Cisco TelePresence System Codec C40 Reference Manual page 49

Cisco TelePresence System Codec C40/C60
Contents Introduction
xConfiguration Network [1..1] QoS Diffserv NTP
This setting will only take effect if Network QoS Mode is set to Diffserv.
Define which priority NTP packets should have in the IP network.
The priority for the packets ranges from 0 to 63 - the higher the number, the higher the priority.
The recommended value for NTP is 0, which means best effort. If in doubt, contact your network
administrator.
The priority set here might be overridden when packets are leaving the network controlled by the
local network administrator.
Requires user role: ADMIN
Value space: <0..63>
Range: Select a value between 0 to 63 - the higher the number, the higher the priority. The default
value is 0 (best effort).
Example: xConfiguration Network 1 QoS Diffserv NTP: 0
xConfiguration Network [1..1] IEEE8021X Mode
The system can be connected to an IEEE 802.1X LAN network, with a port-based network access
control that is used to provide authenticated network access for Ethernet networks.
Requires user role: ADMIN
Value space: <Off/On>
Off: The 802.1X authentication is disabled (default).
On: The 802.1X authentication is enabled.
Example: xConfiguration Network 1 IEEE8021X Mode: Off
xConfiguration Network [1..1] IEEE8021X TlsVerify
Verification of the server-side certificate of an IEEE802.1x connection against the certificates in
the local CA-list when TLS is used. The CA-list must be uploaded to the video system. This can be
done from the web interface.
This setting takes effect only when Network [1..1] IEEE8021X Eap Tls is enabled (On).
Requires user role: ADMIN
Value space: <Off/On>
Off: When set to Off, TLS connections are allowed without verifying the server-side X.509
certificate against the local CA-list. This should typically be selected if no CA-list has been
uploaded to the codec.
On: When set to On, the server-side X.509 certificate will be validated against the local CA-list for
all TLS connections. Only servers with a valid certificate will be allowed.
Example: xConfiguration Network 1 IEEE8021X TlsVerify: Off
D14642.15 Codec C40-C60 API Reference Guide TC7.0, JANUARY 2014.
About the API xConfiguration xConfiguration
xConfiguration Network [1..1] IEEE8021X UseClientCertificate
xConfiguration Network [1..1] IEEE8021X Identity
xConfiguration Network [1..1] IEEE8021X Password
xConfiguration Network [1..1] IEEE8021X AnonymousIdentity
49
xCommand
Authentication using a private key/certificate pair during an IEEE802.1x connection. The
authentication X.509 certificate must be uploaded to the video system. This can be done from the
web interface.
Requires user role: ADMIN
Value space: <Off/On>
Off: When set to Off client-side authentication is not used (only server-side).
On: When set to On the client (video system) will perform a mutual authentication TLS handshake
with the server.
Example: xConfiguration Network 1 IEEE8021X UseClientCertificate: Off
The 802.1X Identity is the user name needed for 802.1X authentication.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: xConfiguration Network 1 IEEE8021X Identity: ""
The 802.1X Password is the password needed for 802.1X authentication.
Requires user role: ADMIN
Value space: <S: 0, 32>
Format: String with a maximum of 32 characters.
Example: xConfiguration Network 1 IEEE8021X Password: ""
The 802.1X Anonymous ID string is to be used as unencrypted identity with EAP (Extensible
Authentication Protocol) types that support different tunneled identity, like EAP-PEAP and EAP-
TTLS. If set, the anonymous ID will be used for the initial (unencrypted) EAP Identity Request.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: xConfiguration Network 1 IEEE8021X AnonymousIdentity: ""
API Reference Guide
xStatus Appendices
Copyright © 2010–2014 Cisco Systems, Inc. All rights reserved.
