Tripp Lite PDUMH20HVNET Specifications

Single-Phase Switched PDU, 3.2-3.8kW 16/20A
200-240V, 1U Horizontal Rackmount, 8 C13 outlets,
C20 inlet with L6-20P and C20 cables
MODEL NUMBER: PDUMH20HVNET
Description
Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and monitoring
with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle, monitor site electrical
conditions and remotely monitor output power consumption. PowerAlert interface supports remote control and
custom notification of user-specified conditions via email, secure web, SNMP, Telnet or SSH interface.
Individually switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined
power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is
first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in
amps is continuously displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before critical IT mains or branch
breakers trip.
Features
16/20A 200/208/230/240V Switched Power Distribution Unit / PDU with built-in web/network interface (Agency derated to 16A continuous)
C20 inlet; 8.5 ft. / 2.6m C20 power cable with L6-20P plug adapter
8 switched C13 outlets
1U horizontal rackmount form factor
Supports power-on, power-off or reboot of each outlet on a real-time or programmable basis
Enables reboot of locked equipment, custom power-on/power-off sequences, load-shedding of optional loads and disabling unused outlets
Network interface provides PDU control and data regarding input voltage, frequency and loading information
Digital display reports load level information in amps
Supports user-specified alarm notification thresholds
In-rack environmental reporting with optional ENVIROSENSE temperature / humidity sensor and rack access notification with up to 4 optional SRSWITCH
door sensors
DHCP/Manual configuration support
10/100 Mbps auto-sensing
1 / 4
Highlights
Switched 16/20A 200-240V PDU,
1U Horizontal Rackmount format
Reports voltage, frequency &
loading information via ethernet
interface
Visual current meter, reversible
housing
C20 inlet; 8.5ft / 2.6m C20 input
cable with L6-20P adapter
8 C13 switched outlets with cord
retention brackets
Temperature, humidity and
contact-closure monitoring
options
Applications
Ideal for power distribution in
datacenters, computer rooms
and network closets
Package Includes
Rackmount PDU
Rack mounting brackets
