Printing the "demo" page (Demo)
The demo page ( see example on page XI ) gives you a full
color/black monochrome print-out and allows you to check
the correct functioning of the print heads.
1. Click the Printer Monitor icon (if necessary).
2. Click the Printer Care tab.
3. Click the Demo button, then follow the instructions
displayed.
Running the print test (Test)
The print test ( see example on page XI ) gives you a
print-out of the printer functional characteristics (firmware
release, print head test, current settings).
1. Click the Printer Monitor icon (if necessary).
2. Click the Printer Care tab.
3. Click the Test button, then follow the instructions
displayed.
The Printer Monitor has an extensive, user-friendly HELP
feature which explains all its functions.
12
Printer Operator Panel
The behavior of the keys and light indicators on the operator
panel will depend on the printer's status and whether the
front cover is closed or open.
Printer states:
free: no data to be printed;
busy: from the reception of data until the completion of
its printing;
standby: printer powered but dormant (more than two
minutes have elapsed since last interchange with host);
reduces power consumption.
special function mode : user-invoked operating mode
independent of host.
User Interface - Printer Operator Panel
