VHF FM REPEATER
TKR-750
SERVICE MANUAL
REVISED II
This service manual applies to products 60700001 or subsequent serial number.
In terms of the products with the serial numbers earlier than 60700001, refer to the TKR-750 service manual as per part number
B51-8556-10 and B51-8661-00.
VHF FM REPEATER TKR-750
Antenna cable (N)
(E30-3419-05)
D-sub cable assy
(E37-0904-05)
TEST/SPKR connector assy
(E37-0913-05)
GENERAL ................................................................. 2
SYSTEM SET-UP ..................................................... 2
Realignment ........................................................ 4
Installation ........................................................ 5
Modification ....................................................... 8
Parts List ............................................................ 22
Exploded View .................................................. 34
Packing ................................................................ 36
Adjustment ....................................................... 37
Front panel
(A62-0934-03)
Fuse (Blade, 15A/32V)
Key top
(F05-1537-05) x 2
(K29-5460-02)
Antenna cable (BNC)
(E30-3418-05)
DC cord (Ext DC in)
(E30-3414-05)
DC backup terminal
(E70-0402-05)
CONTENTS
© 2004-10 PRINTED IN JAPAN
B51-8556-20 ( N ) 1219
Knob (Volume)
(K29-5389-03)
Modular jack
(E08-0877-05)
SCHEMATIC DIAGRAM ........................................ 70
Block Diagram .................................................. 83
Knob (DC source)
(K29-9106-04)
