Page 1: Gas Oven
GAS OVEN EINBAU GAS- BACKOFEN ZBG 331 INSTRUCTION BOOKLET BEDIENUNGSANLEITUNG... -
Page 2: Important Safety Information
Important Safety Information These warnings are provided in the interest of your safety. You MUST read them carefully before installing or using the appliance. Installation • Ensure that all control knobs are in the OFF position when • This oven must be installed by qualified personnel in not in use. -
Page 3: Table Of Contents
Contents For the User For the Installer Important Safety Information Instructions for the Installer Description of the Appliance Important Safety Requirements Controls Building in Before the First Use Electrical Connection Using the Oven Gas connection Using the Traditional Gas Oven Adaptation to different types of gas Grilling Cleaning the Oven... -
Page 4: Description Of The Appliance
Description of the Appliance 1. Control panel 2. Minute minder 3. Light and Grill control knob 4. Gas oven control knob 5. Grill control light 6. Mains on light 7. Grill 8. Oven lamp 9. Rating plate 10. Oven cavity bottom plate Controls Control Knob for the Oven Light and the Electric Grill... -
Page 5: Cooling Fan
Grill Control Light The Grill (thermostat) control light will come on when the thermostat control knob is turned. The light will remain on until the correct temperature is reached. It will then cycle on and off to show the temperature is being maintained. Gas Oven Control Knob Oven burner off 150 - 240... -
Page 6: Using The Oven
Using the Oven Always cook with the oven door closed. The oven is supplied with an exclusive system which produces a natural circulation of air and the constant recycling of steam. This system makes it possible to cook in a steamy environment and keep the dishes soft inside and crusty outside. -
Page 7: Using The Traditional Gas Oven
Using the Traditional Gas Oven Cooking times in the tables do not include pre- During cooking, the door should be opened as little heating. We recommend to pre-heat the oven for as possible to avoid heat loss, and excessive fuel about 10 minutes before cooking. -
Page 8: Grilling
Grilling Hints and Tips Grilling must be carried out with the oven door closed. Most foods should be placed on the grid in the grill pan to allow maximum circulation of air to lift the How to Use the Grill food out of the fats and juices. -
Page 9: Cleaning The Oven
Cleaning the Oven Before cleaning always allow the cooling fan to cool the oven down before switching off at the electricity supply. This appliance cannot be cleaned with steam or with a steam cleaning machine. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. -
Page 10: Replacing The Oven Light
Oven Cavity The enamelled oven cavity is best cleaned whilst the oven is still warm. Wipe the oven over with a soft cloth soaked in warm soapy water after each use. From time to time it will be necessary to do a more thorough cleaning, using a proprietary oven cleaner. -
Page 11: Something Not Working
Something Not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 12: Instructions For The Installer
Instructions for the Installer Cabinet Dimensions Technical Data APPLIANCE GAS SUPPLY: Natural Gas G20 - 20 mbar Minimum aperture height 580 mm APPLIANCE CATEGORY:II2H3B/P Minimum aperture depth 550 mm Minimum aperture width 560 mm Oven Oven burner 2700 W (Natural gas G20) Dimensions of the oven cavity 2500 W (Liquid gas G30/G31) Electric Grill Element... -
Page 13: Securing The Oven To The Cabinet
Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. BUILDING IN The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant diagrams;... -
Page 14: Electrical Connection
Electrical Connection The instructions given below are designed specifically for a qualified installer and should aid him or her to perform all installation, adjustment, and maintenance operations with absolute precision and in compliance with all current legislation and regulations. We strongly recommend that all operations for the installation of your cooker be carryed out by Qualified Personnel in accordance with... -
Page 15: Gas Connection
Gas connection Connecting the appliance to the View flexible from metallic pipe gas supply above gasket The gas supply connection ramp is located in the upper side of the oven, right behind the control panel. To carry out the gas connection: 1. -
Page 16: Adaptation To Different Types Of Gas
