... 1 2 Remote Control Unit ... 1 5 TV Interface Cable ... 1 6 Bracket ... 2 9 Screw (ø4×16mm) ... 4 KTC-D500E 4 Remote Control 3 Wiring harness ... 1 Receiver ...1 7 Card Slot Cover ... 1... -
Page 21: Installing The Digital Tv Tuner
Installing the Digital TV Tuner The Digital TV Tuner (main unit) can be installed by securing it to the pile carpet with Velcro or by screwing it on to a commercially available audio board. Installing the Main Unit • There are various terminals on the main unit. Leave some space to connect cables on the terminal side of the main unit. -
Page 22: Installing And Connecting The Remote Control Receiver
• Wipe oil and dirt off from the installation surface. • Avoid area where there is direct sunlight or close to TV monitor because the remote control signals may be affected. KTC-D500E Remote control receiver 4 Remote control receiver 4... -
Page 23: Inserting Pay Card
Inserting Pay Card Insert the Pay Card into the card slot, and attach the card slot cover. Screw (M3×4mm) 8 Card Slot Cover 7 Digital TV Tuner 1 English... -
Page 24: Connection
Battery KTC-D500E Wiring harness 3 TV Interface Cable 5 Car fuse box Set C position when connecting by Kenwood TV Interface Cable. Ground wire (Black) - (To car chassis) Fuse (5A) Battery wire (Yellow) Fuse (3A) Ignition wire (Red) To the center unit such as a DVD receiver. -
Page 25: Specifications
Specifications TV tuner Input Frequency VHF : 174 – 230 MHz UHF : 470 – 862 MHz Demodulation Type : QPSK/ 64QAM/ 16QAM Channel Bandwidth : 6/ 7/ 8 MHz FFT Size : 2K and 8K Guard Interval : 1/4, 1/8, 1/16, 1/32 Puncture Rate : 1/2, 2/3, 3/4, 5/6, 7/8 Antenna input...
