Grizzly T10042 Instruction Sheet

To reduce the risk of injury from using this
product:
• Do not allow anyone to operate the
sweeper without proper training.
• Do not allow children to use the sweeper.
• Always wear proper eye protection
when using the sweeper.
• If an object becomes lodged in the
sweeper, do not attempt to remove it
while the sweeper brush is moving.
• Keep all hardware tightened to be sure
the sweeper is in safe working order.
• Thoroughly inspect the sweeper for
damage after striking any foreign
objects.
Inventory (Figures 1 and 2)
A. Sweeper Assembly (not shown) ................. 1
B. Leaf Bag (not shown) ................................. 1
C. Long Bag Rod (27¼") ................................ 1
D. Short Bag Rod (25½") ................................ 1
E. Frame Handle ............................................. 1
F. Frame Legs ................................................ 2
G. Hex Bolts M6-1 x 30 ................................... 4
H. Lock Washers 6mm ................................... 4
I. Hex Nuts M6-1 ........................................... 4
J.
Carriage Bolts M6-1 x 30 ........................... 4
K. Lock Nuts M6-1 .......................................... 4
L.
Bag Clips .................................................... 4
M. Hairpin Cotter Pins ..................................... 2
N. Rubber Caps .............................................. 2
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
COPYRIGHT © NOVEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JB10062 PRINTED IN CHINA
MODEL T10042
26" LAWN SWEEPER
INSTRUCTION SHEET
D
C
E
Figure 1. Inventory 1.
G
H
I
J
K
Figure 2. Inventory 2.
F
M
N
L
