- Page 1 Commercial Thermostats Get Control. Get Honeywell. Application Selection and Cross-Reference Guide PneumatiC webStat Controller t7350 t7351F CommerCial ViSionPro 8000 CommerCialPro 7000 multiPro 7000 ZonePro Fan Coil line Volt ® ® ® ™ ®...
- Page 2 The Innovative Leader For more than a century, Honeywell has been on the leading edge of product development for energy-efficient HVAC and building automation products. Contractors and building owners count on Honeywell commercial thermostats for the latest technology, ease-of-use and energy savings.
- Page 3 WebStat Controller ® Web Accessible Thermostats • Honeywell’s WebStat system is composed of the ® world-class T7350H L communicating ® orks thermostats combined with a single WebStat controller which enables your network of T7350H thermostats to be configured and monitored from any computer with internet access from anywhere in the world.
-
Page 4: Communicating Thermostat
– Outdoor Air and Discharge Air Temperature Lockout • Controls up to 3H/3C or 2H/4C conventional systems or 3H/2C heat pumps (T7350H1009) – Flexibility allows the same thermostat to be used on every RTU in the system • Has two 4-20 modulating outputs for controlling Compatible with these Honeywell Systems heating and cooling valves (T7350H1017) – Allows thermostat to be used in hydronic LCBS XL15B W7760B2001 LonSpec /LonStation ™... - Page 5 T7350M Modulating and Staged Thermostat • Integrated humidity sensor – Several strategies for dehumidifying • 365-Day Schedule – Schedule holidays throughout the year to save energy • Remote sensing – Indoor, outdoor, humidity, occupancy and discharge air sensors available for added flexibility – Outdoor Air and Discharge Air Temperature Lockout. • Has two 4-20 modulating outputs for controlling heating and cooling valves –...
- Page 6 T7350A, B, D Standalone Staged Thermostat • Integrated humidity sensor (T7350D) – Several strategies for dehumidifying • 365-Day Schedule – Schedule holidays throughout the year to save energy • Remote sensing (T7350B, D) – Indoor, outdoor, humidity, occupancy and discharge air sensors available for added flexibility – Outdoor Air and Discharge Air Temperature Lockout • Controls conventional or heat pump systems • Flexibility allows the same thermostat to be used on every top roof unit in the system • PID loop...
- Page 7 T7351F Standalone Staged Thermostat • Keypad programming – All configuration is done through the keypad • Integrated humidity sensor – Several strategies for dehumidifying • 365-Day Schedule – Schedule holidays throughout the year to save energy • Remote sensing – Indoor, outdoor, humidity, occupancy and discharge air sensors available for added flexibility – Outdoor Air and Discharge Air Temperature Lockout...
- Page 8 T7350/T7351F Applications Schools Restaurant/Food Service • Up to 10 holidays can be scheduled into the Holiday • PID Commercial Algorithm provides the best Scheduler, which can be programmed to handle multiple comfort control to react to the constantly changing days per holiday event, can program closed days food service and restaurant environments, reacting during the summer or spring break and can be quickly to changing load demands via fast-sensing programmed for specific calendar events. (All Models)
-
Page 9: Equipment Protection
Heat Pumps and reverse acting signals. (T7350M, H) • Outdoor Air Sensor automatically turns off heat pump Communicating Control equipment in cold climates. The T7350 is the only Honeywell thermostat that uses both an outdoor air • Using the Honeywell Command Display S7760A, the sensor and indoor sensors/wall modules for heat pump Honeywell LonStation front-end or the Honeywell XL15B ™... - Page 10 Commercial VisionPRO 8000 ® Programmable Touchscreen Thermostat • Touchscreen user interface – The sleek design, menu-driven programming and large touchscreen display are all here • Saves energy – Effortless programming helps your customers save up to 33% off their energy bill • Meets commercial building codes –...
- Page 11 CommercialPRO 7000 ® Thermostat • Large, easy-to-read display – Screen size is more than double competitive thermostats in this class, allowing for more information to be displayed on the easy-to-view backlit display • Saves energy – Easy-to-use, menu-driven programming helps your customers save up to 33% off energy bills • Meets commercial building codes –...
- Page 12 MultiPRO 7000 ™ Multispeed and Multipurpose Thermostat • Large, easy-to-read display – Screen size is more than double competitive thermostats in this class, allowing for more information to be displayed on the easy-to-view backlit display. • Programmable or non-programmable modes • Saves energy – Effortless programming helps your customers save up to 33% off their energy bill –...
-
Page 13: Program Details
Any change in the label will be treated as a new label creation and the approval process must be followed in total. Coordination will be required for the transition, including purchasing existing stock of customer parts. All private label requests must conform to the standards set by Honeywell. Honeywell reserves the right to deny any private label request as its own discretion. - Page 14 ® ® After-Hours Control in Office Buildings Condominiums/Hotels • The Override button can be configured for a length of • Honeywell’s MultiPRO™ thermostat uses the patent time (1, 2, 3, 4 hours) and can be configured for an exact pending VersaSpeed™ fan ramping algorithm to give override setpoint through the use of the lockout level multiunit facilities such as hotels, condos, dorms and set-up and the temperature range stop setup. A user may...
- Page 15 Applications ™ Remote Sensing Unit Vent Can be configured using Honeywell’s line of 10K ohm and • Can be programmed to control ASHRAE Cycle 1 unit vent 20K ohm commercial sensors, supporting the following applications. applications that residential thermostats don’t: • Unit vent outside-air damper can be programmed through • Temperature Averaging Networks the Economizer feature. When the unit vent is on and Because commercial thermostats can be configured occupied, the thermostat will enable the economizer...
-
Page 16: Humidity Sensors
T7770D1000 — 20K Sensor with override button TIM, which automatically transmits it to the T7350. Simply download the T7350 program software at T7771A1005 — 20K or 10K Sensor with setpoint customer.honeywell.com onto the Palm. Once the buttons and override button T7350 is configured on the Palm, it can be beamed C7772A1012 — 20K Flush mount sensor via the infrared port to the I/R TIM. -
Page 17: Compatible Sensors
Compatible Sensors Honeywell has a full line of sensors that are compatible with our commercial thermostats. remote room Sensors TR21 TR21-A 10K Averaging TR22 20K, ±5° Setpoint Adj. TR23 20K, ±5° Setpoint Adj. & Bypass TR24 20K, Bypass T7771A1005 10K/20K, ±3° Setpoint Adj. & Bypass C7770A1006 Return Air Duct C7041P2004 Button C7189U1005 Remote Indoor T7771A1005 TR21 C7772A1012... - Page 18 ZonePRO ® Commercial Modulating Zoning Thermostat • Good looks – Many thermostats used for this application look very outdated • Price – Very cost-effective alternative to an expensive networked zoning system • Flexibility – Has more features and fits more applications than other thermostats in this market (setback input, additional analog and triac output on the B models)
- Page 19 ZonePRO Applications ® Stand Alone VAV Pressure Hydronic Control & Dependent (VVT Zoning) Control Modulating Heating • Typical building applications include zoning for office • Can be used for modulating hydronic heating or buildings, airports, strip-malls and multi-tenant facilities cooling applications. that have multiple terminal zones that run off of a single • Other common applications include radiant panel air-handler.
- Page 20 Honeywell Thermostat Cross-Reference Chart USER MODEL SCHEDULE OPTIONS APPLICATION INTERFACE 3 Heat / 3 Cool 3 Heat / T7350H1009 365-Day • • Soft Keys • 2 Cool 2 Heat / 4 Cool Communicating T7350H1017 365-Day • • Soft Keys • 4-20 mA...
- Page 21 POWER SENSOR FEATURES AND FUNCTIONS DISPLAY INFORMATION METHOD COMPATIBILITY Indoor, Outdoor, 24 VAC • • • • • • Discharge, 4.2 sq. in. • Humidity, Occupancy Indoor, Outdoor, 24 VAC • • • • • • Discharge, 4.2 sq. in. •...
- Page 22 Line Volt • Simple interface for control of line voltage heaters – Easy for occupants to read and change setpoints T651A3018 — Degree F scale, for heavy-duty line voltage heating systems T651A3026 — Degree C scale, for heavy-duty line voltage heating systems T451A3005 — Degree F scale, for light-duty line voltage heating systems Pneumatic • Large replacement market – Large installed base, popular proven design for pneumatic systems Go to customer.honeywell.com for a list of all model numbers and accessories.
- Page 23 Notes...
- Page 24 Learn More For more information on Honeywell Commercial Thermostats, contact your local Honeywell authorized distributor, call 1-763-954-6464 or visit customer.honeywell.com. Automation and Control Solutions In the U.S.: Honeywell 1985 Douglas Drive North Golden Valley, MN 55422-3992 In Canada: Honeywell Limited 35 Dynamic Drive Toronto, Ontario M1V 4Z9...
