Panasonic CZ-01ESW11P Operation Manual

Packaged air conditioner schedule timer
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual

OPERATION MANUAL

PACKAGED AIR CONDITIONER

SCHEDULE TIMER

MOdel No.
CZ-01ESW11P
Before operating this set, please read these instructions completely

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CZ-01ESW11P

Summary of Contents for Panasonic CZ-01ESW11P

  • Page 1: Operation Manual

    OPERATION MANUAL PACKAGED AIR CONDITIONER SCHEDULE TIMER MOdel No. CZ-01ESW11P Before operating this set, please read these instructions completely...

  • Page 2: Features And Functions

    FEATURES AND FUNCTIONS I Operation controlled by programmed time Operating time and stopping time can be set to the See page minute by each day of the week. The operating and stopping patterns can also be set in schedule accord- 11–14.
  • Page 3 NAMES AND FUNCTIONS OF OPERATING SECTION (Fig. 1, 2) UNIFIED OPERATION BUTTON DISPLAY “ ” (PROGRAMMED AM PM TIME OF SYSTEM OFF) Press this button to perform the unified operation regardless of the No. of programmed Displays the time programmed to stop. time.

  • Page 4: Operation

    OPERATION Set the time to 5:30 p.m. CLOCK SETTING PRESENT TIME (Fig. 3) Press the TIMER ON BUTTON the moment the time signal of TV, radio, telephone, etc. is heard. The (Example) In case of setting Friday, 5:30 p.m. mark “ : ” flashes, and the clock starts.
  • Page 5 Press the PROGRAMMING Press the TIMER ON BUTTON, START BUTTON. Programming is and set the programmed time of available. system start 1. Each time you press The display “PROGRAM START” it, the next area to be set flashes. appears, and the display of days of Note) Set the other programmed time in the same procedure.
  • Page 6 Press the PROGRAMMING Press the PROGRAMMING START BUTTON, and finish the START BUTTON. The program program setting. setting is ready. The display “PROGRAM START” appears, Notes) ● Unless the button is pressed within 20 and the display of days of a week minutes, the display will automatically revert back to the original state.

  • Page 7: Manual Operation

    Change the Press the PROGRAMMING programmed START BUTTON. The program SET 1 OFF OFF time of MON TUE WED THU FRI SAT SUN setting is now finished. system OFF SET 2 CLOCK p 1 to 7:00 Notes) ● Unless the button is pressed within 20 p.m.

  • Page 8: Operation Control

    Notes) ● For current settings, contact your Panasonic dealer. ● To change settings, contact your Panasonic dealer. Do not change settings yourself. ERROR DIAGNOSING FUNCTION (Fig. 7) This schedule timer is provided with the malfunction diagnosing function.
  • Page 9 Matsushita Electric Industrial Co., Ltd. Web Site : http://www.panasonic.co.jp/global/ 3VA10582-6A EM01A045 (0110) HT...
