Dell V505 All In One Inkjet Printer Information Manual

1
Unpack your printer, and remove all tape and packaging
material from the printer. (USB cable sold separately.)
5
To send and receive faxes, connect an active telephone line into the FAX connector ( ). If you are using a DSL modem for your computer, your
must install a DSL filter. Contact your DSL provider for assistance.
Back
Cancel
x
8
Use the arrow buttons and the keypad to specify your language, country, date, time, fax number, and fax name. Press the Select button
each setting. If you need to reset the language, hold the Back
, , ,
( ) .
.
0GY346A00
Setting Up Your Printer
| |
CAUTION:
Before you set up and operate your Dell printer,
™
see the safety instructions in your printer Product
Information Guide. Also, see your User's Guide for
a complete list of features.
2
Use the orange tape to raise the operator panel until it snaps
into place. Remove, and then discard the tape.
Fi &@$ ABC DEF
1 2 3
DELL V505
GHI JKL MNO
Pause ,
4 5 6
PQRS TUV WXYZ
Start
7 8 9
*
0
#
and Start buttons while turning the power on.
, .
( ) ( )
. .
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m
3
Raise the paper support, extend the paper tray, and then raise
the paper stop.
6
Connect the power cord to the power supply on the back of your
printer, and then connect the power cord to the wall.
9
to save Open the printer unit. The ink cartridge carrier moves to the
center. Remove the tape from both carriers.
.
4
Load plain paper in the paper support, and adjust the
paper guide.
Fi
&@$ ABC DEF
1 2 3
DELL V505
GHI JKL MNO Pause ,
4 5 6
PQRS
Back Back Start TUV TUV WXYZ WXYZ
7 8 9
Cancel Cancel
*
x 0 #
7
Press the Power button on the operator panel to turn on
your printer.
10
Remove the tape from the ink cartridges, and then install them
(black or photo on the left and color on the right).
