Figure 1-5 (A) Pcb Location (B) Dip Switch Location (C) Dip Switch Example - Honeywell Acuix IP Series Installation Manual

ACUIX IP Rugged Housing and Dome
A
Printed circuit board location
(PCB) on top of the scan assembly
B
DIP Switch Location on the
PCB
C
Example of a DIP Switch
Setting
ON
OFF
18
Figure 1-5 (A) PCB Location (B) DIP Switch Location (C) DIP Switch Example
Positions 1, 2, 4, 6, and 7 set to OFF
Scan assembly
(including camera)
Positions 3, 5, and 8 set to ON
SW5 Baud rate
and parity
SW6 IntelliBus
protocol
