Hybrid IP-PBX
PT Programming Manual
KX-TDA15
Model No.
Thank you for purchasing a Panasonic Hybrid IP-PBX.
Please read this manual carefully before using this product and save this manual for future use.
PSMPR Software File Version 4.0000 or later

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TDA15

Summary of Contents for Panasonic KX-TDA15

  • Page 1 Hybrid IP-PBX PT Programming Manual KX-TDA15 Model No. Thank you for purchasing a Panasonic Hybrid IP-PBX. Please read this manual carefully before using this product and save this manual for future use. PSMPR Software File Version 4.0000 or later...
  • Page 2 Introduction About this Programming Manual The PT Programming Manual is designed to serve as a reference to programming the Panasonic Hybrid IP-PBX using a Panasonic proprietary telephone (PT) with display. The PT Programming Manual is divided into the following sections: Section 1, Overview Provides an overview of programming the PBX.
  • Page 3 Panasonic Communications Company (U.K.) Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. Declarations of Conformity for the relevant Panasonic products described in this manual are available for download by visiting: http://www.doc.panasonic.de...

  • Page 4: Table Of Contents

    Table of Contents Overview....................9 Introduction ........................10 1.1.1 Introduction ........................10 1.1.2 Password Security......................11 1.1.3 Entering Characters ......................12 PT Programming................... 15 PT Programming ......................16 2.1.1 Programming Instructions ....................16 2.1.2 Entry Values ........................19 2.1.3 Basic Programming......................20 [000] Date & Time............................20 [001] System Speed Dialling Number......................
  • Page 5 [303] Special Carrier Access Code........................28 [304] Emergency Number ..........................28 [320] ARS Mode ..............................28 [321] ARS Leading Number..........................29 [322] ARS Routing Plan Table Number......................29 [325] ARS Exception Number ..........................29 [330] ARS Routing Plan Time Table ........................29 [331–346] ARS Routing Plan Table (1–16) ......................29 [350] ARS Carrier Name..........................30 [351] ARS Trunk Group for Carrier Access ......................30 [352] ARS Removed Number of Digits for Carrier Access................30...
  • Page 6 [515] Wireless XDP Parallel Mode for Paired Telephone................. 38 [516] Programming Mode Limitation........................ 38 2.1.9 Extension Programming ....................39 [600] EXtra Device Port (XDP) Mode ......................39 [601] Terminal Device Assignment ........................39 [602] Class of Service ............................. 39 [603] Extension User Group ..........................39 [604] Extension Intercept Destination......................
  • Page 7 [902] Slot Card Reset ............................49 Appendix....................51 Revision History ......................52 3.1.1 KX-TDA15 PSMPR Software File Version 4.0xxx ............52 Feature Programming References................53 PT Programming Manual...
  • Page 8 PT Programming Manual...

  • Page 9: Overview

    Section 1 Overview This section provides an overview of programming the PBX. PT Programming Manual...

  • Page 10: Introduction

    These programming instructions are designed to serve as an overall system programming reference for the Panasonic Hybrid IP-PBX. Each feature in the PBX has default settings that can be changed to customise the PBX to your requirements. These settings control the functions of the PBX, and changing them is referred to as "system programming".

  • Page 11: Password Security

    1.1 Introduction 1.1.2 Password Security To maintain system security, system passwords are required to access certain programming functions of the PBX. By giving different users access to different passwords, it is possible to control the amount of programming that each user is able to perform. The following types of system passwords are available: Password Description...

  • Page 12: Entering Characters

    1.1 Introduction 1.1.3 Entering Characters The following characters can be used when storing a name, message, or other text entry data using a PT. The tables below show you the characters available by pushing each button a specific number of times. Table 1 (Standard mode) Table 2 (Option mode) PT Programming Manual...
  • Page 13 1.1 Introduction Table 2 (Option mode for CE model) Table 2 (Option mode for GR model) PT Programming Manual...
  • Page 14 1.1 Introduction [Example of Entering Characters] To enter "Ann": (5 times) (5 times) FWD/DND Notes • To erase the character on the cursor, press CLEAR. • To move the cursor to the left, press • To move the cursor to the right, press .

  • Page 15: Pt Programming

    Section 2 PT Programming This section serves as reference operating instructions when using a display PT to program the PBX. PT Programming Manual...

  • Page 16: Pt Programming

    2.1 PT Programming PT Programming 2.1.1 Programming Instructions Required Telephone/Extension PBX settings can be customised through system programming by using a proprietary telephone (PT) with a multiline display, such as the KX-T7636. To access system programming, the Class of Service (COS) assigned to the PT's extension must be programmed to allow system programming, or the PT must be connected to the lowest-numbered port on the card installed in the lowest-numbered slot.
  • Page 17 2.1 PT Programming Fixed Buttons Function KX-T7200/KX-T7400/ KX-T7600/IP-PT* KX-T7500* AUTO ANS SELECT MESSAGE AUTO ANSWER MESSAGE MUTE MUTE FLASH/ FLASH FLASH RECALL TRANSFER CLEAR TRANSFER INTERCOM SECRET INTERCOM : The buttons shown in this column are from the KX-T7600 series. : The buttons shown in this column are from the KX-T7400 series.
  • Page 18 2.1 PT Programming Programming Programming Group Title Description Number System Management Global system parameters [1XX] Programming [2XX] Timer Programming System timers TRS/Barring/ARS TRS/Barring and Automatic Route [3XX] Programming Selection (ARS) programming [4XX] Trunk Programming Trunk, trunk group, and BRI line settings [5XX] COS Programming Class of Service parameters...

  • Page 19: Entry Values

    2.1 PT Programming 2.1.2 Entry Values Throughout this manual, maximum entry values are shown for each programming item, as shown in the example below. [351] Carrier Table No. Trunk Group No. SELECT SELECT Disable/ 01–10 01–64 ENTER ENTER Enable Slot and Port Values Available Slot Entry Values Slot Number Supported Cards...

  • Page 20: Basic Programming

    2.1 PT Programming 2.1.3 Basic Programming [000] Date & Time [In 12-hour Format] [000] Year Month Date 01–31 00–99 01–12 ENTER ENTER Minute Hour SELECT 00–59 (AUTO ANS/MESSAGE) 01–12 ENTER NEXT (HOLD) AM/PM [In 24-hour Format] [000] Year Date Month 01–12 00–99 01–31...

  • Page 21: Extension Name

    2.1 PT Programming Note • If PC Phone, PC Console, or a CTI application is running on a PC connected to an extension whose extension number is to be programmed/modified, quit the application first. [004] Extension Name [004] Extn. No. Name 1–5 digits Max.

  • Page 22: Absent Message

    2.1 PT Programming [008] Absent Message [008] Message Location No. Max. 16 characters 1–8 ENTER ENTER [010] Charge Margin [010] Margin XX.YY% 2+2 decimal places ENTER ENTER [011] Charge Tax [011] Location No. Tax XX.YY% 01–03 2+2 decimal places ENTER ENTER [012] Charge Rate per Unit [012]...

  • Page 23: System Management Programming

    2.1 PT Programming 2.1.4 System Management Programming [100] Flexible Numbering [100] Location No. Feature No. 01–68 1–4 digits ENTER ENTER (HOLD) To the Next Location No. To the Desired Location No. NEXT CANCEL [101] Time Service Switching Mode [101] SELECT (AUTO ANS/MESSAGE) ENTER Manual/Automatic...

  • Page 24: Idle Line Access (Local Access)

    2.1 PT Programming [103] Idle Line Access (Local Access) [103] Location No. Trunk Group No. 01–64 01–64 ENTER ENTER [110] System Password for Administrator—for PT Programming [110] Password 4–10 digits ENTER ENTER 1234 [111] System Password for User—for PT Programming [111] Password 4–10 digits...

  • Page 25: Verification Code Cos Number

    2.1 PT Programming WARNING There is a risk that fraudulent telephone calls will be made if a third party discovers a personal identification number (PIN) (verification code PIN or extension PIN) of the PBX. The cost of such calls will be billed to the owner/renter of the PBX. To protect the PBX from this kind of fraudulent use, we strongly recommend: Keeping PINs secret.

  • Page 26: Timer Programming

    2.1 PT Programming 2.1.5 Timer Programming [200] Hold Recall Time [200] Time 0–240 s ENTER ENTER (HOLD) [201] Transfer Recall Time [201] Time 1–240 s ENTER ENTER [203] Intercept Time [203] Time No. Time No. Time 1 Day/2 Lunch 1–240 s ENTER ENTER 3 Break/4 Night...

  • Page 27: Call Duration Count Starting Time For Lcot

    2.1 PT Programming [208] Call Duration Count Starting Time for LCOT [208] Time 0–60 s ENTER ENTER [209] DISA Delayed Answer Time [209] Time 0–30 s ENTER ENTER [210] DISA Trunk-to-Trunk Call Prolong Time [210] Time 0–7 min ENTER ENTER [211] DISA Intercept Time [211] Time...

  • Page 28: Trs/Barring/Ars Programming

    2.1 PT Programming 2.1.6 TRS/Barring/ARS Programming [300] TRS/Barring Override by System Speed Dialling [300] SELECT (AUTO ANS/MESSAGE) ENTER ENTER Disable/Enable (HOLD) [301] TRS/Barring Denied Code [301] Level No. Location No. Denied Code 2–6 001–100 Max. 16 digits ENTER ENTER To the Next Location No. To the Desired Location No.

  • Page 29: Ars Leading Number

    2.1 PT Programming [321] ARS Leading Number [321] Location No. Leading No. 0001–1000 Max. 16 digits ENTER ENTER [322] ARS Routing Plan Table Number [322] Location No. Plan Table No. 0001–1000 01–16 ENTER ENTER [325] ARS Exception Number [325] Location No. Exception No.

  • Page 30: Ars Carrier Name

    2.1 PT Programming [350] ARS Carrier Name [350] Carrier Table No. Name 01–10 Max. 20 characters ENTER ENTER [351] ARS Trunk Group for Carrier Access [351] Carrier Table No. Trunk Group No. SELECT SELECT Disable/ 01–10 01–64 ENTER ENTER Enable [352] ARS Removed Number of Digits for Carrier Access [352] Digits to Remove...

  • Page 31: Trunk Programming

    2.1 PT Programming 2.1.7 Trunk Programming [400] LCOT/BRI Trunk Connection [400] Slot No. Port No. SELECT (AUTO ANS/MESSAGE) 02–04 01–02 ENTER No Connect/ ENTER (HOLD) Connect To the Next Port No. To the Desired Port No. NEXT CANCEL [401] LCOT/BRI Trunk Name [401] Name Trunk No.

  • Page 32: Lcot Dtmf Minimum Duration

    2.1 PT Programming [412] LCOT DTMF Minimum Duration [412] Slot No. Port No. SELECT 03–04 01–02 80/160 ms ENTER ENTER [413] LCOT CPC Signal Detection Time—Outgoing [413] Slot No. Port No. Mode No. 03–04 01–02 0: None/1: 6.5/ ENTER ENTER 2–113: (N–1)×8 ms [414] LCOT CPC Signal Detection Time—Incoming [414]...

  • Page 33: Bri Network Type

    2.1 PT Programming [420] BRI Network Type [420] Slot No. Port No. Network Type 02–04 01–02 00–56 ENTER ENTER [421] BRI DIL/DDI/MSN Selection [421] Slot No. Port No. SELECT 02–04 01–02 DIL/DDI/MSN ENTER ENTER [422] BRI Subscriber Number [422] Slot No. Port No.

  • Page 34: Bri Tei Mode

    2.1 PT Programming [427] BRI TEI Mode [427] Slot No. Port No. 02–04 01–02 00–63 (for Fix)/ ENTER ENTER ENTER Clear (for Automatic) Note After changing this setting, perform [902] Slot Card Reset to enable the new setting. [450] DIL 1:1 Destination [450] Slot No.

  • Page 35: Extension-To-Trunk Call Duration

    2.1 PT Programming [472] Extension-to-Trunk Call Duration [472] Trunk Group No. Time 01–64 01–60 min ENTER ENTER [473] Trunk-to-Trunk Call Duration [473] Trunk Group No. Time 01–64 01–60 min ENTER ENTER [475] DISA Silence Detection [475] Trunk Group No. SELECT 01–64 No Detect/ ENTER...

  • Page 36: Cos Programming

    2.1 PT Programming 2.1.8 COS Programming [500] Trunk Group Number [500] Time No. COS No. 1 Day/2 Lunch/ 01–64 ENTER 3 Break/4 Night Trunk Group No. SELECT (AUTO ANS/MESSAGE) 01–64 ENTER (HOLD) Disable/Enable To the Next To the Next Trunk Group COS No.

  • Page 37: Executive Busy Override

    2.1 PT Programming [505] Executive Busy Override [505] COS No. SELECT Disable/ 01–64 ENTER ENTER Enable [506] Executive Busy Override Deny [506] COS No. SELECT 01–64 Disable/ ENTER ENTER Enable [507] DND Override [507] COS No. SELECT Disable/ 01–64 ENTER ENTER Enable [508] Account Code Mode...

  • Page 38: Permission For Door Open Access

    2.1 PT Programming [512] Permission for Door Open Access [512] COS No. SELECT Disable/ 01–64 ENTER ENTER Enable [514] Time Service Manual Switching [514] COS No. SELECT 01–64 Disable/ ENTER ENTER Enable [515] Wireless XDP Parallel Mode for Paired Telephone [515] COS No.

  • Page 39: Extension Programming

    2.1 PT Programming 2.1.9 Extension Programming [600] EXtra Device Port (XDP) Mode [600] Slot No. Port No. SELECT (AUTO ANS/MESSAGE) 01–04 Off/On (HOLD) ENTER ENTER To the Next Port No. To the Desired Port No. NEXT CANCEL [601] Terminal Device Assignment [601] Slot No.

  • Page 40: Clip/Colp Number

    2.1 PT Programming [606] CLIP/COLP Number [606] Extn. No. CLIP/COLP No. 1–5 digits Max. 16 digits ENTER ENTER [620] Incoming Call Distribution Group Member Incoming Call [620] Location No. Extn. No. Distribution 01–32 1–5 digits Group No. ENTER 001–128 ENTER [621] Incoming Call Distribution Group Delayed Ringing Incoming Call [621]...

  • Page 41: Incoming Call Distribution Group Distribution Method

    2.1 PT Programming [624] Incoming Call Distribution Group Distribution Method Incoming Call [624] SELECT Distribution Ring/UCD/ ENTER ENTER Group No. Priority Hunt 001–128 [625] Destination for Overflow Time Expiration Incoming Call [625] Destination No. Time No. Distribution Max. 32 digits 1 Day/2 Lunch/ Group No.

  • Page 42: Queuing Hurry-Up Level

    2.1 PT Programming [629] Queuing Hurry-up Level Incoming Call [629] Hurry-up Level Distribution None/1–30 ENTER ENTER Group No. 001–128 [630] Queuing Time Table Incoming Call [630] Time No. Table No. Distribution 1 Day/2 Lunch/ 01–64/None Group No. ENTER 3 Break/4 Night 001–128 ENTER [631] Sequences in Queuing Time Table...

  • Page 43: External Pagers Of A Paging Group

    2.1 PT Programming [641] External Pagers of a Paging Group [641] Paging Group No. External Pager No. SELECT 01–32 No/Yes ENTER ENTER [650] Extension User Groups of a Pickup Group [650] Pickup Group No. Extn. User Group No. SELECT 01–64 001–032 No/Yes ENTER...

  • Page 44: Ps Registration

    2.1 PT Programming [690] PS Registration [690] PS No. Extn. No. To the PS operation 001–028 1–4 digits below ENTER ENTER KX-TCA255 Press POWER Select Select for 2 seconds. "Setting Handset". "Registration". PIN for PS Registration 4 digits Select Select "Register H/set".

  • Page 45: Resource/Interface Programming

    2.1 PT Programming 2.1.10 Resource/Interface Programming [700] External Pager Floating Extension Number [700] Pager No. Extn. No. 1–5 digits (HOLD) ENTER ENTER [710] Music Source Selection for BGM [710] SELECT (AUTO ANS/ MESSAGE) ENTER ENTER External/Internal1/ Internal2 [711] Music on Hold [711] Music Source No.

  • Page 46: Outgoing Message (Ogm) Floating Extension Number

    2.1 PT Programming [730] Outgoing Message (OGM) Floating Extension Number [730] Message No. Extn. No. 01–32 1–5 digits ENTER ENTER [731] Outgoing Message (OGM) Name [731] Message No. Name 01–32 Max. 20 characters ENTER ENTER [732] DISA Security Mode [732] SELECT None/ Trunk/All...

  • Page 47: Smdr & Maintenance Programming

    2.1 PT Programming 2.1.11 SMDR & Maintenance Programming [800] RS-232C Parameter—New Line Code [800] Location SELECT (AUTO ANS/MESSAGE) ENTER ENTER CR+LF/CR (HOLD) [800] RS-232C Parameter—Baud Rate [800] Location SELECT 2400/4800/9600/ 19200/38400/57600/ ENTER ENTER 115200 bps [800] RS-232C Parameter—Word Length [800] Location SELECT 7/8 bits...

  • Page 48: Smdr Skip Perforation

    2.1 PT Programming [803] SMDR Skip Perforation [803] Skip Perforation 0–95 lines ENTER ENTER [804] SMDR Outgoing Call Printing [804] SELECT No print/Print ENTER ENTER [805] SMDR Incoming Call Printing [805] SELECT No print/Print ENTER ENTER [810] Remote Programming [810] SELECT Disable/ Enable...

  • Page 49: Card Programming

    2.1 PT Programming 2.1.12 Card Programming [900] Slot Card Type Reference [900] Slot No. Card Name 01–11 Reference only (HOLD) ENTER [901] Slot Card Deletion [901] Slot No. Delete Confirming the 01–11 ENTER ENTER deleting operation. To the Next Slot No. To the Desired Slot No.
  • Page 50 2.1 PT Programming PT Programming Manual...

  • Page 51: Appendix

    Section 3 Appendix PT Programming Manual...

  • Page 52: Revision History

    3.1 Revision History Revision History 3.1.1 KX-TDA15 PSMPR Software File Version 4.0xxx Changed Contents • [003] Extension Number • [004] Extension Name • [005] Extension Personal Identification Number (PIN) • [006] Operator Assignment • [007] DSS Console Paired Telephone •...

  • Page 53: Feature Programming References

    3.2 Feature Programming References Feature Programming References Absent Message • [008] Absent Message Feature Guide Reference 1.17.2 Absent Message Account Code Entry • [508] Account Code Mode Feature Guide Reference 1.5.4.3 Account Code Entry Automatic Route Selection (ARS) • [320] ARS Mode •...
  • Page 54 3.2 Feature Programming References Feature Guide Reference 1.3.1.2 Call Forwarding (FWD) Call Hold • [200] Hold Recall Time Feature Guide Reference 1.12.1 Call Hold Call Pickup • [650] Extension User Groups of a Pickup Group Feature Guide Reference 1.4.1.3 Call Pickup Call Transfer •...
  • Page 55 3.2 Feature Programming References Calling/Connected Line Identification Presentation (CLIP/COLP) and Calling/Connected Name Identification Presentation (CNIP/CONP)—by QSIG • [003] Extension Number • [004] Extension Name Feature Guide Reference 1.26.4.2 Calling/Connected Line Identification Presentation (CLIP/COLP) and Calling/ Connected Name Identification Presentation (CNIP/CONP)—by QSIG Class of Service (COS) •...
  • Page 56 3.2 Feature Programming References • [730] Outgoing Message (OGM) Floating Extension Number • [731] Outgoing Message (OGM) Name • [732] DISA Security Mode Feature Guide Reference 1.15.6 Direct Inward System Access (DISA) Display Information • [130] Decimal Point Position for Currency •...
  • Page 57 3.2 Feature Programming References 1.8.3 Extension Dial Lock Extension Personal Identification Number (PIN) • [005] Extension Personal Identification Number (PIN) Feature Guide Reference 1.24.1 Extension Personal Identification Number (PIN) Extension Port Configuration • [007] DSS Console Paired Telephone • [600] EXtra Device Port (XDP) Mode Feature Guide Reference 2.1.1 Extension Port Configuration External Feature Access (EFA)
  • Page 58 3.2 Feature Programming References • [632] Maximum Number of Agents Feature Guide Reference 1.2.2.2 Group Call Distribution Host PBX Access Code (Access Code to the Telephone Company from a Host PBX) • [471] Host PBX Access Code Feature Guide Reference 1.5.4.7 Host PBX Access Code (Access Code to the Telephone Company from a Host PBX) Hot Line •...
  • Page 59 3.2 Feature Programming References • [426] BRI Configuration • [427] BRI TEI Mode Feature Guide Reference 1.19.1 Integrated Services Digital Network (ISDN) Intercept Routing • [203] Intercept Time • [604] Extension Intercept Destination • [625] Destination for Overflow Time Expiration Feature Guide Reference 1.1.1.6 Intercept Routing Intercept Routing—No Destination...
  • Page 60 3.2 Feature Programming References Manager Features • [112] Manager Password • [511] Manager Assignment Feature Guide Reference 2.2.6 Manager Features Multiple Subscriber Number (MSN) Ringing Service • [421] BRI DIL/DDI/MSN Selection • [426] BRI Configuration Feature Guide Reference 1.1.1.4 Multiple Subscriber Number (MSN) Ringing Service Music on Hold •...
  • Page 61 3.2 Feature Programming References • [629] Queuing Hurry-up Level Feature Guide Reference 1.2.2.3 Outside Destinations in Incoming Call Distribution Group Overflow Feature • [625] Destination for Overflow Time Expiration • [626] Overflow Time • [627] Destination When All Busy • [628] Queuing Call Capacity •...
  • Page 62 3.2 Feature Programming References • [002] System Speed Dialling Name • [004] Extension Name Feature Guide Reference 1.21.3 PS Directory PS Ring Group • [620] Incoming Call Distribution Group Member Feature Guide Reference 1.21.2 PS Ring Group PS Roaming by Network ICD Group •...
  • Page 63 3.2 Feature Programming References Feature Guide Reference 2.3.8 Software Upgrading Special Carrier Access Code • [303] Special Carrier Access Code Feature Guide Reference 1.5.4.8 Special Carrier Access Code Speed Dialling—Personal/System • [001] System Speed Dialling Number • [002] System Speed Dialling Name •...
  • Page 64 3.2 Feature Programming References Time Service • [101] Time Service Switching Mode • [102] Time Service Starting Time • [514] Time Service Manual Switching Feature Guide Reference 2.2.4 Time Service Toll Restriction (TRS)/Call Barring (Barring) • [300] TRS/Barring Override by System Speed Dialling •...
  • Page 65 3.2 Feature Programming References 1.8.6 Verification Code Entry Virtual PS • [690] PS Registration Feature Guide Reference 1.21.6 Virtual PS Voice Mail (VM) Group • [601] Terminal Device Assignment • [660] VM Group Floating Extension Number Feature Guide Reference 1.20.1 Voice Mail (VM) Group Voice Mail DPT (Digital) Integration •...
  • Page 66 Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. 2006 Panasonic Communications Co., Ltd. All Rights Reserved.

Table of Contents
