Page 1: Washing Machine
FULLY AUTOMATIC ELECTRONIC WASHING MACHINE USER MANUAL BEFORE USING THE WASHING MACHINE, YOU SHOULD CERTAINLY READ THE INFORMATION IN USER’S MANUAL. -
Page 2: Table Of Contents
CONTENTS CHAPTER-1: TECHNICAL SPECIFICATIONS CHAPTER-2: BEFORE USING WASHING MACHINE Safety warnings Recommendations CHAPTER-3: SETTING UP ..Removing transport safety screws Adjusting feet for balance Electrical connection Water inlet connection Water discharge connection CHAPTER-4: PRELIMINARY PREPARATION FOR LAUNDERING CHAPTER-5: CONTROL PANEL Detergent drawer Programme knob Electronic display... -
Page 3: Chapter-1: Technical Specifications
CHAPTER -1: TECHNICAL SPECIFICATIONS 1.Detergent drawer 2.Upper tray 3.Programme knob 4.Electronic display 5.Door 6.Cover of pump filter 7.Transport safety screw 8.Power cable 9.Discharging hose 10.Water inlet valve... - Page 4 CHAPTER -1: TECHNICAL SPECIFICATIONS Operating voltage / frequency (220-240) V ~/50Hz (V/Hz) Total current (A) Maximum: 1 Mpa Water pressure (Mpa) Minimum: 0.1 MPa 2200 Total power (W) Maximum dry laundry capacity (kg) 1000 Spinning revolution (rev / min) Programme number Dimensions 845 x 597 x 582 (Height x Width x Depth) (mm)
-
Page 5: Chapter-2: Before Using Washing Machine
CHAPTER -2: BEFORE USING YOUR WASHING MACHINE SAFETY WARNINGS Do not use a multiple socket or extension cord. Do not insert a plug with damaged or broken cord into the socket. If the cord is damaged it should be replaced by the manufacturer or appointed service agent in order to avoid a hazard. -
Page 6: Recommendations
CHAPTER -2: BEFORE USING YOUR WASHING MACHINE RECOMMENDATIONS The detergent or softener in contact with air for a long time will dry and stick to your detergent drawer. To avoid this put your detergent and softener into the detergent drawer just before washing. -
Page 7: Chapter-3: Setting Up
CHAPTER -3: SETTING UP REMOVING TRANSPORT SAFETY SCREWS As a result of manufacturing quality control procedures, a certain amount of water may remain in your machine, this is normal and not harmful. You must pay attention to the following issues before using your washing machine. - Page 8 CHAPTER -3: SETTING UP REMOVING TRANSPORT SAFETY SCREWS Remove the screws by pulling them. To the holes where the transport screws have been removed, insert the plastic transport screw taps found in the accessories bag. The transportation screws that have been removed should be kept for future use if the machine needs to be transported elsewhere.
-
Page 9: Adjusting Feet For Balance
CHAPTER -3 SETTING UP ADJUSTING FEET FOR BALANCE Do not install your machine on rugs or similar surfaces. For your machine to work silently and without any vibration, it should be positioned on a flat, non-slippery and durable floor. You can adjust the feet of your machine to stabilise the balance. -
Page 10: Electrical Connection
CHAPTER -3: SETTING UP ELECTRICAL CONNECTION / WATER SUPPLY CONNECTION ELECTRICAL CONNECTION Your washing machine works with 220-240V and 50Hz. An earthed plug has been attached to the power cable of your washing machine. It is essential to connect this plug to an earthed 10 ampere socket. - Page 11 CHAPTER -3: SETTING UP WATER DRAIN CONNECTION WATER DRAIN CONNECTION Be sure that water inlet hoses are not folded, twisted, crushed or elongated by stretching. Water drain hose should be mounted at a height of minimum 60 cm, maximum 100 cm from the ground. The end of the water drain hose may directly be fitted to the dirty water outlet hole or a special apparatus mounted on the outlet bracket of the wash-stand.
-
Page 12: Chapter-4: Preliminary Preparation For Laundering
CHAPTER-4:PRELIMINARY PREPARATION FOR LAUNDERING SEPARATING LAUNDRY Sort your clothes according to their types (cotton, synthetic, sensitive, woollen, etc.),washing temperatures and level of dirtiness. Never wash your white and coloured clothes together. Since your new coloured clothes may shed dye on the first wash, wash them separately. - Page 13 CHAPTER-4:PRELIMINARY PREPARATION FOR LAUNDERING SEPARATING LAUNDRY Ironing No whitening Whitening temperature is available maximum 110°C Ironing Ironing temperature is temperature is No ironing maximum 150°C maximum 200°C No dry cleaning Dry cleaning Leave on a flat available place Drying by twirling Hang when wet Dry by hanging is not allowed...
- Page 14 CHAPTER-4: PUTTING LAUNDRY IN THE MACHINE Open the door of your machine. Load clothes into the machine evenly. Load each item separately. When you shut the door of your machine, be careful that no cloth is jammed between the cover and the gasket. Shut the door of your machine tightly otherwise your machine will not start the washing process.
- Page 15 CHAPTER-4: ADDING DETERGENT INTO MACHINE The quantity of the detergent that you will put in your machine depends on the following criteria: Your detergent consumption will change according to the dirtiness of your clothes. For slightly dirty clothes, do not pre-wash and put a small amount of detergent in the compartment no.2 of the detergent drawer.
-
Page 16: Chapter-5: Control Panel
CHAPTER 5: CONTROL PANEL... -
Page 17: Detergent Drawer
CHAPTER 5: CONTROL PANEL DETERGENT DRAWER A. Prewashing compartment B. Main washing compartment C. Softener compartment D. Siphon cover E. Liquid level detergent plate... -
Page 18: Programme Knob
CHAPTER 5: CONTROL PANEL PROGRAMME KNOB You may select the programme you like to wash your Laundry through programme knob. You may set the programme selection operation by rotating the programme knob in both direction. Ensure that the programme knob is exactly on the programme you want to select. -
Page 19: Electronic Display
CHAPTER 5: CONTROL PANEL ELECTRONIC DISPLAY 1-Adjusting button for revolution speed 2-Adjusting button for temperature of washing water 3-Auxiliary function prewash 4-Auxiliary function for rapid wash 5-Auxiliary function for easy ironing 6-Auxiliary function for delay timer 7-Start/Pause button 8-Electronic display On the electronic display, you may view washing water temperature, spinning revolution speed of your machine, the amount time your machine will continue washing, the auxiliary functions you have... -
Page 20: Chapter-6: Operating Your Machine
CHAPTER 6: OPERATING YOUR MACHINE Plug your machine in. Open the water tap. Open the machine door. Spread your Laundry in your machine. Push the door of your machine until hearing the locking sound to close it. Put detergent and softener in the detergent drawer. First washing operation Some water may be left in your machine due to experiments and tests carried out during production. - Page 21 CHAPTER 6: OPERATING YOUR MACHINE Half-load detection system Your machine features a half-load detection system. In case you put approximately half or less amount of Laundry of maximum laundry capacity in your machine, your machine will run so as to save washing time, water consumption and energy in some programmes (White cotton 95°, Colourfast cotton 60°, Non colourfast cotton 40°).
- Page 22 CHAPTER 6: OPERATING YOUR MACHINE PROGRAM TABLE MAXIMUM AMOUNT OF TEMPERATURE DETERGENT PROGRAMME LAUNDRY TYPE (°C) COMPARTMENT LAUNDRY (kg) Very dirty cotton and flax textiles. (Underwears, linen, tablecloth, towel (maximum 1- COTTON 4,5 kg), bedclothes, etc. Dirty cotton and flax textiles. (Underwears, linen, tablecloth, towel (maximum 4,5 2- COTTON ECO kg), bedclothes, etc.
- Page 23 CHAPTER 6: OPERATING YOUR MACHINE PROGRAM TABLE Total Total Energy PROGRAMME LAUNDRY TYPE Total Water Max. Time Consumption Consumption T(°C) (min) (kwH) Very dirty cotton and flax textiles. (Underwears, linen, tablecloth, towel (maximum 1- COTTON 95 C 2,69 4,5 kg), bedclothes, etc. Dirty cotton and flax textiles.
- Page 24 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 1-Revolution speed selection and auxiliary function of soaking You can set the spinning revolution for your Laundry via revolution speed setting button. When you select a new programme, the maximum spinning revolution speed of the programme you have selected will be viewed on the display of revolution speed.
- Page 25 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS If this function is selected, your Laundry will be soaked in the latest rinsing water. When your machine soaks your Laundry in the latest rinsing water, symbol will blink on electronic display. If you want to take your Laundry out, press on “Start / Pause” button. Your machine will empty the water in it and finish the programme without spinning.
- Page 26 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 2-Washing water temperature selection You can select the washing water temperature with the washing water temperature adjustment button. Whenever you select a new programme, the maximum washing water temperature is shown on the washing water temperature display.
- Page 27 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 4-Auxiliary function for rapid wash This auxiliary function will enable the washing duration of your Laundry that are not very dirty to be shortened. In case you put half of or less than half of the laundry capacity of the washing programme you have selected in your machine, your machine will...
- Page 28 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 6-Auxiliary function for delay timer By using this auxiliary function, you can let your machine start washing after half an hour to 23 hours. To use auxiliary function of delay timer: - Press time delay button once. - Expression of “0.5h”...
- Page 29 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 7-Anti-Allergic auxiliary function In the programmes where this auxiliary function is active, your machine will perform an extra rinsing operation on your Laundry prior to latest rinsing operation. Note: Anti-Allergic auxiliary function is selected automatically only in Baby wear programme.
-
Page 30: Starting The Programme
CHAPTER 6: OPERATING YOUR MACHINE STARTING THE PROGRAMME Start/Pause button By pressing on Start/Pause button, you may start the programme you have selected, suspend a running programme. If you switch your machine to pause mode, electronic display will blink. When you start your machine, the following symbols for the programmes you have selected will be available on electronic display. -
Page 31: Adding/Removing Laundry
CHAPTER 6: OPERATING YOUR MACHINE ADDING/REMOVING LAUNDRY Laundry adding to / removing from the machine -If you want to add or remove Laundry when your machine is running, switch your machine to Pause mode by pressing Start/Pause button. - When you Pause the machine, the Open Door symbol will flash and you can open the door to either add or remove laundry. -
Page 32: Child Lock
CHAPTER 6: OPERATING YOUR MACHINE CHILD LOCK Child lock To avoid the cycle being altered if any programme knobs are pressed or turned when a programme has started, the Child Lock may be set. Child lock is an auxiliary function which can be activated by pressing and holding Quick Wash and Wrinkle Removing functions together for 3 seconds. -
Page 33: Cancelling Programme
CHAPTER 6: OPERATING YOUR MACHINE CANCELLING PROGRAMME Cancelling programme If you want to cancel any programme running: - Switch the programme knob to 0. - Your machine will stop the washing operation and the programme will be cancelled. - To get rid of the water accumulated in the machine switch the programme knob to any programme. -
Page 34: Finishing Programme
CHAPTER 6: OPERATING YOUR MACHINE FINISHING PROGRAMME Finishing programme - Your machine will stop by itself as soon as the programme you have selected finishes. -Expression of “END” will flash on the electronic display. Note: Within 2 minutes after the programme has finished, your machine will extinguish the electronic display to save energy. -
Page 35: Chapter-7: Electronic Display Warning Symbols
CHAPTER -7: ELECTRONIC DISPLAY WARNING SYMBOLS WARNING OF WATER CUT-OFF / LOW MAINS WATER PRESSURE If symbol flashes on the electronic display: - Water tap may be closed. Check. - Mains water may be cut-off. Check. If so, switch the programme knob to position 0. -
Page 36: Warning Of Clogged Pump Fitler
CHAPTER -7: ELECTRONIC DISPLAY WARNING SYMBOLS WARNING OF CLOGGED PUMP FILTER If symbol flashes on the electronic display: - Pump filter may be clogged. Clean the pump filter. (*) - Discharging hose may be clogged or twisted. Check the discharging hose. -
Page 37: Chapter-8: Maintenance And Cleaning Of Your Machine
CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE Unplug your machine. Close the water tap. WATER INLET FILTERS On the tap part of your machine’s water inlet hose and at the ends of water inlet valves, there are filters to prevent dirt and foreign materials in the water entering the machine. - Page 38 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / PUMP FILTER The pump filter system elongates the life of your pump, which is used to drain the dirty water. It prevents lint entering the pump. Cleaning the pump filter every 2-3 months is recommended. To clean the pump: Open the kickplate’s cover, by pulling the handle.
- Page 39 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / PUMP FILTER WARNING! Danger of being scalded! Since the water inside the pump maybe hot, wait for it to cool.
- Page 40 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / DETERGENT DRAWER Detergents may form a sediment in your detergent drawer or in the housing of the detergent drawer over time. To clean this sediment, you must remove the detergent drawer.To pull out the detergentdrawer: Pull the detergent drawer to the end.(DIAGRAM-1) Press the blue siphon plug in the drawer, and continue to pull the drawer until it is removed.(DIAGRAM-2)
- Page 41 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / SIPHON PLUG / CABINET / DRUM Siphon plug Pull out the detergent drawer. Remove the siphon plug and clean the residues of the softener thoroughly. Fit the cleaned siphon plug in its location.
-
Page 42: Chapter-9: Practical Information
CHAPTER -9: PRACTICAL INFORMATION (Take care to ensure the type of fabric being treated is considered) Alcoholic beverages: The stain point, should first be washed with cold water, then should be wiped with glycerine and water and be rinsed with water mixed with vinegar. Shoe Polish: The stain should be slightly scratched without ruining the cloth, rubbed with detergent and rinsed. - Page 43 CHAPTER -9: PRACTICAL INFORMATION Blood stain: Lay your clothes in cold water for 30 minutes. If the stain still does not disappear,lay in mixture of water and ammonia (3 table-spoons of ammonia in 4 litres of water)for 30 minutes. Cream, ice-cream and milk: Lay your clothes in cold water and rub the stained area with detergent.
-
Page 44: Chapter-10: Troubleshooting
CHAPTER -10: TROUBLESHOOTING All repairs which must be done on the machine should be done by authorised agents only. When a repair is required for your machine or you are unable to eliminate the failure with the help of the information given below: Unplug the machine. - Page 45 CHAPTER -10: TROUBLESHOOTING METHODS OF PROBABLE CAUSE FAILURE ELIMINATION Water tap is closed. Open water tap. The water inlet hose Check the water inlet may be bent. hose. The water inlet hose is Clean the filters of Your machine does not obstructed.
- Page 46 CHAPTER -10: TROUBLESHOOTING METHODS OF PROBABLE FAILURE ELIMINATION CAUSE There is a small It does not prevent amount of clothes in operation of the the device. machine. Excessive amount of Your machine is Do not exceed the clothes are filled in vibrating.
- Page 47 CHAPTER -10: TROUBLESHOOTING METHODS OF PROBABLE FAILURE ELIMINATION CAUSE Clothes exceeding the maximum capacity has been Lighten the load. filled in your machine. Use the amount of The washing result Your water may be detergent according to is bad. hard. the declaration of the detergent producer.
- Page 48 CHAPTER -10: TROUBLESHOOTING METHODS OF PROBABLE CAUSE FAILURE ELIMINATION The load control system will automatically attempt to balance the load before a spin cycle No failure. The starts. The spinning unbalanced load It is important when process is not done control works in that loading the machine or starts with delay .
-
Page 49: Chapter-11: Automatic Fault Warnings And How To Correct Them
CHAPTER -11: AUTOMATIC FAULT WARNINGS AND HOW TO CORRECT THEM Your machine is equipped with the systems which are capable of both taking necessary precautions and warning you in case of any breakdown by means of continuous self-checking during washing operations. - Page 50 CHAPTER -11: AUTOMATIC FAULT WARNINGS AND HOW TO CORRECT THEM TROUBLE CODE POSSIBLE WHAT TO DO FAULT - Water tap may be closed. Check. - Mains water may be cut-off. Check. - If so, switch the programme knob to position 0. You can select a programme and run your machine after the mains water is supplied.
-
Page 51: Chapter-12: Describing And Saving Energy
CHAPTER -12: DESCRIBING SAVING ENERGY Energy and water consumption may vary based on water pressure, water hardness, water temperature, ambient temperature, laundry amount, additional function selection, voltage fluctuations. It will reduce energy and water consumption to use your machine with the laundry capacity proposed for the selected programme, wash your Laundry less dirty or daily Laundry in short programmes, carry out cleaning and maintenance periodically, use your machine in convenient time intervals specified by electricity vendor. -
Page 52: Disposal Of Your Old Machine
DISPOSAL OF YOUR OLD MACHINE This symbol on the product or package implies that the product should not be treated as domestic waste. Instead, it should be delivered to applicable waste collection places recycling electrical and electronic equipment. You will contribute to avoid potential negative results regarding environment and human health, which will arise due to wrong waste procedure for the product by ensuring that this product is...
