Introduction
The Model T10043 38" Lawn Sweeper features
four rows of bristle brushes, a large capacity leaf
bag that swings up for dumping, adjustable height
settings, and a universal hitch for towing behind
any riding lawn mower.
Tools Needed for Assembly
•
10, 13, 14mm wrench and/or socket.
•
Awl or similar tool.
•
Crescent wrench (optional).
•
Read the vehicle and sweeper owner's
manuals and know how to operate your
vehicle and sweeper before using this
sweeper attachment.
•
Maximum speed limit while towing this
sweeper is 6mph.
•
Do not allow children or anyone without
proper training to operate the sweeper.
•
Do not use sweeper as a trailer for
carrying people or animals.
•
Keep all hardware tightened to be sure
the sweeper is in safe working order.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
To reduce the risk of injury when using this product:
COPYRIGHT © NOVEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JB10063 PRINTED IN CHINA
MODEL T10043
38" LAWN SWEEPER
INSTRUCTION SHEET
Figure 1. Model T10043 38" Lawn Sweeper.
•
Never attach the leaf bag dump rope to
any part of your body or clothing. Do
not hold onto the rope while towing the
sweeper.
•
Attach the leaf bag dump rope to the
towing vehicle and make sure it is kept
away from wheels and rotating parts.
•
If an object becomes lodged in the
sweeper, do not attempt to remove it
while the sweeper brush is moving.
•
Only use the hitch for towing the trailer.
Do not attempt to use rope or chain for
towing.
Advertisement
Related Manuals for Grizzly T10043
Summary of Contents for Grizzly T10043
- Page 1 COPYRIGHT © NOVEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #JB10063 PRINTED IN CHINA...
- Page 2 Unpacking After all the parts have been removed from the box, you should have the following items: Box Contents (Figure 2) A. Leaf Bag (Not Shown) ........ 1 B. Sweeper Assembly ........1 C. Leaf Bag Dump Rope ......... 1 D.
- Page 3 Assembly Flat Hitch Bracket Hex Bolts Attach the hitch tubes to the sweeper assem- bly as shown in Figure 5. Do not tighten the hardware at this time. Refer to the inventory figures on Page 2 for hardware identifica- tion. Note: Make sure the rear ends of the hitch tubes angle slightly upward, as shown in Figure 5, Detail A.
- Page 4 Assemble the height adjustment lever, as Insert the upper bag tube through the pocket shown in Figure 9. Refer to the inventory fig- in the leaf bag and into the rear bag tube, ures on Page 2 for hardware identification. then secure it with a plastic plug, as shown in Figure 11.
- Page 5 11. Insert the two support rods between the Place the assembled lower leaf bag frame into the leaf bag and connect it to the upper upper and lower bag frame assemblies, as frame tubes with the M10 x 15 clevis pins shown in Figure 15.
- Page 6 Operations 13. Attach the leaf bag assembly to the sweeper assembly using an M6 x 33 clevis pin and a The Model T10043 can be raised or lowered to 2mm hairpin cotter pin, as shown in Figure achieve the optimal sweeping height for different 17.
-
Page 7: Maintenance
Maintenance Apply a few drops of light oil to the wheel bushings, as shown in Figure 22, and spin To prevent excessive wear, periodically lubricate the wheel to distribute the oil. Replace the the brush shaft bushings, the wheel bushings, washer, wheel nut, and the dust cap. - Page 8 Remove the retaining clip from the brush With extensive use, the brushes on the Model shaft, then remove the spacers (Figure 24). T10043 may become worn and require replace- ment. To replace the brushes: Tilt the sweeper all the way forward to allow easy access to the brushes.
- Page 9 T10043 Parts & Labels Breakdown T10043 38" Lawn Sweeper...
- Page 10 HEX BOLT M8-1.25 X 16 PT10043037 WHEEL DUST CAP PTLW17M INT TOOTH WASHER 5MM PT10043038 HEX BOLT M10-1.5 X 85 PT10043081 FRICTION WASHER 8MM PT10043039 SPACER BUSHING PT10043082 GRIZZLY 1-800 LABEL PT10043040 RATCHET GEAR RIGHT PT10043083 GRIZZLY.COM LABEL PT10043041 RATCHET GEAR LEFT...
