Honeywell 3 系统配置 图 2-2)分别配置了默认的IP地址,分别为 网络接警机在出厂时为两个千兆网口(见 192.168.0.2 和 192.168.1.2。用户可根据需要为这两个网口配置另外的IP地址,具体步骤如 下: 配置需要与接警机相连的 PC 机网卡,修改其对应网络连接的 Internet Protocol(TCP/IP) 属性,属性窗口如下图所示: 图 3-1 Internet Protocol(TCP/IP) 属性窗口 在上图所示的窗口中,选择“使用下面的 IP 地址”,并在“IP 地址”中设置一个与 默认 IP 地址处于同一子网的 IP 地址(例如 192.168.0.3 或 192.168.1.3)。点击 【确定】按钮完成配置。 将 PC 机与网络接警机的千兆网口相连。 如第一步中配置的 IP 地址为 192.168.0.X,则 PC 机应与千兆网口 1 相...
CMS with a RS232 serial port cable, and stores alarms in its database. You can search the alarms with the keys and display on the front panel, and log in the IP Receiver System to search, manage and back up the received alarms.
Page 24
Honeywell Specifications: 180~265V AC Voltage Input 177mm(H)×482.6mm(W)×452mm(D) Dimension Weight 15.20 kg Display 4 lines, 20 characters VFD Mounting Rack Mounting 0℃~50℃ Operating Temperature Package checklist: Name Quantity IP Receiver User Guide Serial port cable...
IP Receiver. The indicator turns green when IP Receiver is connected to COMM the serial port of CMS and turns red when IP Receiver is not connected to CMS. The indicator is green and flashes when IP Receiver is EVENT reporting alarms.
Gigabit Ethernet port 2 COM4 COM3 HDD Indicator USB2.0 Power Indicator PS/2 Power ON/OFF switch CMS can be connected to the COM2 port on IP Receiver with a crossover serial port cable. The communication port COM2 is a 9-pin COM port.
Ethernet port 1; if the IP address set in step 1 is 192.168.1.X, connect your PC to gigabit Ethernet port 2. Log in “IP Receiver System” to change the network configuration (if IP Receiver is connected to gigabit Ethernet port 1, enter http://192.168.0.2...
There are three options for searching alarms: “All Alarms”, “Reported Alarm” and “Unreported Alarm”. Unreported Alarm: If IP Receiver is not connected with CMS, all the alarms are stored in the database of IP Receiver as unreported alarms.
Page 29
Figure 9 alarms (Reported), number of unreported alarms (Unreported) and two IP addresses (IP1 and IP2) of the two network ports on IP Receiver for connecting IP devices. Press ▲ and ▼ to turn the page up and down; Figure 10 Press ►, ◄...
Page 30
Honeywell The screen displays “Scanning” after a while the front panel and motherboard are not linked by a serial port cable (in 1 minute). Figure 11 Shut down Turn off the switch on the rear panel (No.12 in Figure 2-2). It costs about 15 seconds to end the programs before displaying “Shutting down…”.
5 Network Operations Initialization If IP Receiver is to be connected to a router, you must assign a static IP address that is not occupied by other device for IP Receiver, and you can assign at most 2 IP addresses. After...
Honeywell Login When IP Receiver and your PC belong to the same subnet, input the IP address of IP Receiver in Internet Explorer (IE) on your PC to login into IP Receiver. If the PC is connected to the internet and IP Receiver is connected to...
Honeywell Configuration After you log in the system, you can see the following page. The system includes three functional tabs, which are Configuration, Search, and Reports. On the top-right corner of the page, you can select “Change password” or “Log out”, below which is the current version.
Honeywell Search Click the Search tab to enter the Search page Figure 5-6 Search In the left pane there lists 6 search ways: by account, by time, by IP address, by CID, combination search, and advanced search. Among them “Advanced search” supports the SQL query sentences and “Combination search”...
Honeywell Each page can display at most 20 records. To browse through the pages click Next or Last. Export Result Records Click Export on the “Report” result page (see Figure 5-7) and you can export the latest 5000 records that you searched to the Excel file. If the result records are less than 5000, all the records you have searched are exported to the XLS file in which the records are arranged in reverse chronological order.
Honeywell Error information is displayed if the current password entered is Note incorrect or the new password and confirm password do not match. Logout Click “Log out” on the top-right corner of the page can log out the system and return to the...
6 Network Structure of IP Receiver and Configuration on Router Alarms from WAN devices are transmitted to the IP Receiver that is connected to the LAN by router, so it’s a must to configure router to assure the safe and effective alarm report of IP Receiver (refer to the following configuration steps that are performed on a BELKIN router).
Page 38
Honeywell Figure 6-2 Virtual Servers Setting Security setting: Security setting is very important for receiving alarms via network. • Block the Ping packets from the WAN port to avoid malicious detection. • Enable the function of anti network attack to prevent DOS attack.
Page 39
Honeywell Ignore the Ping packets from WAN port: Figure 6-3 WAN Ping Blocking The configuration for filters: Figure 6-4 Client IP Filters Lastly set a strong password for the router (minimum of 15 characters in length, composed of letters, numbers, and special characters).
