INSTRUCTION MANUAL
Power Planer
1923H
010674
DOUBLE INSULATION
IMPORTANT: Read Before Using.
1

Advertisement

Table of Contents
loading

Related Manuals for Makita 1923H

Summary of Contents for Makita 1923H

  • Page 1 INSTRUCTION MANUAL Power Planer 1923H 010674 DOUBLE INSULATION IMPORTANT: Read Before Using.

  • Page 2: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model 1923H Planing width 82 mm Planing depth 3.5 mm Shiplapping depth 23 mm No load speed (min 16,000 Overall length 293 mm Net weight 3.5 kg Safety class • Due to our continuing programme of research and development, the specifications herein are subject to change without notice.

  • Page 3: Planer Safety Warnings

    If operating a power tool in a damp location is accessories, or storing power tools. Such unavoidable, use a residual current device preventive safety measures reduce the risk of (RCD) protected supply. Use of an RCD reduces starting the power tool accidentally. the risk of electric shock.

  • Page 4: Functional Description

    Switch action cause vibration and shorten tool life. 17. Use only Makita blades specified in this CAUTION: manual. Before plugging in the tool, always check to see •...
  • Page 5 Use only the Makita wrench provided to remove or • adjusting plate. Now slip the heel of the adjusting plate install the blades.
  • Page 6 Tighten the three hex flange head bolts (with the 1. Pan head screw socket wrench provided) and rotate the drum to 2. Adjusting plate check clearances between the blade ends and the 3. Planer blade tool body. locating lugs Check the three hex flange head bolts for final 4.

  • Page 7: Correct Setting

    For European countries and areas When you wish to perform clean planing operation, connect a Makita vacuum cleaner to your tool. Install the nozzle on the tool using the screws. Then connect a hose of the vacuum cleaner to the nozzle as shown in the figures.

  • Page 8: Planing Operation

    For other countries and areas Shiplapping (Rabbeting) A nozzle and joint (optional accessories) are necessary to connect a Makita vacuum cleaner to your tool. Consult a Makita catalogue or representative on the nozzle and joint. Nozzle assembly (optional accessory) 1. Screw 2.

  • Page 9: Maintenance

    To make a chamfering cut as shown in the figure, align the "V" groove in the front base with the edge of the workpiece and plane it. MAINTENANCE CAUTION: Always be sure that the tool is switched off and • unplugged before attempting to perform inspection 002584 or maintenance.

  • Page 10: Replacing Carbon Brushes

    The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center.
  • Page 12 Makita Corporation www.makita.com 883522J3...
