B140-101, B140-1P1-WP-1, B140-101X, B140-1A1-WP
201110026-93-3094-EN.indd 1
Owner's Manual
DVI over Cat5 Extenders
and Extender/Splitters
Local Unit Models: B140-002 and B140-004
Remote Unit Models: B140-1P0, B140-1P0-WP-1,
B140-1A0, B140-1A0-WP-1 and B140-110
(B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP
remote receivers only)
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2011 Tripp Lite. All rights reserved.
Extender Kit Models:
1
2
2
8
9
11
14
17
20
22
27
11/3/2011 11:37:06 AM
Advertisement
Table of Contents
Related Manuals for Tripp Lite B140-101
Summary of Contents for Tripp Lite B140-101
-
Page 1: Table Of Contents
Extender/Splitter Daisy-Chain with Remote/Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Warranty & Warranty Registration 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2011 Tripp Lite. All rights reserved. 201110026-93-3094-EN.indd 1 11/3/2011 11:37:06 AM... -
Page 2: Package Contents
External Power Supplies (0, 1, or 2) Mounting Hardware Wallplate Screws Screwdriver for Equalization Adjustment DVI Daisy-chain Cable Product Features • Support DVI-D Single-Link video resolutions up to 1920 x 1080 (60Hz) • Plug-and-play; no software or drivers required • Compatible with all major operating systems • HDCP compatible B140-101 • DVI over Cat5 Passive Extender Kit (Box-style) • Extend a 1024 x 768 (60Hz) signal up to 100 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 50 ft. from the source • No external power required 201110026-93-3094-EN.indd 2 11/3/2011 11:37:06 AM... - Page 3 Product Features B140-1P1-WP-1 • DVI over Cat5 Passive Extender Wallplate Kit • Extend a 1024 x 768 (60Hz) signal up to 75 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 50 ft. from the source • RJ45-style wallplates allow for the use of standard Cat5e/6 patch cables; 110 punchdown connection not required • No external power required B140-101X • DVI over Cat5 Active Extender Kit (Box-style) • Extend a 1024 x 768 (60Hz) signal up to 200 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 150 ft. from the source • Remote receiver unit features a built-in Equalization control for video image adjustment • Includes mounting hardware that allows remote unit to be wallmounted, rackmounted or pole mounted B140-1A1-WP • DVI over Cat5 Active Extender Wallplate Kit • Extend a 1024 x 768 (60Hz) signal up to 200 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 150 ft. from the source • Remote receiver unit features a built-in Equalization control for video image adjustment • RJ45-style wallplates allow for the use of standard Cat5e/6 patch cables; 110 punchdown connection not required 201110026-93-3094-EN.indd 3...
- Page 4 Product Features B140-002 • 2-Port DVI over Cat5 Extender/Splitter Local Transmitter Unit (Box-style) • Splits a DVI-D Single-Link signal into 2 separate signals • Works with remote/repeater and receiver units to extend a DVI-D Single-Link signal passed the 16-ft. (5 m.) distance limitation • Includes mounting hardware that allows the unit to be wallmounted, rackmounted or pole mounted B140-004 • 4-Port DVI over Cat5 Extender/Splitter Local Transmitter Unit (Box-style) • Splits a DVI-D Single-Link signal into 4 • Additional DVI port can be used to connect a local monitor or to daisy-chain additional B140-004 units. Up to 3 B140-004 units can be daisy-chained together to increase the number of connected monitors • Works with remote/repeater and receiver units to extend a DVI-D Single-Link signal passed the 16 ft. (5 m.) distance limitation...
- Page 5 Product Features B140-1A0 • DVI over Cat5 Active Extender Remote Receiver Unit (Box-style) • Works with B140-002 and B140-004 extender/splitters to extend a 1024 x 768 (60Hz) signal up to 200 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 150 ft. from the source • Built-in Equalization control for video image adjustment • Includes mounting hardware that allows the unit to be wallmounted, rackmounted or pole mounted B140-1A0-WP-1 • DVI over Cat5 Active Extender Wallplate • Works with B140-002 and B140-004 extender/splitters to extend a 1024 x 768 (60Hz) signal up to 200 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 150 ft. from the source • Built-in Equalization control for video image adjustment • RJ45-style wallplate allows for the use of standard Cat5e/6 patch cables; 110 punchdown connection not required B140-1P0 • DVI over Cat5 Passive Extender Remote Receiver Unit (Box-style) • Works with B140-002 and B140-004 extender/splitters to extend a 1024 x 768 (60Hz) signal up to 100 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 50 ft. from the source • Built-in DVI cable; separate DVI cable not required • No external power required 201110026-93-3094-EN.indd 5 11/3/2011 11:37:06 AM...
- Page 6 Product Features B140-1P0-WP-1 • DVI over Cat5 Passive Extender Wallplate • Works with B140-002 and B140-004 extender/splitters to extend a 1024 x 768 (60Hz) signal up to 75 ft. from the source, or a 1920 x 1080 (60Hz) signal up to 50 ft. from the source • RJ45-style wallplate allows for the use of standard Cat5e/6 patch cables; 110 punchdown connection not required. • No external power required B140-110 • DVI over Cat5 Extender Remote/Repeater Unit (Box-style) • Extends and expands your Tripp Lite DVI over Cat5 installation, allowing you to locate multiple monitors at different points in a chain of up to 700 ft. • Extends a 1024 x 768 (60Hz) signal up to 175 ft., or a 1920 x 1080 (60Hz) signal up to 125 ft. from the local transmitter unit to the first remote/repeater unit in the installation • Extends a 1024 x 768 (60Hz) signal up to an additional 175 ft., or a 1920 x 1080 (60Hz) signal up to an additional 125 ft. from each remote/repeater unit to the next unit in the chain.
-
Page 7: Optional Accessories
Product Features Optional Accessories: • B132-004-RB 1U Rackmount Bracket • N202-Series Cat6 24 AWG, solid wire patch cables • P561-Series DVI-D Single-Link cables 201110026-93-3094-EN.indd 7 11/3/2011 11:37:06 AM... -
Page 8: Mounting (Optional)
The following images show the different ways the included mounting brackets can be attached for different mounting methods. Note: The B140-004 can also be mounted to a Tripp Lite B132-004-RB 1U Rackmount Bracket. Up to 3 B140-004 local units can be connected to a B132-004-RB. -
Page 9: Standard Extender Kit Installation
TO DVI SOURCE B140-101 — Up to 100 ft. at 1024 x 768 (60 Hz), or up to 50 ft. at 1920 x 1080 (60 Hz) B140-1P1-WP-1 — Up to 75 ft. at 1024 x 768 (60 Hz), or up to 50 ft. at 1920 x 1080 (60 Hz) B140-101X and B140-1A1-WP —... - Page 10 B140-101X remote unit to the monitor using a Tripp Lite P561-Series DVI cable. B140-1A1-WP and B140-101X only: Connect the external power supply to the remote unit and plug it into a Tripp Lite Surge Suppressor, Power Distribution Unit (PDU) or Uninterruptible Power Supply (UPS). The Green RJ45 LED on the B140-101X remote unit will illuminate to indicate it is receiving power. The Green Power LED...
-
Page 11: Extender Kit With Remote/Repeater Installation
Connect the built-in DVI connector on the B140-101X local unit to the DVI source; or, connect the DVI source to the INPUT port on the B140-1A1-WP local unit using a Tripp Lite P561-Series DVI-D Single Link Cable. B140-1A1-WP only: Connect the external power supply to the local unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green Power LED will illuminate. 201110026-93-3094-EN.indd 11 11/3/2011 11:37:09 AM... - Page 12 Extender Kit with Remote/Repeater Installation (B140-101X and B140-1A1-WP extender kits only) Using Cat5e/6 cable, connect the RJ45 port on the local unit to the RJ45 INPUT port on the B140-110 remote/repeater unit. Connect a monitor to the DVI OUTPUT port on the remote/repeater unit using a Tripp Lite P561-Series DVI-D Single-Link Cable. Connect the external power supply to the remote/repeater unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green Power LED and the Green RJ45 LEDs illuminate to indicate the unit is receiving power. Up to 4 units can be daisy-chained (3 remote/repeaters and 1 receiver).
- Page 13 Extender Kit with Remote/Repeater Installation (B140-101X and B140-1A1-WP extender kits only) Using Cat5e/6 cable, connect the RJ45 OUTPUT port on the last remote/repeater unit to the RJ45 INPUT port of the B140-101X or B140-1A1-WP remote receiver unit. Connect a monitor to the DVI OUTPUT port on the remote receiver unit using a Tripp Lite P561-Series DVI-D Single-Link Cable. Connect the external power supply to the remote receiver unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green RJ45 LED on the B140-101X remote receiver, or the Green Power LED on the B140-1A1-WP remote wallplate, illuminates to indicate...
-
Page 14: Standard Extender/Splitter Installation
Cat5e/6 cable. Using stranded wire cable, or cable with a gauge (AWG) size higher than 24 AWG, will result in lesser performance and shorter extension distance. Tripp Lite N202-Series (Cat6) patch cables are made with 24 AWG solid wire cabling. - Page 15 Optional for B140-004: Connect a DVI monitor to the DVI port on the B140-004 marked LOCAL using a Tripp Lite P561-Series DVI-D Single-Link Cable. Connect the external power supply to the B140-002 or B140-004 local unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green RJ45 LEDs and Red Power LED on the B140-004 will illuminate to indicate power is being received from the external power supply. The Green RJ45 LEDs on the B140-002 will illuminate to indicate power is being received from the external power supply.
- Page 16 Standard Extender/Splitter Installation Connect the B140-1P0 DVI-D Single-Link connector to the monitor; or, connect the B140-1P0-WP-1, B140-1A0 or B140-1A0-WP-1 to the monitor using a Tripp Lite P561-Series DVI-D Single-Link Cable. The Green RJ45 LED on the B140-1P0 and the Green LED on the B140-1P0-WP-1 illuminate to indicate the unit is receiving power from the monitor. Repeat step 9 for each additional monitor you are connecting. Turn on the power to the DVI source. The Orange RJ45 LEDs illuminate on the B140-002, B140-004 and B140-1A0, and the Orange LED illuminates on the B140-1A0-WP-1 to indicate the unit is receiving a signal from the source.
-
Page 17: Extender/Splitter With Remote/Repeater Installation
Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable with a gauge (AWG) size higher than 24 AWG, will result in shorter extension distance. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling. 3. The installation diagram shows the B140-004. The B140-002 installation will be the same, except there are only 2 remote ports and there is no local monitor port. - Page 18 Extender/Splitter with Remote/Repeater Installation (B140-1A0 and B140-1A0-WP-1 remote receiver units only) Connect the DVI source to the INPUT port on the B140-002 or B140-004 using a Tripp Lite P561-Series DVI-D Single-Link Cable. Optional for B140-004: Connect a local monitor to the DVI OUTPUT port using a Tripp Lite P561-Series DVI-D Single-Link Cable. Connect the external power supply to the local unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green RJ45 LEDs illuminate to indicate power is being received from the external power supply.
- Page 19 Extender/Splitter with Remote/Repeater Installation (B140-1A0 and B140-1A0-WP-1 remote receiver units only) Connect the external power supply to the remote/repeater unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green Power LED and the Green RJ45 LEDs illuminate to indicate the unit is receiving power. To add a third remote/repeater unit, repeat steps 8 through 10. To finish your installation with a B140-1A0 or B140-1A0-WP-1 remote receiver unit, proceed to step 12. Using Cat5e/6 cable, connect the RJ45 OUTPUT port on the last remote/repeater unit to the RJ45 INPUT port on a B140-1A0 or B140-1A0-WP-1 remote receiver unit.
-
Page 20: Extender/Splitter Daisy-Chain Installation
Cat5e/6 cable. Using stranded wire cable, or cable with a gauge (AWG) size higher than 24 AWG, will result in lesser performance and shorter extension distance. Tripp Lite N202-Series (Cat6) patch cables are made with 24 AWG solid wire cabling. - Page 21 Extender/Splitter Daisy-Chain Installation Make sure the DVI source is powered OFF. Connect the DVI source to the DVI port on the B140-004 labeled INPUT using a Tripp Lite P561-Series DVI-D Single-Link Cable. Connect the external power supply to the B140-004 local unit and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green RJ45 LEDs and Red Power LED will illuminate to indicate power is being received from the external power supply. Using the included DVI daisy-chain cable, connect the OUTPUT DVI port on the first B140-004 to the INPUT DVI port on a second B140-004.
-
Page 22: Extender/Splitter Daisy-Chain With Remote/Repeater Installation
Cat5e/6 cable. Using stranded wire Cat5e/6 cable, or cable with a gauge (AWG) size higher than 24 AWG, will result in shorter extension distance. All Tripp Lite N202-Series Cat6 cables are made with 24 AWG solid wire cabling. 201110026-93-3094-EN.indd 22... - Page 23 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Up to 175 ft. at 1024 x 768 (60Hz) Up to 175 ft. at 1024 x 768 (60Hz) Up to 125 ft. at 1920 x 1080 (60Hz) Up to 125 ft.
- Page 24 B140-004 using the included 1-ft. DVI daisy-chain cable. Repeat step 3 if you want to connect a third B140-004. Connect the external power supply to the first B140-004 in the daisy-chain and plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The Green RJ45 LEDs and the Red Power LED on the B140- 004 will illuminate to indicate power is being received from the external power supply.
- Page 25 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Up to 4 units can be daisy-chained (3 remote/repeaters and 1 receiver). To connect additional remote/repeater units, proceed to step 11. To finish your installation with a B140-1A0 or B140-1A0-WP-1 remote receiver unit, proceed to step 15. Using Cat5e/6 cable, connect the RJ45 OUTPUT port on the first remote/repeater unit to the RJ45 INPUT port on a second remote/ repeater unit.
- Page 26 Extender/Splitter Daisy-Chain with Remote/ Repeater Installation (B140-004 extender/splitter, and B140-1A0 and B140-1A0-WP remote receivers only) Repeat steps 8 through 17 for each additional RJ45 output port on the local transmitter units. Turn on the power to the DVI source. The Orange RJ45 LEDs on the local transmitter, remote/repeater and B140-1A0 illuminate to indicate a signal is being received from the source. The Orange LED on the B140-1A0-WP-1 illuminates to indicate a signal is being received from the source.
-
Page 27: Warranty & Warranty Registration
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. - Page 28 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support 201110026 • 933094 201110026-93-3094-EN.indd 28 11/3/2011 11:37:17 AM...
