Status
Codec
PeerID
Connect Time
Tx Pkts
Rx Pkts
Rx Losts
Rx Jitter
In Calls
Out Calls
Speaker Gain
Log
3 . 1 2 I S D N
3 . 1 2 I S D N
ISDN means integrated services digital network that is an international communications
standard for sending voice, video, and data over digital telephone lines or normal telephone
wires.
Below shows the menu items of ISDN for i models.
for the physical ISDN port. Be aware that ISDN1/2 port is
available for the users living in Europe and using Vigor
2910VGi only. For other V models, only the status for VoIP1
and VoIP2 will be shown in this page.
It shows the VoIP connection status.
IDLE - Indicates that the VoIP function is idle.
HANG_UP - Indicates that the connection is not established
(busy tone).
CONNECTING - Indicates that the user is calling out.
WAIT_ANS - Indicates that a connection is launched and
waiting for remote user's answer.
ALERTING - Indicates that a call is coming.
ACTIVE-Indicates that the VoIP connection is launched.
Indicates the voice codec employed by present channel.
The present in-call or out-call peer ID (the format may be IP
or Domain).
The format is represented as seconds.
Total number of transmitted voice packets during this
connection session.
Total number of received voice packets during this connection
session.
Total number of lost packets during this connection session.
The jitter of received voice packets.
The accumulating in-call times.
The accumulating out-call times.
The volume of present call.
Display logs of VoIP calls.
