- Page 1 Digital Wireless Microphone System System Integration Guide...
-
Page 2: Table Of Contents
Table of Contents Outline Network System Configuration ......57 System Configuration ..........57 Equipment Features ...........60 Digital Wireless Outline Installation of Remote Control Unit RMU-01 ....61 What is DWX? ............4 Network Device Connections ........63 What Is WiDIF-HP? ............5 Making and Checking Network Settings .....64 2.4 GHz area operation check ........65 What Is Cross Remote? ...........6 Step 1 Network Setup ..........66... -
Page 3: Outline
Outline Sony started in the wireless microphone business in 1974 with the introduction of a 40-MHz band VHF system. This was soon followed by an industry-first PLL Synthesized VHF system in 1983. Continually enhancing its wireless products line, Sony introduced a groundbreaking 800-MHz band PLL Synthesized UHF Wireless Microphone system at the NAB event in 1991. -
Page 4: Digital Wireless Outline
Digital Wireless Outline What is DWX? DWX refers to Sony’s new digital wireless microphone system. The DWX series reflects Sony’s extensive expertise in professional microphones and sound design. It represents a successful blend of Sony know-how, wireless technology renowned for stability, and cutting-edge digital audio technology. -
Page 5: What Is Widif-Hp
What Is WiDIF-HP? WiDIF-HP (WiDIF: Wireless Digital Interface Format, HP: High Profile) is a wireless digital audio interface format developed by Sony. It enables highly secure transmission with high sound quality and low system latency, and supports simultaneous multi- channel operation. -
Page 6: What Is Cross Remote
Digital Wireless Outline What Is Cross Remote? Cross Remote is a system that allows transmitters to be monitored and controlled from a receiver and the Wireless Studio control software installed on a computer connected to the receiver. For example, the settings of a transmitter worn under clothing can be easily changed over the wireless link. -
Page 7: Technology
Technology WiDIF-HP Technology A new high-profile format for the digital audio interface on UHF – WiDIF-HP -- has been developed for the DWX series. This section provides further details on WiDIF-HP technology. WiDIF-HP Technology Outline A digital audio wireless transmission system handles audio after the analog signal has been converted into digital form by an A/D converter. - Page 8 Secure transmission The Sony digital audio codec achieves an optimum balance between sound quality, bit rate, and latency, while having the redundant bit assignment necessary for wireless transmission. Channel Coding and Decoding In order to ensure high quality audio signal transmission within the given bit rate limits, WiDIF-HP employs synchronization technology to keep the error count as low as possible, along with error processing technology that minimizes the risk of noise when an error occurs.
- Page 9 & 1152 kb/s Bit Expansion Sony has developed a new digital modulator and demodulator that allows large-scale simultaneous multi- channel operations. In addition to benefiting from advanced RF technology know-how in the field of analog wireless transmission systems, the digital audio wireless transmission system also incorporates a digital modulation system that is less vulnerable to wave interference.
-
Page 10: Key Features Of Widif-Hp
WiDIF-HP technology was developed by Sony to fundamentally improve the transient response performance and therefore further enhance sound quality. It employs 24-bit/48-kHz sampling and provides: ... - Page 11 Digital wireless system Provided that there are no errors, the audio signal quality will not be degraded. In the Sony digital wireless system, an error does not occur provided the D/U signal ratio is 20 dB or more. Therefore sound quality will not be impaired as long as this condition is met.
- Page 12 D/U signal ratio of 40 dB or more. In the Sony digital wireless system on the other hand, an error does not occur provided the D/U signal ratio is 20 dB or more. Therefore sound quality will not be impaired as long as this condition is met. The digital...
- Page 13 Common Frequency Reuse Configuration In a digital wireless system, the minimum distance for reusing a common frequency is one sixth of an analog setup. Compared to an analog system or a mixed analog/digital system, the digital wireless system can be configured for a three times bigger operation area which facilitates efficient use of space in convention centers for trade fairs and similar applications.
- Page 14 This makes it easy to maintain confidentiality for conference rooms, live performance venues and other applications where strong measures against interception are required. The Sony digital system offers the choice between a secure mode using encryption keys, and a password mode where a secure group comprising multiple transmitters and receivers can be created.
- Page 15 Metadata Transmission Along with the audio signal, comprehensive information about the transmitter is sent as metadata, including audio input level, battery status, attenuator setting, etc. This enhances operation convenience, since the transmitter status can be monitored in any of the following ways: On the display of the receiver ...
-
Page 16: Widif-Hp Precautions
Sony professional lavalier and shotgun microphones with a suffix /9X in the model name, such as the ECM-77BC/9X, are certified by Sony to be suitable for use with the DWX digital wireless system. Other Sony professional microphones without a /9X in the model name may not be suitable for use with the DWX system. - Page 17 Sound Quality Degradation under Weak Field Conditions — Analog and Digital Propagation Provided that the transmitter power is the same, the signal level at the receiver at a given distance will be the same for a digital wireless and analog wireless system. This means that both systems can be said to have a service area of the same size.
- Page 18 Notes Refer to Sony digital wireless system frequency lists for further details on pre-programmed groups of frequencies built into every DWX transmitter and receiver. Sony’s built-in pre-programmed frequency groups provide 500 kHz channel spacing for digital channel plans D1-D9 along with analog channel plans 01-09 (containing irregular channel spacing) to ensure compatibility with Sony analog wireless system channel plans.
- Page 19 System Behavior in Case of Interference To understand how analog and digital systems can have a mutual effect on each other in actual operation, it is important to consider the way in which the demodulated audio signal deteriorates when interference occurs.
-
Page 20: Cross Remote Technology
Technology Cross Remote Technology Cross Remote is a system that allows transmitters to be monitored and controlled from a receiver and the Wireless Studio control software installed on a computer connected to the receiver. Cross Remote Outline Compared to analog wireless systems, the DWX series allows more channels to be operated simultaneously. The Cross Remote system for remote control of transmitters from a receiver was developed to facilitate setup and operation of large wireless microphone configurations. - Page 21 Why does Cross Remote use both UHF and 2.4 GHz frequencies? Cross Remote is a two-way communication system for transmitters and receivers that uses both UHF and 2.4 GHz frequencies to complement each technology’s strengths and advantages. Advantages of 2.4 GHz (over using two-way UHF) ...
- Page 22 Technology System configuration Cross Remote defines APL layer. Application Layer: Determines the network configuration and pairing Defines the protocols for user interaction method, roaming principles, and protocols. APL Layer on the network ST mode/NT mode switching is also performed here. (pairing and address allocation).
- Page 23 Used frequencies Cross Remote selects the optimal frequency for communication based on the system and the environment. If interference is detected on a currently used frequency, the system automatically switches to another frequency and continues communication. This assures stable operation even under congested 2.4 GHz conditions.
- Page 24 Technology Pairing Prior to being able to use the Cross Remote control functions, the transmitter and receiver must be assigned to each other in a process called pairing. The relationship between transmitter and receiver is that of Coordinator to Device. When NT mode is used, the Remote Control Unit RMU-01 is the Coordinator. Pairing requirement Because Cross Remote uses only three frequencies to control multiple transmitters (up to 82 in NT mode), it is not possible to identify devices by frequency assignment, as for the main communication link.
- Page 25 Roaming In NT mode, when the connection between transmitter and remote control unit is interrupted, the transmitter automatically searches for another remote control unit to connect to. If found, the transmitter connects to that remote control unit, and the connection to the paired receiver is established again.
-
Page 26: Cross Remote Features
Technology Cross Remote Features Cross Remote can be operated in two modes, ST mode and NT mode, to fit different system requirements. This section explains the features of ST mode and NT mode, and of the Wireless Studio application designed for monitoring and controlling transmitters. - Page 27 NT Mode Features In NT mode, transmitters and receivers communicate via the Remote Control Unit RMU-01 connected to a network. This enhances convenience during simultaneous multi-channel operation. In ST mode, a paired receiver and transmitter operate in a one-on-one configuration. This will lead to channel congestion when the equipment count increases.
- Page 28 Technology Communication flow from Wireless Studio RMU-01 All commands must Transmit control command pass through receiver Computer used via 2.4 GHz band for monitoring Transmitter Send command via Ethernet Send command via Ethernet Show transmitter ATT 0 dB ...
- Page 29 Features of Wireless Studio Using the Wireless Studio software application supplied with the Digital Wireless Receiver DWR-R01D, up to 82 transmitters can be simultaneously monitored and controlled. By recording the operation log, operational errors can be examined later. Status Viewer Shows the status of various equipment.
-
Page 30: Cross Remote Precautions
Technology Cross Remote Precautions This section provides information about various points to keep in mind when setting up and operating a Cross Remote system. Ensuring a Stable Service Area In the Cross Remote service area, the two wireless signals for the main (UHF) link and remote control ... -
Page 31: Configuring A Dwx System
Configuring a DWX System DWX System Configuration This section describes the process of configuring a system and provides information about limitations, frequency support and other aspects. System Sections and Configuration Flow System configuration In general, configuring a DWX system will involve the three devices listed below. 1. -
Page 32: System Limitations
Configuring a DWX System System Limitations The following limitations apply regarding equipment used in a DWX series system. Section Item Maximum Limit Remarks Audio/frequency Max. number of transmitters US/Canada 12 channels Within 1 TV channel (6 MHz) planning section 16 channels Within 1 TV channel (8 MHz) Japan 18 channels... -
Page 33: Audio Equipment Selection
Audio Equipment Selection When selecting equipment for a DWX series system, please take the features and specifications of the respective models into consideration. Equipment Features DWX series equipment is divided into the following categories. DWX Microphone Series DWX Transmitter Series ... - Page 34 Support for diversity reception enables dual antenna input/ microphone connected through the supplied XLR cable, or the cascaded output. audio output from a mixer, etc. 9 or 12 V DC power supply output for powering Sony UHF AN series active antennas. Battery compartment (output) ...
- Page 35 DWR-S01D Digital Wireless Receiver Rear Panel Camcorder slot interface 2-channel receiver ANALOG OUT (Analog output) 1/2 connectors (XLR type) For connection to the analog input of a mixer, amplifier, etc. The analog audio output level can be set from a menu. ...
- Page 36 Configuring a DWX System Adapter Bottom DWA-01D Wireless Adapter The DWA-01D can be used as a portable wireless receiver in conjunction with the Digital Wireless Receiver DWR-S01D. It can also be mounted on a camcorder, and two units can be linked for 4-channel operation.
-
Page 37: Uhf System Configuration
UHF System Configuration In order to maximize performance of the Digital Wireless Receiver DWR-R01D, select the UHF antenna configuration as described below. System Configuration System Requirements Because the DWX system uses RF transmission in the UHF band, similar to analog wireless systems, antenna cables of an existing analog wireless system can be used, provided that the frequency matches. -
Page 38: Equipment Features
Configuring a DWX System Equipment Features UHF Accessories Wall installation using built-in outlet box UHF Antenna AN-01 Plate covering the outlet box This is a unidirectional log periodic dipole antenna. Connect to the Hangers Example of horizontal ANTENNA A/B NO.6-32UNC directivity characteristics IN (DC9V OUT) screws (supplied) - Page 39 Screw to the wall. ANTENNA A DC OUT (power supply to antenna A) switch Supplies 9V DC to the Sony UHF antenna connected to the ANTENA A DC OUT 1 and 2 connectors. If interference or distortion occurs, set to OFF.
-
Page 40: Antenna Installation Requirements
(thickness), and the subsequent letter indicates the impedance: “C” stands for 75 ohms and “D” for 50 ohms. Both for analog wireless systems and digital wireless systems, Sony recommends “5D-2V” -- “8D-2V” cables with 50-ohm impedance because these have lower transmission losses. 75-ohm BNC cables can also be used. - Page 41 Number of antennas and diversity reception Use two identical antennas The DWX system, like the conventional analog wireless system, uses the space diversity reception principle. Two antennas are employed to receive the signal, with the system automatically switching to the antenna with the stronger signal.
- Page 42 Configuring a DWX System Antenna installation position Distance between transmitter and antenna Line-of-sight service area ranges for different RF power levels are listed below. RF power Transmission distance 10 mW 60 m (196.9 ft.) 1 mW 20 m (65.6 ft.) If the transmitter is located too close to the antenna, input overload may occur, leading to intermodulation distortion and noise.
- Page 43 Booster gain setting conditions BNC cables used with UHF antennas should have low losses. To obtain the proper diversity effect, the cables should in principle be kept as short and large-gauge as possible, and should have the same length. If BNC cables need to be run over long distances, you should use an antenna booster to compensate for cable transmission losses.
-
Page 44: Making And Checking Rf Settings (Uhf)
Configuring a DWX System Making and Checking RF Settings (UHF) Follow the procedure shown in the flowchart below to establish parameters and check operation. Parameters to check 1. Band usage: White space TV channel 2. Group usage: See “List of Supported Frequencies” (page 78) 3. -
Page 45: Checking The Rf Level (Uhf)
Checking the RF Level (UHF) The RF level at which the receiver receives signals can be checked using the display of the Digital Wireless Receiver DWR-R01D or the RF level meter of Wireless Studio. See the next section for details. Checking with the DWR-R01D display You can check whether the transmitter is in the service area by using the display of the Digital Wireless Receiver DWR-R01D. -
Page 46: Step 1 Channel Plan Selection
Configuring a DWX System Checking with Wireless Studio The RF level meter of the Wireless Studio application can be used to verify the RF level. RF level meter Step 1 Channel Plan Selection Check possible sources of interference including TV broadcast signals and external interference noise and determine the band and group to use. - Page 47 TV broadcast transmissions exist into consideration when selecting the group. For details on the groups that can be selected, see “Sony Digital Wireless Microphone System Frequency Lists” (PDF). * When simultaneous multi-channel operation is realized with a mix of analog wireless and digital wireless systems, the frequency spacing between the analog and digital systems must be at least 375 kHz.
-
Page 48: Step 2 Antenna Installation And Setup
Configuring a DWX System Step 2 Antenna Installation and Setup Select the channel with the most difficult conditions as the desired channel, and perform an operation test with the desired channel (single channel). Determine and optimize antenna installation positions and orientation that will be difficult to change later, and decide on number of antennas and gain settings. - Page 49 Antenna installation and setup 9 Power up only the desired channel TX and establish a setup simulating the expected conditions during actual operation. Example: If the TX is the DWM-01, it should be held in the hand, close to the mouth. If the TX is the DWT-B01, it should be worn on the hip.
- Page 50 Configuring a DWX System Flowchart for Step 2 Selecting the desired channel From Step 1 Power up all TX except for one. Power down a different TX Check third-order intermodulation distortion noise level Designate channel with highest noise level as desired channel Antenna installation and setup ...
-
Page 51: Step 3 Checking The Service Area With One Channel
Step 3 Checking the Service Area With One Channel Using the desired channel subject to severe conditions, assign a range of parameters for TX power output and RX attenuator settings, and check whether the settings result in coverage of the intended service area. Procedure 12 Power up only the desired channel TX and establish a setup simulating the expected conditions during actual operation. -
Page 52: Step 4 Checking Third-Order Intermodulation Distortion
Configuring a DWX System Step 4 Checking Third-order Intermodulation Distortion Power up all transmitters for channels other than the desired channel, and generate third-order intermodulation distortion (subsequently called interference) in the receiver for the desired channel. Assign a range of parameters for TX output power and RX attenuator settings and check the interference noise level with each setting. -
Page 53: Step 5 Checking Simultaneous Multi-Channel Operation
Step 5 Checking Simultaneous Multi-channel Operation Using settings established as acceptable in steps 1 – 4, power up all transmitters and check the service area for the desired channel. If the service area for the desired channel is achieved, the service area for other channels should also be equal or better. - Page 54 Configuring a DWX System Flowchart for Step 3 Checking the service area with one channel From Step 2 Make parameter settings and power up only TX for desired channel Check whether service area is achieved for desired channel (single channel) Change TX RF power and RX ATT level parameters...
-
Page 55: Troubleshooting
Troubleshooting If noise, audio output dropout, or a decrease in the QL occurs, check the following. Is the RF level Is the RF level To Case 3 too low? too high? To Case 1 To Case 2 Case 1: RF level is too low (15 dBu or less, RF indicator frequently turns red) ... -
Page 56: Quick Check
Configuring a DWX System Quick Check When there is not enough time for a step-by-step configuration of the system, such as during an event or concert, check the following three items to verify that the system has been configured properly. Conditions for checking Perform the check after confirming that all antennas and cables are installed, settings for the antenna gain, TX RF power, RX attenuator, and used frequencies are configured, and the RX equipment is turned on. -
Page 57: Network System Configuration
Operation is not guaranteed for connections utilizing wireless LAN access points. ST mode and NT mode The Sony digital wireless system supports two types of remote control: ST mode where a transmitter and receiver communicate directly in a one-on-one configuration, and NT mode where the transmitter and receiver communicate via the RMU-01 connected to the network. - Page 58 Configuring a DWX System System configuration examples Configure the system while referring to the following examples. Configuring an ST mode system When operating from the receiver only When operating from the receiver and a computer One DWR-R01D or DWR-S01D unit ...
- Page 59 Configuring an NT mode system Notes When determining the number of RMU-01 units to use, refer to the “Installation of Remote Control Unit RMU-01” (page 62) section and take the coverage area of the RMU-01 into consideration. When supplying power to the RMU-01 via PoE, refer to the diagrams in the “Power supply (PoE) for RMU-01” section. When operating from the receiver only When operating from the receiver and a computer One DWR-R01D unit...
-
Page 60: Equipment Features
Configuring a DWX System Equipment Features DWX Network Accessories Computer requirements Remote Control Unit RMU-01 The computer on which to install Wireless Studio for use with the DWX system must meet the following requirements. This is a 2.4 GHz antenna designed specifically for Cross Remote NT mode operation. -
Page 61: Installation Of Remote Control Unit Rmu-01
1) RMU-01 2) Transmitter 1) Radius: approx. 10 m (33 feet) 2) Front side (the side with SONY logo) When installing multiple RMU-01 units, place them so that strong signal area touches that of adjacent RMU-01 unit. Installation example 1 (plane view) - Page 62 The number of operation channels does not significantly 3) To make the most of the signal emission change the roaming time. characteristics, install facing the front side (the side with SONY logo) downward. 1-channel system: approx. 1 second 4) Ceiling ...
-
Page 63: Network Device Connections
Network Device Connections This section describes which LAN cables to use and how to supply power (PoE) when connecting each device in a network. LAN cable information Use Category 5 or better LAN cable, and keep cable length under 100 meters. If cable runs of more than 100 meters are required, use a hub or other suitable equipment. -
Page 64: Making And Checking Network Settings
Configuring a DWX System Making and Checking Network Settings Follow the steps described below to make network settings and check the Cross Remote functions. Step 1 Specify the IP addresses and subnet masks of the devices connected to the network. Network setup Step 2 Verify that there are no IP address conflicts and that all devices connected to the network are... -
Page 65: 2.4 Ghz Area Operation Check
2.4 GHz area operation check Checking with the DWR-R01D display Use the “Cross Remote” control condition indication to check whether the transmitter is in the 2.4 GHz area. “Cross Remote” control condition indication “Cross Remote” control condition indication Indicates the signal transmission condition of the “Cross Remote” control function (four levels). : Good transmission : Somewhat good transmission : Somewhat poor transmission... -
Page 66: Step 1 Network Setup
Configuring a DWX System Step 1 Network Setup Specify the IP addresses and subnet masks of the devices connected to the network. Network configuration Configure a dedicated network for the DWX system, using 100Base-TX/10Base-T Ethernet equipment. Do not use an existing network. System precautions and limitations ... - Page 67 Computer network settings Use the regular procedure for the respective operating system to set the IP address and subnet mask of the computer. PC network settings The following procedure explains the setting operations using the Windows XP operating system. * For details on how to make network settings with other operating systems, refer to the help of the operating system that you use.
- Page 68 Configuring a DWX System RMU-01 network settings Install the setup tool supplied with the RMU-01 on the computer and make the RMU-01 network settings from the computer. Procedure Start the RMU-01 setup tool on the computer. Click the [Search Devices] button. Note On some computers equipped with multiple LAN ports (either wired or wireless), the RMU-01 units connected to the LAN will not be detected even after you click the [Search Devices] button.
-
Page 69: Step 2 Checking Equipment Connections
Step 2 Checking Equipment Connections Verify that all devices connected to the network are correctly installed and set up. Checking the remote mode The display of the DWR-R01D can be used to check whether the receiver currently operates in ST mode or NT mode. - Page 70 Configuring a DWX System Checking the equipment count Use Wireless Studio to check the type and number of devices connected to the network. If there are IP address conflicts such as address duplication, the actual number of devices and the number shown in Wireless Studio will not match.
-
Page 71: Step 3 Checking For 2.4 Ghz Interference
Step 3 Checking for 2.4 GHz Interference Verify that there is no interference in the frequency bands used for Cross Remote. Procedure Power down all DWX equipment so that no RF signals in the 2.4 GHz band are emitted by the DWX system. - Page 72 Configuring a DWX System Flowchart Step 1 Network setup to Establish network settings for each device Step 2 Checking equipment connections Check mode Check equipment count Check and re-assign IP addresses Does number of devices shown in Wireless Studio match actual number of devices?
- Page 73 Step 4 Checking the monitor function Power up all equipment and make WiDIF-HP reception settings Check monitor function at receiver and computer Does status monitoring Repeat RF level setting (see page 45) work in all channels? Step 5 Checking the control function ...
-
Page 74: Sample System Configaration
Sample System Configaration Sample Minimum System Configuration (2 channels) The Digital Wireless Transmitter DWT-B01 and the Digital Wireless Receiver DWR-S01D are used in a one-on-one configuration. Cross Remote via internal 2.4 GHz DWR-R01D Transmitters Sample Small-Scale System Configuration Using Remote Control Unit RMU-01 (7 – 16 channels) Transmitters UHF antennas RMU-01... -
Page 75: Sample Medium-Scale System Configuration Using Antenna Divider Wd-850 (17 Channels Or More)
Sample Medium-Scale System Configuration Using Antenna Divider WD-850 (17 channels or more) Transmitters RMU-01 RMU-01 UHF antenna 50-ohm 50-ohm terminator 50-ohm terminator To AC power terminator source To AC power source DWR-R01D (Total eight units) To AC power source DWR-R01D (Total eight units) RMU-01 Making and Checking Network Settings... -
Page 76: Sample Maximum System Configuration (82 Channels)
Sample System Configaration Sample Maximum System Configuration (82 channels) Transmitters UHF antenna WD-850 WD-850 Network connections are not illustrated here. Making and Checking Network Settings... -
Page 77: References
References * December, 2010 List of Supported Frequencies Because there are no dedicated frequency bands for wireless use in North America and Europe, empty TV channels in the UHF band are used for wireless microphone operation. The bandwidth of one TV channel is 6 MHz in the US and 8 MHz in the EU. -
Page 78: Equipment Specifications
3.0 V DC, with two LR6 (AA) batteries Operating voltage Battery life Continuous operating time 5 hours (Ambient temperature 25 °C, using Sony LR6 AA-size alkaline batteries, 10 mW output, wireless remote control off, DIMMER MODE set to AUTO OFF) Operating temperature 0 °C to 50 °C Storage temperature –20 °C to +60 °C... -
Page 79: Remote Control Unit
Digital Wireless Receiver Digital Wireless Adapter DWR-R01D DWR-S01D DWA-01D Tuner section Audio section Wireless interface WiDIF-HP Audio output connector SMC9-4S (female) (OUTPUT1/OUTPUT2) Type of reception Space diversity Analog output impedance 150 ohms or less Circuit system Double superheterodyne AES/EBU output impedance 110 ohms Carrier frequencies See frequency information below. - Page 80 References UHF Accessories AN-820A AN-01 WD-850 Directivity Unidirectional Horizontal omnidirectional — Antenna type log periodic dipole array Dipole — Frequency bands 470 – 862 MHz 470 – 542 MHz 556 – 662 MHz 638 – 758 MHz 758 – 862 MHz —...
