Honeywell HD70P Specifications

HD70P
SUPER HIGH RESOLUTION 600 TVL FIXED LENS DAY/NIGHT
VANDAL DOME CAMERA WITH INFRARED ILLUMINATORS
The Performance Series rounds out Honeywell's camera portfolio with a variety of
indoor, outdoor and low light cameras that lets end users pick the perfect camera
for virtually any installation. Ideal for a diverse range of applications, the
Performance Series includes a wide range of high performing IR bullet cameras
and mini-domes that are easy to install and even easier to use.
The HD70P is a day/night camera that switches from color to black and white
mode depending upon available light. The HD70P incorporates a 1/3" CCD that
offers 600 TV lines of crisp, clear horizontal resolution. The HD70P utilizes smart
infrared technology. Auto LED brightness adjustment provides even distribution of
the IR, eliminating excessive illumination and washed out video. The camera
comes equipped with 24 integrated LEDs, a built-in fixed, IR corrected lens (f=3.8
mm) and a 3-D axis gimbal that is capable of 360° of pan, 180° of tilt and 360° of
horizontal rotation. In addition, the lens is separated from the LEDs by a boot
mechanism which eliminates internal IR glare.
The built-in breather vent effectively stops all humidity buildup to eliminate weather-
related issues, loss of critical video, or possibly having to replace the camera.
The HD70P installs quickly and easily. It comes standard with a two-conductor pigtail
that connects to the barrel connector so there is no need to cut wires during
installation. It also features a video out port for easy focus. The HD70P is designed for
use in challenging environments. It is IP66 rated for outdoor installations, but can also
be installed indoors, mounted directly to a ceiling or wall.
Market Opportunities
The HD70P is a cost effective surveillance solution for applications that experience
changing light conditions throughout the day. The HD70P offers a simple yet solid
design that provides optimum performance for both indoor and outdoor
applications including lobbies, atriums, vestibules, gated entrances, foyers, loading
docks and driveways.
Features
• 1/3" Interline Transfer CCD
• Super high resolution color:
600 TV lines
• Day/night with 24 LEDs
• Built-in fixed lens (f=3.8 mm)
• Digital Noise Reduction technology
for noise free images
• Smart IR for even distribution of the
IR to prevent excessive illumination
• Privacy zone, mirror function
• User-friendly design for easy access
and adjustment of camera settings
• Built-in breather vent stops
humidity buildup
• Vandal-proof and weather resistant
housing: IP66 rating
• Total effectiveness in zero
lux environments
• IR LED visible range of 50 ft. (15 m),
depending on scene reflectivity
• 3-D axis gimbal
• Video out port for setup
• Two-conductor pigtail is standard for
connection to barrel connector
• 12 VDC input
www.honeywellvideo.com
