Grizzly G1600 Instructions

Always wear safety glasses
during
serious personal injury.
Exceeding this PSI may
result in injury/tool damage.
RESPIRATORY HAZARD!
Sanding
dust. Wear the appropriate
protection during use!

Functional Overview

A pneumatic sanding drum mounted to a lathe
allows for easy and smooth sanding of contours
and curves.
The inflatable bladder provides for easy changes
of the replaceable sanding sleeve and also allows
for fine-tuning of the overall flexibility of the drum
for sanding compound curves and contoured sur-
faces.
By increasing the pressure in the drum, a user
can create a more rigid surface for sanding shal-
low contours. Similarly, by decreasing the pres-
sure, a user can soften the surface of the drum,
allowing it to "wrap-around" workpieces with
tighter curves.
Completely releasing the pressure decreases the
diameter of the drum so the sanding sleeve can
be removed and replaced.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
EYE INJURY HAZARD!
use to prevent
10 PSI MAX
AIR PRESSURE!
produces
COPYRIGHT © MARCH, 2008 BY GRIZZLY INDUSTRIAL, INC.
#JB10532 PRINTED IN TAIWAN
PNEUMATIC SANDING
DRUM FOR MODEL G1495

Specifications

Mounting Bore ..............................1" x 12 TPI LH
Length ............................................................... 6"
Diameter ........................................................... 4"
Air Inlet Type ...............................Schrader Valve
Maximum Pressure .................................. 10 PSI
Inflation Method .................... Manual Pump Only
Inventory
A. Pneumatic Sanding Drum .......................... 1
B. Sanding Sleeve .......................................... 1
fine
Replacement Sanding Sleeves
G4387 4" x 6" x 60 Grit Silicon Carbide
G4388 4" x 6" x 80 Grit Silicon Carbide
G1975 4" x 6" x 100 Grit Silicon Carbide
G4389 4" x 6" x 120 Grit Silicon Carbide
G1976 4" x 6" x 150 Grit Silicon Carbide
MODEL G1600
INSTRUCTIONS
B
Figure 1. Model G1600.
A
