3 . 9 D i a g n o s t i c
3 . 9 D i a g n o s t i c
Diagnostic Tools provide a useful way to view or diagnose the status of your Vigor modem.
Below shows the menu items for Diagnostics.
3 . 9 . 1 D i a l - o u t
3 . 9 . 1 D i a l - o u t
Click Diagnostics and click Dial-out Trigger to open the web page. The internet connection
(e.g., PPPoE, PPPoA, etc) is triggered by a package sending from the source IP address.
Available settings are explained as follows:
Item
Decoded Format
Refresh
Vigor130 Series User's Guide
s
s
T r i g g e r i n g
T r i g g e r i n g
Description
It shows the source IP address (local), destination IP
(remote) address, the protocol and length of the package.
Click it to reload the page.
122
