- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg WHT814LSIT cerca il tuo prodotto tra le migliori offerte di Lavatrici e Asciugatrici WHT814LSIT Lavatrice Manuale utente Washing Machine User’s Manual Numero del documento 2820524249_IT/ 10-09-14.(11:13)
-
Page 2: General Safety Instructions
General safety instructions This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 Life and property safety Never place the product on a carpet-covered floor. Electrical parts will get overheated since air cannot circulate from under the device. -
Page 3: Electrical Safety
store all detergents and additives in a safe place away from the reach of the children by closing the cover of the detergent container or sealing the detergent package. 1.3 Electrical safety If the product has a failure, it should not be operated unless it is repaired by the Authorized Service Agent. -
Page 4: Important Instructions For Environment
Important instructions for environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. -
Page 5: Technical Specifications
Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark SMEG Model name WHT814LSIT Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0.536... -
Page 6: Appropriate Installation Location
4.1 Installation • Apply to the nearest authorized service agent for the installation of your product. • Preparation of the location and electrical, tap water and waste water installations at the place of installation is under customer's responsibility. • Make sure that the water inlet and discharge hoses as well as the power cable are not folded, pinched or crushed while pushing the product into its place after installation or cleaning procedures. -
Page 7: Connecting Water Supply
4.1.4 Connecting water supply The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly. Attach a pressure reducing valve if water pressure is higher. -
Page 8: Adjusting The Feet
4.1.6 Adjusting the feet CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing and vibration problems. -
Page 9: Preparing Laundry For Washing
4.2 Preparation 4.2.1 Sorting the laundry * Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature. * Always obey the instructions given on the garment tags. 4.2.2 Preparing laundry for washing • Laundry items with metal attachments such as, underwired bras, belt buckles or metal buttons will damage the machine. -
Page 10: Using Detergent And Softener
4.2.6 Using detergent and softener When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's instructions written on the package and follow the dosages specified. Use measuring cup if available. The detergent drawer is composed of three compartments: –... - Page 11 If the product does not contain a liquid detergent cup: • Do not use liquid detergent for the prewash in a programme with prewash. • Liquid detergent stains your clothes when used with Delayed Start function. If you are going to use the Delayed Start function, do not use liquid detergent.
-
Page 12: Tips For Efficient Washing
4.2.7 Tips for efficient washing Clothes Light Colours and Black/Dark Delicates/ Colours Whites Colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature range temperature range based temperature range range based on soiling level: based on soiling level: cold -40 on soiling level: cold based on soiling 40-90 level: cold -30... -
Page 13: Operating The Product
4.3 Operating the product 4.3.1 Control panel 1 - Programme Selection knob 6 - On / Off button 2 - Spin speed adjustment button 7 - Start / Pause button 3 - Temperature Adjustment button 8 - End Time Setting button 4 - Display 9 - Auxiliary Function buttons 5 - Program Follow-up indicator... -
Page 14: Programme And Consumption Table
4.3.3 Programme and consumption table Auxiliary functions Selectable temperature Programme range °C 60** 0.54 1600 Cold-60 Cotone Eco 60** 0.34 1600 Cold-60 40** 0.34 1600 Cold-60 Antiallergico 2.60 1600 30-90 Camicie 1.29 • • • Cold-60 0.70 1000 • • Cold-40 Sport 0.55... -
Page 15: Programme Selection
Indicative values for Synthetics programmes (EN) Remaining Moisture Content Remaining Moisture Content (%) ** (%) ** ≤ 1000 rpm > 1000 rpm Synthetics 60 1.13 02:21 Synthetics 40 0.90 01:42 * You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur between the time shown on the display and the real washing time. - Page 16 • Cotone Eco (Cotton Economic) Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other programmes, it provides high energy and water savings. Actual water temperature may be different from the stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), programme time may automatically get shorter.
-
Page 17: Temperature Selection
CAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Permanent damage occurs in the machine. • Lingerie Use this programme to wash delicates such as underwears. If there is little amount of laundry, use a laundry net. -
Page 18: Auxiliary Function Selection
Spin Speed Adjustment button only serves for decreasing the spin speed. Rinse Hold option is indicated with “ı_ı” symbol and No Spin option is indicated with “_” symbol. If you are not going to unload your laundry immediately after the programme completes, you can use Rinse Hold function in order to prevent them from getting wrinkled when there is no water in the machine. -
Page 19: Time Display
• Prelavaggio (Prewash) A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water, detergent and time. • Quick Wash This function can be used in Cottons and Synthetics programmes. It decreases the washing times and also the number of rinsing steps for lightly soiled laundry. -
Page 20: Starting The Programme
Additional laundry may be loaded during the End Time countdown period. At the end of the countdown, End Time indicator turns off, washing cycle starts and the time of the selected programme appears on the display. When the End Time selection is completed, the time appears on the screen consists of end time plus the duration of the selected programme. -
Page 21: Child Lock
88:88 1888 Changing the programme selection after programme has started: The programme change is not allowed when the current programme is running. You can select the new programme after switching the current programme to pause mode. The selected program starts anew. Changing the auxiliary function, speed and temperature Depending on the step the programme has reached, you can cancel or activate the auxiliary functions. -
Page 22: End Of Programme
If you press On / Off button when the Child Lock is enabled, the programme will not be cancelled. You should cancel the Child Lock first. If you want to open the loading door after you have cancelled the programme but it is not possible to open the loading door since the water level in the machine is above the loading door opening, then turn the Programme Selection knob to Pump+Spin programme and discharge the water in the machine. -
Page 23: Maintenance And Cleaning
4.4 Maintenance and cleaning Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular intervals. 4.4.1 Cleaning the detergent drawer Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as shown below in order to prevent accumulation of powder detergent in time. -
Page 24: Draining Remaining Water And Cleaning The Pump Filter
4.4.5 Draining remaining water and cleaning the pump filter The filter system in your machine prevents solid items such as buttons, coins and fabric fibers clogging the pump impeller during discharge of washing water. Thus, the water will be discharged without any problem and the service life of the pump will extend. -
Page 25: Troubleshooting
Troubleshooting Problem Reason Solution Programme cannot be started or Washing machine has switched to self protection Š Press and hold On / Off button for 3 seconds. selected. mode due to a supply problem (line voltage, water (see. "Cancellation of program") pressure, etc.). - Page 26 Problem Reason Solution Programme time does not There might be unbalanced load in the machine. Š Automatic unbalanced load detection system countdown. (*) might be activated due to the unbalanced distribution of the laundry in the drum. Machine does not switch to There might be unbalanced load in the machine.
- Page 27 Problem Reason Solution Laundry became stiff after Insufficient amount of detergent is used. Š Using insufficient amount of detergent for the washing. (**) water hardness can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. Detergent is put in the wrong compartment.
