Removing and Replacing Components

Removing the Power Supply from the Server

Replacing a Power Supply
To replace a power supply, follow these steps
1. Remove the front bezel from the server and remove the defective power supply if you have
not already done so.
2. Open the power supply release lever and slide the power supply into place.

Sliding the Power Supply into Place

3. Push in on the power supply release lever to lock the retaining clip in place.
4. Replace the front bezel.

Hard Drives

The zx6000 and rx2600 servers can support up to three hot-pluggable, Low-Voltage Differential
(LVD) hard disk drives. These hard disk drives are 3.5-inch form factor, 10K and 15K RPM
devices that connect to Ultra 320 Wide LVD (Low Voltage Differential) SCSI interfaces on the
disk bay backplane.
There is a significant difference between the terms hot-pluggable and hot swappable:
■
Hot swapping happens at the device level; that is, a hot-swappable device manages insertion
or removal on its own without assistance from operating system commands.
74 HP Integrity rx2600 server and HP workstation zx6000 Operation and Maintenance Guide
