Grizzly G0711 Instruction Sheet

This machine can cause
serious personal injury
if used incorrectly. To
reduce this risk, read
and
instructions before using!
The Model G0711 has a maximum operating
pressure of 100 PSI. Exceeding this pres-
sure can lead to an explosion, which may
cause serious personal injury!
EYE/EAR INJURY HAZARD!
Wear safety glasses and
hearing protection while
using this tool!
Disconnect tool from air
supply whenever servicing
or adjusting machine!
Keep hands clear of ham-
mer at all times!
Package Inventory
Foot Switch, Hose, and Hammer Assembly ..... 1
C-Frame ............................................................ 1
Hammer Head w/Coil Spring ............................. 1
Die ⁄ "-Shaft 1"-Radius ..................................... 1
7
8
Die ⁄ "-Shaft 2"-Radius ..................................... 1
7
8
Die ⁄ "-Shaft 3"-Radius ..................................... 1
7
8
Hex Wrench 4mm .............................................. 1
Hex Wrench 5mm .............................................. 1
WARNING: NO PORTION OF THIS MANUAL MAY bE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROvAL OF GRIZZLY INDUSTRIAL, INC.
understand
INJURY HAZARD!
CRUSHING HAZARD!
COPyRIGHT © AUGUST, 2010 By GRIzzLy INDUSTRIAL, INC.
(FOR MACHINES MFG. SINCE 7/10) #TR13227 PRINTED IN CHINA
PLANISHING HAMMER
INSTRUCTION SHEET

Specifications

Control Power ..................................... Pneumatic
Throat Depth ...............................................19
Hammer/Die Opening (Usable) ...............
Maximum Opening (Loading/Unloading) .......... 4"
Maximum Workpiece Thickness .........
these
Hammer Speed .......................... 875–1350 BPM
Operating Air Pressure ...................... 50-100 PSI
Maximum Air Pressure ........................... 100 PSI
Air Inlet Size, Consumption ........
Overall Dimensions ......... 23" L x 5
Weight ........................................................35 lbs
Figure
If you have any questions about this
machine, please call or write us.
MODEL G0711
1
. Model G0711 Planishing Hammer.
NOTICE
Grizzly Industrial, Inc.
1203 Lycoming Mall Circle
Muncy, PA 17756
Phone: (570) 546-9663
E-Mail: techsupport@grizzly.com
⁄ "
5
8
⁄ "–1 ⁄ "
3 1
8 4
⁄ " (2mm)
5
64
⁄ " NPT, 4 CFM
1
4
⁄ " W x 24" H
1
2
