  • Page 1 Conserver ce mode d’emploi Bewahren Sie bitte diese Bedienungsanleitung auf. Conservate queste istruzioni Guarde estas instruções Φυλάξτε τις Οδηγίες αυτές Guarde estas instrucciones Сохраните эту инструкцию Збережіть ці інструкції CZ-ESWC2 INSTRUCTION MANUAL • Schedule Timer MODE D’EMPLOI • Temporisateur BEDIENUNGSANLEITUNG •...

  • Page 2: Table Of Contents

    Contents page Product Information ..................EN-2 Alert Symbols ....................EN-2 Installation Location ..................EN-3 Electrical Requirements.................EN-3 Safety Instructions ..................EN-3 Names and Functions of Parts ..............EN-4 Using the Schedule Timer ................EN-5 Setting the Present Time ...............EN-6 Setting Today’s Day of the Week ............EN-7 Setting Up Programmed Operations .............EN-8 Setting Errors ..................EN-10 How to Check Program Times .............EN-11 How to Copy Program Times ...............EN-12...

  • Page 3: Installation Location

    Installation Location • We recommend that this schedule timer be installed properly by qualifi ed installation technicians in accordance with the Installation Instructions provided with the schedule timer. • Do not install the schedule timer where there are fumes or fl...

  • Page 4: Names And Functions Of Parts

    Names and Functions of Parts Operating Buttons A: PROGRAM button E: HOLIDAY button B: PROG. COPY buttons F: CANCEL button C: CLEAR button G: TIMER OFF button D: Setting buttons A: PROGRAM button Use to start setting programs and to enter program settings. B: PROG.

  • Page 5: Using The Schedule Timer

    Display A B C A: Today’s day of the week Indicates today’s day of the week. B: Program schedule Appears under days that are scheduled for program operation. indication ( C: Holiday schedule indication Appears around scheduled holidays. (Refer to page EN-16) D: ERROR indication Displayed when a mistake is made during timer setting.

  • Page 6: Setting The Present Time

    Setting the Present Time Set the present time. (Example: When the present time is 12:45) STEP 1 Hold down the SET button and press the HH button to set the hour. • The hour increases one hour at a time with each single press of the HH button while the SET button is held down.

  • Page 7: Setting Today's Day Of The Week

    Setting Today’s Day of the Week Set today’s day of the week. (Example: When today is Wednesday) STEP 1 Hold down the SET button and press the DAY button to set today’s day of the week. • blinks and moves one day at a time across the days of the week with each single press of the DAY button while the SET button is held down.

  • Page 8: Setting Up Programmed Operations

    Setting Up Programmed Operations Correctly set the present time and today’s day of the week. Example settings Unless both are correctly set, the programs will not run as expected. • Up to 6 programmed operations can be set per day for each group and day of the week.
  • Page 9 STEP 3 Set up the program and press the SET button. • Select timer operation with the (timer ON/ OFF) button and (remote controller operation enable/disable) button. Then, set the trigger time with the HH and MM buttons, and press the SET button. •...

  • Page 10: Setting Errors

    Setting Errors If time is set as shown below while setting up a program, “ERROR” is displayed (the indication blinks). Therefore, correct the time setting. If Program Times Are the Same STEP 1 Every time the SET button is pressed, the setting mode switches between programmed operations of the same time setting ( in the above example), therefore select the time setting to correct.

  • Page 11: How To Check Program Times

    How to Check Program Times You can check the programmed times for each group and day of the week. STEP 1 Press the GROUP button and select a group whose time you want to check. NOTE • Group selection is disabled depending on installation conditions.

  • Page 12: How To Copy Program Times

    How to Copy Program Times You can copy the already set program of one day into another day (Day Program Copying), as well as copy the entire week programmed for one group into another group (Group Program Copying). Example of Day Program Copying Example of Group Program Copying (Copying Monday’s program into Tuesday) (Copying group No.
  • Page 13 STEP 4 Press the SET button to copy. • Press the SET button and the program schedule marker ( ) will be displayed. STEP 5 Select other copy destination days if desired. • You can copy the selected source day program into other days by repeatedly pressing the DAY button to select a day of the week followed by the SET button to set it.
  • Page 14 How to Copy Group Programs STEP 1 Press the PROG. COPY GROUP button. • “CP-1” starts blinking in the present time display area and “CP” (copy) starts blinking in the program area to indicate the copy source. STEP 2 Select a source group program to copy. •...
  • Page 15 STEP 5 Select other copy destination groups if desired. • You can copy the selected source group programs into other groups by repeatedly pressing the GROUP button to select a group followed by the SET button to set it. NOTE •...

  • Page 16: How To Set Holidays In A Scheduled Week Of Operation

    How to Set Holidays in a Scheduled Week of Operation Operations programmed for a specifi c day during the week can be temporarily disabled by setting that day as a holiday. • When the set holiday passes, the holiday setting is canceled and operation is resumed as programmed the following week.

  • Page 17: How To Disable The Timer Operation

    STEP 4 Press the HOLIDAY button to enter the holiday. • The normal display returns. How to Disable the Timer Operation To halt programmed operation for one week or more, you can disable all timer programs. • Once the timer has been disabled, programmed operations are not run until the below procedure is performed. NOTE •...

  • Page 18: How To Clear Programs

    How to Clear Programs Press the PROGRAM button. • When the PROGRAM button is pressed, the group No. and the present day of the week start blinking and the present time indication changes to a blinking “PG-1”. • Press the GROUP button to select a group to clear. NOTE •...

  • Page 19: Important Information To Remember

    Important Information to Remember 1. Schedule Timer and Air Conditioner Operation Air conditioners operate either according to operations programmed from the schedule timer (starting/stopping and remote control operation enable/disable) or according to a connected remote controller or system controller. Schedule timer settings (Example) Operation without system controller operation •...
  • Page 20 2. Power Outages If the air conditioner is running when power is lost, the air conditioner remains OFF when power is restored. Also, if remote controller operation was disabled when power was lost, it is enabled for a few minutes when power is restored.

  • Page 21: Troubleshooting

    Troubleshooting Before requesting servicing, check the following. Trouble Cause/Remedy blinks on the display. The schedule timer is performing initial communications with connected indoor units. Wait for communications to fi nish. Air conditioners do not operate as scheduled when The timer has been disabled. (Refer to page EN-17) the set time comes.
  • Page 22 Authorized representative in EU Panasonic Testing Centre Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, Germany Printed in Japan...
