Summary of Contents for Makita UH4261
- Page 1 Инструкция Makita UH5261 Перейти в карточку товара 8 800 775 98 98...
-
Page 2: Specification
UH4261/ UH4861/ UH5261 Description Hedge Trimmers 420mm/ 480mm/ 520mm ONCEPT AND MAIN APPLICATIONS UH4261/ UH4861/ UH5261 are new series Hedge trimmers for entry users, featuring compact and lightweight design for more improved handling. Their specifications are the same as UH4260 series models, except a minor structural change of Front switch. -
Page 3: Necessary Repairing Tools
Removing Bearing box complete [2] LUBRICATION Apply Makita grease N. No.2 to the following portion to protect parts and product from unusual abrasion. (1) Gear room (5g: Refer to Fig. 6.) (2) Crank portion of Shear blade complete (2g: Refer to Fig. 8) (3) Contact portion of Spindle bottom end and Plan bearing 8 (a little: Refer to Fig.8) - Page 4 P 3/ 7 epair [3] DISASSEMBLY/ASSEMBLY [3] -1. Shear blade complete and Front grip (cont.) ASSEMBLING Take the disassembling step in reverse. Note: • Be sure to set Flat washer 8 and Nylon sleeve 5 in place. (Figs. 7 and 8) •...
- Page 5 P 4/ 7 epair [3] DISASSEMBLY/ASSEMBLY [3] -3. Armature and Switch DISASSEMBLING (1) Remove Shear blade complete and Helical gear 67. (Refer to pervious pages.) (2) Switches, Switch lever A / C and Switch arm can be removed. (Fig. 15) (3) Remove Brush holders, and then separate Armature with Bearing box complete from Housing L.
- Page 6 P 5/ 7 epair [3] DISASSEMBLY/ASSEMBLY [3] -5. Switch lever B DISASSEMBLING Disassemble Switch lever B from Front grip by removing Tabs of Switch lever B one by one with Slotted screwdriver. (Fig.19) Fig. 19 Slotted screwdriver 3. Tab of Switch lever B Compression spring 5 1.
-
Page 7: Circuit Diagram
P 6/ 7 ircuit diagram Fig. D-1A 220 - 240V For the Market where the Radio interference suppression is required. Color index of lead wires' sheath Black Yellow White Orange Purple Choke coil Terminal block Field Switch A Noise Power supply suppressor cord Switch A: Switch operated with Switch lever A in Main grip... -
Page 8: Wiring Diagram
P 7/ 7 ircuit diagram Fig. D-1C For the Market where the Radio interference suppression is not required. Color index of lead wires' sheath Black Yellow White Orange Terminal block Field Switch A Power supply cord Switch A: Switch operated with Switch lever A in Main grip Switch B: Switch operated with Switch lever B in Front grip Switch B iring diagram... - Page 9 Makita UH5261 Описание Характеристики...
