Engineered Solutions | AMC2 VdS Enclosure
AMC2 VdS Enclosure
www.boschsecurity.com
This enclosure is used for securely mounting and
housing the AMC2 and a power supply in a VdS-
certified environment.
System overview
This enclosure has been produced in accordance with
strict guidelines and is used for securely mounting and
housing the AMC2 and a power supply.
When mounted according to VdS 2119 guidelines the
access control panel AMC2 4R4 can be used for
arming and disarming VdS-Class C certified intrusion
alarm systems.
Certifications and approvals
IP rating
VdS Enviroment Class
Parts included
Quantity Component
1 The VdS enclosure
1 Screws and fittings
1 Uncovered printed circuit board (PCB) for additional LED
IP30
II
VdS 2119-compliant
u
DIN-rail click system for easy mounting and
u
replacement
Tamper-detection
u
Quantity Component
1 Connectors for the PCB
1 Set of cables
1 Anti-tamper switch for the enclosure
1 Lock and key set for the enclosure
1 Installation manual for compliance with VdS 2119
Technical specifications
Mechanical properties
Dimensions
Ordering information
AMC2 VdS Enclosure
AMC2 enclosure with single DIN rail and mountings for
VdS 2119-compliant installation. An AMC2 control
panel within it may arm/disarm VdS-Class C intrusion
detection systems. The AMC2, power supply and
batteries are not included.
Order number
AEC-AMC2-VDS
405 x 405 x 100 mm
(15.95 x 15.95 x 3.94 in)
