- Page 1 ⁄ gallon paint tanK instruction manual Copyright © MAy, 2008 By grizzly industriAl, inC. Warning: no portion of this manual may be reproduced in any shape or form Without the Written approval of grizzly industrial, inc. #JM10748 printed in ChinA...
-
Page 3: Safety Instructions For Pneumatic Tools
for your own safety read instruction manual before operating this equipment the purpose of safety symbols is to attract your attention to possible hazardous conditions. this manual uses a series of symbols and signal words which are intended to convey the level of importance of the safety messages. the progression of symbols is described below. - Page 4 7. avoid entanglements. do not wear loose clothing, gloves, neck- ties, rings, bracelets, or other jewel- ry, which may get caught in moving parts, when operating this tool. Wear a protective hair covering to contain long hair. 8. use correct air pressure. exceeding the maximum psi rating of this tool may cause unpredictable operation or bursting.
-
Page 5: Cleaning And Maintenance
additional safety instructions for paint tanks 1. read this manual. this manual contains proper operating instructions for this paint tank. 2. design modifications. do not modify the tank design or construction. drilling into the tank or weld attach- ments, or altering its design, could weaken the tank. -
Page 6: Specifications
inc. - Page 7 unpacking your paint tank was carefully packaged for safe shipping. if you discover any damage after you have signed for delivery, immedi- ately call Customer Service at (570) 546- 9663 for advice. save the containers and all packing materi- als for possible inspection by the carrier or its agent.
-
Page 8: Tank Assembly
pressure gauge regulator Assembly Air inlet Fitting safety Valve figure 2. regulator and lift handle installed on paint tank. to assemble the paint tank: 1. Apply pipe thread tape to all male pipe threads. 2. thread the lift handle into the center hole on the tank lid (see figure 2) and secure with the hex nut. - Page 9 tank regulator the pressure regulator on the paint tank controls the amount of pressure in the paint tank and the spray gun. the following are operating guidelines for internal and external spray guns: internal mix guns: use higher tank pressures up to the full amount of air pressure being delivered to the spray gun.
-
Page 10: Tank Setup
read the manual before operation. become familiar with this tool, its safety instructions, and its operation before beginning any work. serious personal injury may result if safety or operational information is not understood or followed. like all tools there is potential danger when operating this tool. -
Page 11: Cleaning And Lubrication
cleaning and lubrication cleaning the tank proper cleaning is the best way to ensure trouble free performance from your paint tank. if your tank is not thoroughly cleaned, damage and poor operation will result. problems caused by improper cleaning will not be covered by the warranty. - Page 12 tank troubleshooting symptom possible cause Air escaping from 1. Broken or damaged dia- regulator port. phragm in tank regulator. pressure dropping 1. dirty or worn valve seat in slowly on regulator. regulator. 2. loose air fittings leaking air. Fluid or air leak at 1.
- Page 13 If a Always wear safety manual is not available, glasses and a DO NOT use machine. Go respirator when using to www.grizzly.com or this equipment. call (800) 523-4777. Max. Pressure: 50 PSI REF PART # DESCRIPTION PH8225018...
-
Page 14: Warranty
Warranty grizzly industrial, inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. this warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of mainte- nance. -
Page 15: Warranty Card
____20-29 ____50-59 how long have you been a woodworker/metalworker? ____0-2 years how many of your machines or tools are grizzly? ____0-2 do you think your machine represents a good value? ____yes Would you recommend grizzly industrial to a friend? ____yes Would you allow us to use your name as a reference for our customers in your area? note: We never use names more than 3 times. - Page 16 2069 bellingham, Wa 98227-2069 tape along edges--please do not staple place stamp here...
