Panasonic MEW01 351 Planning Manual
Panasonic MEW01 351 Planning Manual

Panasonic MEW01 351 Planning Manual

Fire alarm system
Table of Contents

Advertisement

Planning Instructions
MEW01351
Revision -
Fire Alarm System EBL512 G3
V1.1.x
Author:
Jan Pettersson
Date of issue: 2011-02-11
Date of rev:

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic MEW01 351

  • Page 1 Planning Instructions MEW01351 Revision - Fire Alarm System EBL512 G3 V1.1.x Author: Jan Pettersson Date of issue: 2011-02-11 Date of rev:...
  • Page 2 This page has deliberately been left blank.
  • Page 3: Table Of Contents

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Table of contents Introduction________________________________ 8 Definitions / Explanations ___________________ 10 PEWN AB _______________________________________ 10 Alarm points _____________________________________ 10 2.2.1 Smoke detector _______________________________ 10 2.2.2 Sensor ______________________________________ 10 2.2.3...
  • Page 4 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The TLON network ________________________________ 17 Single TLON Network / redundant TLON Network ______ 17 Control Units 5000 and 5001 _________________ 19 Mounting plates ___________________________________ 21 5.1.1...
  • Page 5 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 9.3.1 Web-servers __________________________________ 59 Other units _______________________________________ 59 9.4.1 Alert Annunciation Controllers ___________________ 59 9.4.2 External LED ________________________________ 60 9.4.3 Alarm devices (sounders, etc.) ___________________ 60 9.4.4...
  • Page 6 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 14.3.3 Reset interlocking output (H9/C3) ________________ 87 14.3.4 Disable interlocking output (H9/C4) _______________ 87 14.3.5 Re-enable interlocking output (H9/C5) _____________ 87 14.4 Interlocking control expressions ______________________ 87...
  • Page 7 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.22 Test of routing equipment ________________________ 110 16.23 Calibration of supervised outputs __________________ 110 16.24 Service signal _________________________________ 110 16.25 Fault signal (fault condition) ______________________ 111 16.26...
  • Page 8 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 19.2.3 Upgrade number of alarm points _________________ 129 19.2.4 Restart _____________________________________ 130 19.2.5 Delete _____________________________________ 130 19.2.6 Properties___________________________________ 130 System properties (settings) _________________ 131 20.1...
  • Page 9 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 28.2 C.i.e. / System ___________________________________ 160 National regulations _______________________ 162 Drawings / connection diagrams _____________ 163 Revision history ___________________________ 164 Drawings according to the valid table of drawings.
  • Page 10: Introduction

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Introduction EBL512 G3 Planning Instructions is a document intended to be used by planning engineers as well as service / commissioning engineers. This document should be read in conjunction with the drawings according to the valid Table of drawings and the EBL512 G3 Operating Instructions MEW01163.
  • Page 11 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  a product name (e.g. Main Board 128 alarm points)  a p.c.b. number (e.g. 9290-2B) and can also have a configuration (e.g. CFG: 2) and a revision (e.g. REV: 1) ...
  • Page 12: Definitions / Explanations

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Definitions / Explanations Definitions / explanations / abbreviations / etc. frequently used or not explained elsewhere in the document. PEWN AB Panasonic Electric Works Nordic AB Alarm points Units, which can generate a fire alarm (in the control unit), i.e.
  • Page 13: Conventional Zone Line Input / External Line

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 2.2.8 Conventional zone line input / External line Input intended for one or more conventional alarm points. End-of-line device in the last alarm point on the line.
  • Page 14: Network / Tlon / Lonworks / Echelon / Node / Tlon Conn. Board / Channel / Backbone Net / Router / Repeater

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x ® ® 2.12 Network / TLON / LonWorks / Echelon / Node / TLON Conn. board / Channel / Backbone net / Router / Repeater Brief explanations to the words/expressions to be found in connection with a "network".
  • Page 15: Site Specific Data (Ssd)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 2.17 Site Specific Data (SSD) The SSD is unique for each installation. All alarm points, presentation numbers, user definable alarm text messages, programmable outputs, etc. are created in the PC program WinG3 and also downloaded in EBL512 G3 with WinG3.
  • Page 16: Overview

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Overview The EBL512 G3 system EBL512 G3 is a microprocessor controlled intelligent fire alarm system, intended for analog addressable smoke detectors, as well as conventional detectors and manual call points.
  • Page 17: S/W Versions

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x is space for two 28 Ah batteries. Larger batteries (up to 65 Ah) have to be placed outside the c.i.e. The batteries and the power supply are connected to the Main board (5010), which handles the charging of the batteries, etc.
  • Page 18: Tlon Manager

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x WinG3 shall have the same version number as the EBL512 G3 software version number, e.g. 1.1.x and 1.1.x respectively. indicates only a small correction and is not required to be the same.)
  • Page 19: Control Unit / Tlon Network

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Control Unit / TLON Network The TLON network An installation (a system) can be one control unit (c.i.e.) or up to 30 control units connected in a TLON Network.
  • Page 20 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x NOTE! In a system where each control unit is independent of the other (i.e. each control unit works like a "standalone" control unit) a single TLON Network may be sufficient.
  • Page 21: Control Units 5000 And 5001

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Control Units 5000 and 5001 Two types of control units are available: Type no. Product Front (FBP with display & CP) 5000 EBL512 G3 c.i.e.
  • Page 22 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Figure 2. The EBL512 G3 front with display ("Man-Machine- Interface"); The Fire Brigade Panel (FBP) is the upper part and the Control Panel (CP) is the lower part. The look might vary depending on the language, country, etc.
  • Page 23: Mounting Plates

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Each control unit 5000-5001 has the following basic configuration:  Grey metal cabinet  MMI board (5011) (not in 5001)  EBL512 G3 front with display (not in 5001) ...
  • Page 24: Com Loops

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x COM loops Each control unit has four COM loops (0-3) to which the loop units are connected. Connections according to dwg 512 G3 – 25, - 31, - 36, - 37 &...
  • Page 25 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  Since not all COM loop units are found by the control unit, the communication starts in the B-direction also.  Since it is not a single break, all units will not be found by the control unit.
  • Page 26: Programmable Voltage Outputs (S0-S3)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Programmable voltage outputs (S0-S3) The 24 V DC outputs S0-S3 are supervised (monitored) Connections according to dwg 512 G3 – 23. When all connections are done a calibration has to be performed, see chapter "Calibration of...
  • Page 27: Relay Outputs For Routing Equipment (Tx)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Relay outputs for routing equipment (tx) Not programmable outputs. The outputs can be tested via menu H1, see the EBL512 G3 Operating Instructions MEW01163. Connections according to dwg 512 G3 –...
  • Page 28: Expansion Boards 458X

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Expansion boards 458x Inside EBL512 G3 (5000 and 5001) there are space and holders for up to six optional expansion boards of the types 4580, 4581 and 4583 to be mounted, see drawing 512 G3 - 01.
  • Page 29: Expansion Board No. (Address) Setting

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Expansion board no. (address) setting The expansion board no. (address) is set via jumpers on the expansion board respectively. Board no. 4580, 4581 and 4583...
  • Page 30: Type Of Zone Line Input

    NOTE! Valid for the Australian and New Zealand conventions only. This type shall be used only when any of the other types cannot be used (e.g. for some older type of detectors and not Panasonic detectors). It has the highest zone line current consumption since the end-of-line device is a resistor, 4K7 (±5 %).
  • Page 31: Relays Expansion Board 4581

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x and low voltage states cannot be reached / activated. After alarm reset (in EBL512 G3) the zone line input will return to the normal state.
  • Page 32: Inputs And Outputs Expansion Board 4583

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The I/O expansion board 4583 has two programmable supervised / not supervised voltage outputs (Output 0-1), one special / programmable output (Output 2) intended for German extinguishing system and five programmable supervised / not supervised inputs (Input 0-4).
  • Page 33: I/O Matrix Board 4582

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Input 0 (J1:3-4): Can be used for German Fire alarm routing equipment fault (Melder quittung) Input 1 (J1:7-8): Can be used for German key cabinet (FSK rückmeldung)
  • Page 34: Generic

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Fan control and indicating panel, for four Fan control panels, each with six LEDs (On / Auto / Off / Running / Stopped / Fault) and three push buttons (On / Auto / Off).
  • Page 35: Fan Control

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  Output no. (0-47)  Properties, like any programmable relay output. Each input (0-15) has to be added and programmed via WinG3 regarding: ...
  • Page 36: Zone Control

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  Zone (control) no. (0-15)
  • Page 37: Printer

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Printer The control unit type 5000 can be with or without a printer depending on if "PRN" is added in the article number or not. It is mounted on the front panel door and is connected to the MMI board 5011.
  • Page 38: Tlon Connection Board 1590

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x TLON connection board 1590 On the EBL512 G3 control unit (5000 / 5001) main board (5010), there are spaces and connectors for two TLON connection boards type...
  • Page 39: Peripheral Devices

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Peripheral devices Alarm points. Analog alarm points (detectors, etc.) are connected directly to a COM loop. Conventional alarm points (detectors, etc.) are connected to an 8 zones expansion board (4580) zone line input or a COM loop unit (e.g.
  • Page 40 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The following units can be connected to the COM loops (in NORMAL mode): NOTE! is used on the Alarm Acknowledge Facility Control (AAFC) Australian market only.
  • Page 41: Input Units

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x NOTE! The COM loop address for the Addressable Base station for wireless units (4610) is set on a DIL-switch in the unit respectively. The COM loop address for a wireless detector (4601) is depending on which Base station it is "connected"...
  • Page 42 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 9.1.1.1 Analog Sensor Bases (ASB) An analog detector (Sensor) shall be plugged in an analog base. The COM loop address is set in the detector, see below.
  • Page 43 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 3339 Enclosed Addressable Manual Call Point. 3339 is like the 3333 unit but with another type of back-box (incl. a tightening gasket). For surface mounting. For indoor use in premises where IP56 rating is required.
  • Page 44 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 4313). Built-in LEDs are lit to indicate that the detector activated a fire alarm. Prepared for mechanical lock (screw attached) – if required. Via WinG3, it is set how the detector shall operate: Two presentation numbers (addresses): The detector unit works as two separate detectors.
  • Page 45 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 0 4 8 12 16 20 24 28 32 36 40 44 48 52 56 60 Smoke value Figure 8. When the calculated value in the decision algorithm exceeds the lower graph, pre-warning will be activated.
  • Page 46 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The Address setting tool (3314) is also used for mode setting: NORMAL mode: 4301 in this mode is in WinG3 set to one of...
  • Page 47 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 6295 Heat detector: Enclosed (IP67) Fixed temperature heat detector, 57°C, class A2 S (static response temp. range 54- 70°C), latching. Min./typical/max. ambient temp. -40/+25/+50°C. Built-in LED is lit to indicate that the detector has activated a fire alarm.
  • Page 48: Addressable I/O Units

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 3390 Label holder. To be mounted in an analog base (3312 / 3312F / 3312FL / 4313) . Intended for a label with "zone-address", "technical address", etc.
  • Page 49 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x address label on which the unit's COM loop address can be written. The Address setting tool (3314) is also used for the mode setting: NORMAL mode: Used for 3361 in system EBL512 G3.
  • Page 50: Alarm Devices (Addressable Sounders)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x technical address can be written. The Address setting tool (3314) is also used for mode setting: NORMAL mode: Used for 3364 in system EBL512 G3.
  • Page 51: Short Circuit Isolators (Addressable)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x connected to the COM loop but max. 10 per COM loop. Red ABS plastic housing and PC lens. Low (0.5 Cd) or high (1 Cd) light output is programmable.
  • Page 52: Units For Hazardous (Ex) Areas

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Segment A Segment B A-dir.  4313 no. A no. 00 EBL512 G3 4313 no. B no. 01 B-dir.  Segment C Figure 9. Two 4313 isolators connected to a COM loop gives three loop segments, i.e.
  • Page 53: Other Com Loop Units

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x of up to 20 IS detectors 2840 and 2841. It is mounted in a Waterproof box (IP66/67). Five compression glands for the cable entries are supplied. Box dimensions (L x W x H): 280 x 280 x 133 mm.
  • Page 54 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x equipment requiring 24 V DC with battery backup, e.g. the 3364 unit (see page 47). It also has a "/Mains OK" output (normally low), intended to be connected to the corresponding input on the 3364 unit.
  • Page 55 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Fan control functions. The panel is intended to be mounted in the General control cabinet 4590, in which three Fan control panels 4593 can be mounted. For connection to the c.i.e. is one I/O Matrix board 4582 required for each 4594 board.
  • Page 56: Com Loop Addresses For Base Station And Wireless

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x can be "connected" to each Addressable Base station for wireless units (4610). Each Base station shall have a transmission channel (0-3) selected. The Base station's COM loop address is set on a DIL-switch.
  • Page 57: External Fire Brigade Panels

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Via WinG3 can "Selective alarm presentation" be programmed, i.e. you can select which alarms that shall be presented in each unit, see the Technical Description for the unit respectively.
  • Page 58: Alert Annunciation Units

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x get access to the push buttons. They are disabled until they are supposed to be used. The unit shall be wall mounted. Two compression glands are attached. In all other respects it is like 1826, except that a printer cannot be mounted in 1828.
  • Page 59: External Presentation Units

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Fire brigade alerted, indicating that the "Fire brigade tx" output is activated in EBL512 G3 because: - the activated fire alarm is not an AA alarm - the AA function has been ended, e.g.
  • Page 60: German Fire Brigade Panels

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x EBL512 G3. Any fault in the system will be presented as "General fault in system". The buzzer will sound. It can be silenced. Any disablement in the system will be presented as "General...
  • Page 61: Units Connected To The Rs232 Interface J7

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Units connected to the RS232 interface J7 9.3.1 Web-servers 1598 Web-server II. This unit can be used: a) for presentation of the actual c.i.e. status in a PC using the web browser Microsoft Internet Explorer.
  • Page 62: External Led

    Alarm devices (sounders, etc.) Regarding addressable alarm devices, see page 48. In the Panasonic product range are no alarm devices intended for a supervised (monitored) voltage output (e.g. S0 – S3 in EBL512 G3). Connections of alarm devices according to drawing 512 G3 - 23.
  • Page 63: Boxes

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x (e.g. 1N4004) in parallel with the coil, like in the alarm devices, see drawing 512 G3 - 23. 9.4.5 Boxes 3362 Waterproof box (IP66 / 67). A grey polycarbonate box with ingress protection rating IP66 / 67.
  • Page 64: Programmable Inputs

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Programmable inputs In each control unit are four programmable, not supervised inputs (I0-I3) available. In EBL512 G3 can also be mounted the Inputs and Outputs expansion board 4583, with five programmable inputs (Input 0-4).
  • Page 65: Control Unit Inputs I0 - I3 & Inputs 0 -4 On Exp. Board 4583

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 10.1 Control unit Inputs I0 - I3 & Inputs 0 -4 on exp. board 4583 10.1.1 Not supervised Normally open (R > 2K) or Normally closed (R < 2K) Activation time: >0.5 sec.
  • Page 66: Input Programming

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Input programming Input programming is done in WinG3. For more information see WinG3 help. Each input has to have an individual Trigger condition ("Triggered by") and Logic. It is not recommended to let two or more inputs have the same trigger condition.
  • Page 67 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Comments to the trigger conditions (above): 0. Activates any output as long as the input is active. This is valid even if the output is disabled.
  • Page 68 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 12. Activated input will generate a fault in EBL512 G3. Output with trigger condition "Extinguishing system fault" will be activated. The following fault message will be shown:...
  • Page 69: Logic

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 23. Used for the "outside switch" (i.e. the New Zealand FB silence switch). 24. The Addressable multipurpose I/O unit 3361 monitored Input 0 used as zone line input (Z).
  • Page 70: Programmable Outputs

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Programmable outputs In each control unit are four programmable voltage outputs (S0-S3) and two programmable relay outputs (R0-R1) available. 8 relays expansion boards (4581) and Input and Output expansion board (4583) with three programmable outputs (Output 0-2) can be mounted in each EBL512 G3.
  • Page 71: Control Unit Outputs S0 - S3

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Each 3377 and 3379 unit is programmed (WinG3) regarding:  COM loop address  Name (Normally not changed)  Priority level (High / Medium / Low) ...
  • Page 72: Control Unit Outputs R0 & R1

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 12.2 Control unit outputs R0 & R1 Each control unit has two programmable relay outputs: Relay output, NO or NC contacts programmable Relay output, NO or NC contacts programmable Connections and more information, see dwg.
  • Page 73: The 3364 Unit's Vo0 - Vo2

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The 3364 unit's VO0 – VO2 12.6 Each 3364 unit has two programmable, supervised (monitored) voltage outputs: Output VO0 Supervised (monitored) voltage output, 24V DC...
  • Page 74: Output Programming

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Output programming Output programming is done in WinG3. See the WinG3 dialog box respectively. See also WinG3 help. 13.1 Type of output Some output types can be collective disabled. Some output types can when activated, be indicated by an LED.
  • Page 75: Logic

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 13.2 Logic (•) Normally open / low Normally open relay contact or normally low voltage output. ( ) Normally closed / high Normally closed relay contact or normally high voltage output (24V DC).
  • Page 76 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Regarding the programming, see chapter "Output Signal Periods", page 138. Figure 13. Delay time, Pulse length, Pulse off and/or De- Activation, have to be set for the type respectively.
  • Page 77 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x In EBL512 G3 COM loop units Output S0-S3 4581 4583 I/O unit Unit Siren, 4582 Inter S/B & 3361 3364 board locking board board...
  • Page 78: Control Expression

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 13.5 Control expression Each programmable output has to be given a control expression. It is created by so called Boolean algebra. Trigger conditions (see "Available functions"), logical "Operators"...
  • Page 79 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Heavy Smoke Alarm Zone (+Zone no.) Heavy Smoke Alarm Zone Address (+Zone no.+Address) General Heavy Smoke Alarm Consecutive Heavy Smoke Alarm (sequence) (+start Zone no. and address +stop Zone no. and address +Quantity) Two Address Dependent Fire Alarm (+Zone no.
  • Page 80 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Comments to the trigger conditions (functions): Fire alarm. For more information regarding fire alarm, see EBL512 G3 Operating Instructions MEW01163. See 1. See 1.
  • Page 81 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Routing equipment output (Fire brigade tx) is disabled. The specified zone is disabled. The specified alarm point (zone/address) is disabled. One or more alarm points (zone/address) are disabled.
  • Page 82: Logical Operators

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x "Control, neutral". See also chapter "Fire Door Closing", page 88. Service signal is activated (by any sensor). This control expression is true when the control unit standard output "Fire brigade tx"...
  • Page 83 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x y is true (=1) when all the conditions a, b, c are true, i.e. a=1 and b=1 and c=1 makes y=1. All other combinations makes y=0.
  • Page 84 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 13.5.3.3 Inverts a condition, e.g. NOT b = NOT 0=1. a OR NOT b AND c = y This is shown in the following table: 13.5.3.4...
  • Page 85 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Here follows some examples (and explanations) to show the principles how to build a control expression with "conditions" and logical operators.): Example 1 Output:...
  • Page 86: Interlocking Function

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Interlocking function The interlocking function is used to verify that an output really is activated, i.e. by "combining" an output with an input (feed-back from the equipment controlled by the corresponding interlocking output).
  • Page 87 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Figure 16. WinG3 "Interlocking Combination" dialog box. Name: Displayed in the WinG3 Tree and List views. Default is "Interlocking Combination" that can be edited when wanted / required.
  • Page 88: Interlocking Indications

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Buzzer checked = activated interlocking input will turn on the c.i.e. buzzer (0.8 / 0.8 sec.) . The buzzer can be silenced. It will be automatically turned on again, if a new interlocking input is activated.
  • Page 89: Activate Interlocking Output (H9/C2)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Use "↑" "↓" to scroll between several interlocking combinations. 14.3.2 Activate interlocking output (H9/C2) Even if the control expression for an interlocking output is not fulfilled (true), the output can be manually activated via this menu.
  • Page 90: Fire Door Closing

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Fire Door Closing Programmable outputs can be used for fire door closing. A special trigger condition is available (Fire Door Closing.). Type of output is normally "Control, neutral".
  • Page 91: Functions / Services / Features

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Functions / Services / Features Some Functions / Services / Features require programming in WinG3, see chapter "PC software (S/W)", page 15. For more information see also EBL512 G3 Operating Instructions MEW01163 and WinG3 help.
  • Page 92: Decision Value

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Sensor value Obsc. in % / m Fire alarm level (C) Sensor value (A) Fire alarm Constant Service signal offset 3.0 % sensitivity given...
  • Page 93: Alarm Algorithm / Alternative Alarm Algorithm

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The pre-warning offset and the heavy smoke alarm level can, for the whole system, be set in WinG3, see chapter "Alarm algorithms", page 136. See also WinG3 help.
  • Page 94: Filtering Algorithm

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.4.2 Filtering algorithm In order to secure a fast detection of real fire alarms and to reduce nuisance (false) alarms to a minimum, a filtering algorithm is used.
  • Page 95 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Figure 19. An example of the filtering algorithm for an Analog smoke detector with the step value X = 5. The polling time (t) in this example is approx.
  • Page 96: Smouldering Smoke Algorithm

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The decision value has here reached the pre-warning level and pre-warning is activated. The decision value is here below the pre-warning level and the pre-warning is automatically reset.
  • Page 97: Performance Factor

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Figure 20. An example of the smouldering smoke algorithm for an Analog smoke detector 4301. Explanations to the figure: In this example, the week average sensor value and the decision value are "10"...
  • Page 98: Algorithms For Analog Heat Detectors

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x and max. sensor values. All three values should be studied together. (E.g. one or two high sensor values will not result in a high performance factor.) The performance factor is calculated for each...
  • Page 99: Class A1 Algorithm

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.6.1 Class A1 algorithm Conforms to Class A1. Typical / max. application temperature 25 / 50° C. Max. / min. static response temperature 54 / 65° C.
  • Page 100: Minimum / Maximum Sensor Values

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x FAULT: Loop unit xxx-xx Technical number xxxxxx 16.8 Minimum / Maximum sensor values To find out how the environment is, where an analog detector 33xx / 430x (in NORMAL mode) is mounted, the minimum and maximum sensor values can be studied.
  • Page 101: 2-Zone / 2-Address Dependence (Co-Incidence Alarm)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.9 2-zone / 2-address dependence (Co- incidence alarm) In some premises 2-zone or 2-address dependent fire alarm ("Two unit dependent" in WinG3) can be used to avoid unwanted / false alarms (nuisance alarms).
  • Page 102: 2-Address (-Unit) Dependence

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.9.2 2-address (-unit) dependence Each analog detector, addressable multi purpose I/O unit (3361) monitored Input 0 (Z) and 8 zones expansion board (4580) input, can be programmed for 2-unit dependent fire alarm activation.
  • Page 103: Delayed Alarm

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.10 Delayed alarm In some premises delayed fire alarm activation can be used to avoid unwanted false alarms (nuisance alarms). The delay time will be added at the end when a fire alarm normally would have been activated in the c.i.e.
  • Page 104: Alert Annunciation

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.12 Alert Annunciation In some installations the Alert Annunciation function can be used to avoid unwanted false alarms (nuisance alarms) to the fire brigade. A time channel can turn on/off this function.
  • Page 105 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The AA alarm has to be acknowledged within an acknowledge time and the AA alarm has to be reset within an investigation time, else the output(s) for routing equipment (fire brigade tx) will be activated.
  • Page 106: Alarm Acknowledgement Facility (Aaf)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.13 Alarm Acknowledgement Facility (AAF) This facility is used on the Australian market only. The AAF function is similar to the "Alert Annunciation function" (see page 102).
  • Page 107 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Quiscent state Any detector in alarm? Buzzer ON AP timer starts Detector LED ON AAFC LED ON AAFC button pressed? IP timer starts Buzzer OFF...
  • Page 108: Quiet Alarm

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The detectors in an AAF zone can be one to five and not be programmed as 2-unit-dependent and not be controlled by the Alert Annunciation function.
  • Page 109: Fire Alarm Type B

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x If a fire alarm type A is received, the probability of a real fire is higher than for a fire alarm type B. The alarm receiver can take different actions depending on if it is a type A or B fire alarm.
  • Page 110: Disable Zone

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x shall not be selected, see chapter "System properties, Page 2", page 133. NOTE! Enhanced Disablement is NOT valid when a time channel is used for disablements, only when menu H2/B1 or B2 is used.
  • Page 111: Disconnect & Re-Connect Loop / Zone Line Input

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.19 Disconnect & Re-connect loop / zone line input Disconnected via menu H8/S1 and Re-connected via menu H8/S2: COM loop Zone line input Addr. zone interface (3361 zone line input) For more information see EBL512 G3 Operating Instructions MEW01163.
  • Page 112: Test Of Routing Equipment

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x devices. (The test cannot be started if fire alarm already is activated in the system.). One or all control units can be selected. When the test starts the alarm devices will be "on"...
  • Page 113: Fault Signal (Fault Condition)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x (nuisance alarms) since all conventional smoke detectors (except 4350, see page 123) have a fixed fire alarm level. Conventional smoke detectors have no service signal output and have to be replaced on a regular basis (i.e.
  • Page 114 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x In the dialog box for any alarm point (e.g. a detector/sensor) , there is a "Text" field where the alarm text for that alarm point can be typed (or edited).
  • Page 115: Downloading Alarm Texts To The Du:s 1728 / 1735 / 1736 And Ext. Fbp:s 1826 / 1828

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x NOTE! If any alarm point shall have a different alarm text in one or more of the "display units" 1826, 1828, 1735, 1736 or 1728 , the text has to be typed in the WinG3 "Text editor", for the "display unit"...
  • Page 116: Daylight Saving Time

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 16.28.1 Daylight saving time The time is automatically changed when the Daylight saving time period starts and stops respectively, if set so in WinG3. When, is depending on which convention that is used: ...
  • Page 117: Wing3 Menu Tools

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The sounders will remain turned ON until they are turned OFF by pressing the soft key "Evacuate off" (P7). NOTE 1! The alarm devices (sounders) will always be activated steady (sound continuously) irrespective of the fact that the outputs can be set to anything else for fire alarm (e.g.
  • Page 118 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Backup SSD: (When connected and logged on to an EBL512 G3.) For backup (upload) of SSD from all the EBL512 G3 control units and connected Display Units (e.g.
  • Page 119: Special New Zealand Functions

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Special New Zealand functions NOTE! The functions in this chapter are valid for the New Zealand convention only. 17.1 Alarm devices 17.1.1 Silence alarm devices (inside switch) On the c.i.e.
  • Page 120 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The outside switch is turned OFF (i.e. from activated to not activated state).  "FAULT: Silence switch active " will be Serviced.  Any fire alarm ("ALARM") and acknowledged alarm ("ACKNOWLEDGED") will automatically be disabled /...
  • Page 121: Battery Faults

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  Programmable outputs not activated.  Output for routing equipment (Fire brigade tx) not activated. 17.2 Battery faults For other conventions, see chapter "Security functions", page 153.
  • Page 122 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x An acknowledged alarm has the same functionality as a normal fire alarm except for the indication in the c.i.e. display. In the fire alarm list (presented in the display) will "ALARM" be changed to "ACKNOWLEDGED".
  • Page 123: Cyber Sensor Functions

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Cyber sensor functions The latest generation of detectors are called "Cyber sensors". The Cyber sensor "family" consists of the following detectors:  Conventional photoelectric smoke detector 4352 ...
  • Page 124: Pulse Up - Down Counter

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Pulse up – down counter 18.1 The detector have a "pulse up – down counter", starting at "0" and cannot be negative. Pulse up – down counter for smoke 18.1.1...
  • Page 125: Alarm Threshold Levels

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x activated. 4301: Fire judgement is depending on other alarm and filtering algorithms (see chapter "Functions / Services / Features", page 89). 4300: Fire judgement is depending on other alarm and filtering algorithms (see chapter "Functions / Services / Features", page 89).
  • Page 126 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  Cooking condition, depending on the occurrence of smoke together with rise of temperature, i.e. level 3 = 2S+deltaT > 10. NOTE! S has to be > 2.5 and deltaT has to be > 3.
  • Page 127: Alarm Delay Time

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 18.4.1.4 Clean condition, level 1, 2 & 3 For this learning condition to be adapted there must be no check-mark for level 1, level 2 and level 3 respectively during the learning period, i.e.
  • Page 128: Analog Data Output

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x data1 = The average smoke obscuration value (S) for 60 seconds before the alarm threshold level was passed. data2 = The sum of the difference between the smoke obscuration value (S) and the alarm threshold level every second for nine seconds after the counter shows "9".
  • Page 129: Self Diagnosis Of Internal Devices

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x filtering algorithms (see chapter "Functions / Services / Features", page 89). 18.8 Self diagnosis of internal devices The detectors perform an internal check of some vital functions and components (e.g.
  • Page 130: Control Unit Properties

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Control unit properties Figure 25. The WinG3 "Control unit properties" dialog box. NOTE! Default settings in WinG3 might vary depending on convention. 19.1 Control unit properties dialog box Opens when you add a control unit or via the "Control unit"...
  • Page 131: Wing3 Control Unit Pop-Up Menu

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Set the wanted number and the validation check in WinG3 can give a "too many alarm points" warning. The validation check is automatically performed when starting a download of SSD to the c.i.e.
  • Page 132: Restart

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Click "Read" for the current number of alarm points and the serial number for the control unit you are connected to. If the number of alarm points shall be changed, report the serial number to the producer, in order to receive a password.
  • Page 133: System Properties (Settings)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x System properties (settings) Figure 26. The WinG3 "System properties" dialog box, Page 1 and Page 2. NOTE! Default settings in WinG3 might vary depending on convention.
  • Page 134 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 20.1.3.2 Alarm Acknowledgement Facility Used in conjunction with the AAF Control that is available on the Australian market only. See also chapter "Alarm Acknowledgement Facility (AAF)", page 104.
  • Page 135: System Properties, Page 2

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 20.1.3.5 Alarm delay time (seconds) Valid for the detectors and zone line inputs with this option selected via WinG3 0 is default. 0-255 seconds is possible. Note, this delay time starts when the fire alarm normally should have been activated.
  • Page 136: Menu System

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Enhanced disablements: Disabled alarm point will not  activate pre-warning, fire alarm or fault. Checkbox not marked = Disabled alarm point will not activate pre-warning or fire alarm.
  • Page 137 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  disable, re-enable and activate programmable control outputs  set alternative alarm algorithm for analog detector types 430x on / off  set 2-unit dependence function on / off The properties for each Time channel (2-14) and each Day of the week (Monday –...
  • Page 138: Alarm Algorithms

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x A time interval can be copied in one day field and pasted into another day field. Tuesday: Programmed the same way as the Monday.
  • Page 139 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Figure 28. Smoke algorithm N-15 for 4301, Heat algorithm Class A1 for 3308 and Combined Decision algorithm Dec for 4300 respectively. Detector: Shortening and Type number (e.g. OPT 4301 = Analog photoelectric (optical) smoke detector, AHD 3308 = Analog heat detector and AMD 4300 = Analog Multi Detector).
  • Page 140: Output Signal Periods

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x In addition, a special password is required to change the parameters for fire alarm. 20.2.3.2 Parameters for heat algorithms The "alarm" levels are fixed, i.e. there are no offset values. The sensor values can be 0-200, which is equivalent to 0-100°...
  • Page 141: National Holidays

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x In the list (to the left), Steady (continuously) and Intermittent 0.8 / 0.8 s are already defined since these alternatives are often used. It is however, possible to define them to something else.
  • Page 142: Two Zone Dependence

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Up to twenty national holidays can be set for the whole system. National holidays can be added one by one, i.e. by selecting a date in the calendar (up to the right) and click with the left mouse button.
  • Page 143: Statistics (System Information)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Default for all zones is no two zone dependence. NOTE! Normally, only conventional zones (i.e. zone line inputs with conventional detectors) should be used for two-zone dependence.
  • Page 144: Compatibility

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Compatibility Regarding backwards compatibility:  Addressable short circuit isolator 4370 is compatible with Addressable short circuit isolator 4313. NOTE! In system EBL512 G3 shall all Addressable short circuit...
  • Page 145: Cable Types

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Cable types A fire alarm installation is a safety installation and it is important that the cables used are of correct types and according to national regulations, e.g.
  • Page 146: Alarm Device Cables

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 22.5 Alarm device cables Alarm devices (sounders, etc.), see dwg. 512 G3 – 23, – 35 and – 38. ELQRB 2 x 0.6 mm (0.3 mm ) or equivalent.
  • Page 147: Com Loop Cable Length

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x COM loop cable length The cable length and max. COM loop current, are depending on the number and type of loop units and the cable type, see Figure 30 and Figure 31, page 146 and 147 respectively.
  • Page 148 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Maximum conductor resistance 2 x 1 mm (0.75 mm 24.5 ohm / km Total COM loop unit current consumption Figure 30. Graphs showing the total conductor resistance in relation to the COM loop units' total current consumption.
  • Page 149 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Maximum cable length Meter 2 x 1 mm (0.75 mm 24.5 ohm / km Total COM loop unit current consumption Figure 31. Graphs showing the cable length in relation to the COM loop units' total current consumption.
  • Page 150: Current Consumption

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Current consumption The different loop units have different current consumption. Note that some units have much higher current consumption in "active state". To check the current consumption on the COM loops, cable lengths, etc.
  • Page 151 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x COM loop units (input / display units) Normal state Alarm state (quiescent) (mA) (activated) (mA) Analog heat detector 3308 + analog base 3312xx Analog heat detector, enclosed 3309...
  • Page 152 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Other units Normal state Alarm state (quiescent) (mA) (activated) (mA) Routing equipment (Fire brigade tx / Fault tx) Acc. to the producer Acc. to the producer...
  • Page 153 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The following table is a help when calculating the cable length and/or the number of units. The table is based on the current consumption at the lowest power supply voltage allowed i.e.
  • Page 154: Power Supply

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Power supply Main power source Normally the EBL512 G3 control unit is powered by the built-in rectifier (230 V AC / 24 V DC ±1%, 6.5 A).
  • Page 155: Charger Functions

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x 25.1 Charger functions According to EN54-4, section 5.3.1 b): The charger shall be designed and rated so that a battery discharged to its final voltage can be recharged to at least 80% of its rated capacity within 24 hours and to its rated capacity within another 48 hours.
  • Page 156: Current Consumption Calculations

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x  In order to not damage the batteries, the voltage output will be switched off at approx. 20.8 V. This only happens in case of no main power source (230 V AC), i.e.
  • Page 157: Rectifier (Main Power Source)

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x has to be < 6.3 A. (The battery charging will be turned off in conjunction with fire alarm activated in the system.) For the total EBL512 G3 current consumption in relation to backup time, see tables in chapter "Battery (second power source)", page 155.
  • Page 158: Fuses

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x The relation between the total current consumption in normal state (I ) and the backup time. One table for the built-in 28 Ah batteries and one table for the external 65 Ah batteries: NOTE! Theoretical values.
  • Page 159 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x shall be used to read a true value instead of a calculated current consumption. A tip: Turn off the main power source (230 V AC) and use e.g. a "clamp current meter"...
  • Page 160: W Versions

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x S/W versions Due to continual development and improvement, different S/W versions can be found. Different S/W versions can be found on different markets. The S/W versions listed below were the valid ones when this document was written (the date of this document or date of revision).
  • Page 161: Technical Data

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Technical data Voltage Primary (V AC): 230 (176-264) -- 1.6 A System (V DC): 24 Current consumption (A) Quiescent / active: Depending on type (5000 or 5001), type and number of exp.
  • Page 162: Limitations

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Limitations See also "Control Unit / TLON Network", page 17. 28.1 User definable texts At least 617 "User definable texts" can be programmed per c.i.e. The texts are to be distributed amongst the following: ...
  • Page 163 Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Item C.i.e. System General fire alarm via progr. input External fault via progr. input Programmable outputs (= control expressions) Addressable 2 voltage outputs unit...
  • Page 164: National Regulations

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x National regulations When planning a fire alarm installation, national regulations, customer demands, etc. have to be followed. EBL512 G3 is very flexible. Many functions / facilities are built-in the system, e.g.
  • Page 165: Drawings / Connection Diagrams

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Drawings / connection diagrams Resulting from continual development and improvement, all dimensions quoted are approximate only and subject to change without notice, as are other technical features and data.
  • Page 166: Revision History

    Panasonic Electric Works Nordic AB MEW01351 Rev: - Planning Instructions Fire alarm system EBL512 G3, V1.1.x Revision history...
  • Page 167 This page has deliberately been left blank.
  • Page 168 Panasonic Electric Works Nordic AB Jungmansgatan 12, SE-211 19 Malmö, Sweden Tel: +46 (0)40 697 70 00 • Fax: +46 (0)40 697 70 99 info-fste@eu.pewg.panasonic.com • www.panasonic-fire-security.com...
