OVEN AND ACCESSORIES

OVEN
1
12
11
16
3
2
9
10
13
17
18
19
20
2
1 Door
4
2 Door hinges
3 Grill heating element
5
4 Oven lamp
5 Waveguide cover
6
6 Control panel
7 Seal packing
7
8 Door lock openings
9 Oven cavity
8
10 Door seals and sealing surfaces
11 Door safety latches
12 Door open handle
13 Ventilation openings
14
14 Outer cabinet
15 Rear cabinet
16 Power supply cord
15
ACCESSORIES:
Check to make sure the following accessories are
provided:
(17) Turntable (18) Roller stay (19) Seal packing
(20) Rack
Place the roller stay in the seal packing on the floor of
the cavity.
Then place the turntable on the roller stay.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
