PART NAMES

INDOOR UNIT
12
AH-PN10, AH-PN10-GY
AH-PN13, AH-PN13-GY
OUTDOOR UNIT
AU-PN10
AU-PN13
AU-L10
AU-L13
OM_AH-PN10 13GY_EN.indd Sec1:2 OM_AH-PN10 13GY_EN.indd Sec1:2
9
10
11
AH-L10
AH-L13
E-2
1 1 Inlet (Air)
2
2 Open Panel
3
3 Air Filter
4 4 AUX Button
5 Receiver Window
5
6
6 Vertical Airflow Louvre
7 Horizontal Airflow Louvre
7
8 8 Outlet (Air)
9
9 OPERATION Lamp (red
10
10 TIMER Lamp (orange
11
11 POWERFUL JET Lamp
(green )
12 PLASMACLUSTER Lamp
(blue )
13
13 Inlet (Air)
14
14 Refrigerant Pipe and
Interconnecting Cord
15
15 Drainage Hose
16 Outlet (Air)
16
NOTE:
Actual units might vary slightly
from those shown above.
)
)
