PART NAMES (UNIT)

INDOOR UNIT
Indoor unit apperance may be different from the image above.
※
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 Receiver Window
5 Vertical Airflow Louver
6 Horizontal Airflow Louver
7 Outlet (Air)
8 OPERATION Lamp (green )
9 TIMER Lamp (orange )
10 ERROR Lamp
(For AH-X10/13/15/18/20 series: green,
For AH-X24/25 series: blue)
B129_EN.indd 2
The position of ON/OFF button:
1
2
(For AH-X10 series)
3
4
5
6
7
8
9
(For AH-X13/15/18/20 series)
10
(For AH-X24/25 series)
EN-2
