Page 1: Spray Gun
MODELS H3253, H3254, H3255 INSTRUCTION MANUAL H3253 H3254 H3255 COPYRIGHT © APRIL, 2006 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #PC8209 PRINTED IN CHINA... -
Page 2: Section 1: Safety
SECTION 1: SAFETY For Your Own Safety Read Instruction Manual Before Operating This Equipment The purpose of safety symbols is to attract your attention to possible hazard- ous conditions. This manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. - Page 3 UNINTENTIONAL STARTING. Do not carry tool with hand on trig- ger and always disconnect from air when not in use. Model H3253, H3254, H3255 Spray Gun 17. DISCONNECT TOOLS before ser- vicing and changing accessories. 18. DO NOT OVERREACH. Keep proper footing/balance at all times.
-
Page 4: Section 2: Introduction
SECTION 2: INTRODUCTION Foreword We are proud to offer the Grizzly Model H3253, H3254, H3255 Spray Gun. These models are part of a growing Grizzly family of fine tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation, and proof of Grizzly’s commit-... -
Page 5: Tool Data Sheet
INLET AIR PRESSURE FLUID PRESSURE CUP MATERIAL MAX. PATTERN WIDTH BODY MATERIAL MATERIAL USAGE WATERBORNE MATERIAL COMPATIBLE Model H3253, H3254, H3255 Spray Gun TOOL DATA SHEET H3253, H3254, H3255 H3253 H3254 1 liter 750ml Siphon Siphon 1.8MM 1.3mm 4-7 CFM 3.2 CFM... -
Page 6: Section 3: Set Up
B. Cup ... 1 C. Service Wrench ... 1 " NPT ... 1 D. Cleaning Brush ... 1 E. Barbed Hose Fitting Figure 3. Model H3255 inventory. Model H3253, H3254, H3255 Spray Gun ⁄ " NPT ... 1 ⁄ " NPT ... 1... - Page 7 (see Figure 5). For the Model H3254, the cup is simply screwed on. Model H3253, H3254, H3255 Spray Gun Figure 5. Installing cup. 3. Attach the air hose to the spray gun using the barbed hose fitting provided (Models H3253, H3254, H3255) or with ⁄...
- Page 8 (H3255 only). Fluid Control Atomizing Cap: Controls the spray pattern from vertical to horizontal. Trigger: Two stage trigger. Stage one only releases compressed air for blowing off the work piece. Stage two sprays material. Model H3253, H3254, H3255 Spray Gun...
-
Page 9: Section 4: Operations
NEVER spray in an confined space where toxic fumes and flammable vapors can accumulate to deadly levels. Model H3253, H3254, H3255 Spray Gun Spraying The Model H3253, H3254, H3255 siphon feed spray gun set is designed to spray a... - Page 10 If it doesn't, please refer to Troubleshooting on Page 15. CONTAMINATION HAZARD! Dispose of paint waste in a responsible man- ner! Follow manufacturer's recom- mendations and local laws regarding disposal. Model H3253, H3254, H3255 Spray Gun...
-
Page 11: Atomizing Cap And Fan Adjustments
Page 13). Holes Stroke Figure 9. Set up for horizontal stroke direction with vertical fan pattern. Model H3253, H3254, H3255 Spray Gun Stroke Figure 10. Set up for vertical spray stroke with horizontal fan pattern. Rotating the pattern adjustment control in Figure 10 will give you a range between the two patterns in Figure 11. -
Page 12: Section 5: Accessories
This air blow gun includes a safety tip and rubber tip for all normal air cleaning jobs. ⁄ " NPT . Figure 15. H3174 Air Blow Gun with 2 Model H3253, H3254, H3255 Spray Gun ⁄ " NPT. pressure regulator. Tips. -
Page 13: Section 6: Maintenance
Fluid Tip Needle Cup Lid Figure 16. Disassembly for cleaning. Model H3253, H3254, H3255 Spray Gun 5. Unscrew the atomizing cap with your fingers and the fluid tip with the ser- vice wrench. The fully disassembled gun should look like Figure 16. - Page 14 D. Air Flow Control Valve E. Pattern Control F. Fluid Control Knob Allow the lubricant to coat threads, and run into gun body to lubricate all moving parts and seals. Figure 17. General lubrication points. Model H3253, H3254, H3255 Spray Gun...
-
Page 15: Troubleshooting
1. No pressure at gun. 2. Fluid passages dirty. 3. Fluid control closed. 4. Out of paint. 5. Material too thick. Model H3253, H3254, H3255 Spray Gun Troubleshooting Solution 1. Tighten fluid tip or replace seat with new one. 2. Add material. - Page 16 1. Lower inlet air pressure. 2. Keep gun at recommended distance. 3. Slow down and maintain consistent even parallel stroke. 1. Clean or replace both. 1. Install an in-line air filter. 2. Replace air line. Model H3253, H3254, H3255 Spray Gun...
- Page 17 PH3253021 GASKET PH3253022 HOUSING PH3253023 LOCKNUT PH3253024 LOCKNUT PH3253025 LOCKNUT PH3253028 COMPRESSION SPRING PH3253029 BODY Model H3253, H3254, H3255 Spray Gun � � � �� �� �� �� �� �� REF PART # PH3253030 NUT PH3253031 PACKING PH3253032 BODY PH3253033 VALVE...
- Page 18 PH3254018 TRIGGER ADJ. SCREW PH3254019 GUN FRAME & TRIGGER ASSY. PH3254020 NEEDLE PIN ASSY. PH3254021 PAINT STRAINER PH3254022 SERVICE WRENCH PH3254023 HOSE FITTING PH3254024 CLEANING BRUSH *Not shown in parts breakdown Model H3253, H3254, H3255 Spray Gun � �� � �� DESCRIPTION...
- Page 19 Parts Breakdown H3255 Model H3253, H3254, H3255 Spray Gun...
- Page 20 PH3255035 NUT PH3255036 POTHOOK PH3255037 SWITCH HANGER PH3255038 CONTAINER COVER PH3255039 WASHER PH3255040 PAINT INLET PIPE PH3255041 CONTAINER PH3255042 SERVICE WRENCH PH3255043 CLEANING BRUSH PH3255044 BARBED AIR FITTING *Not shown in parts breakdown Model H3253, H3254, H3255 Spray Gun DESCRIPTION...
-
Page 21: Warranty And Returns
