USER MANUAL FOR YOUR BAUMATIC BFD40W 45 cm freestanding dishwasher NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for you or any person not familiar with the operation of the appliance.
Contents Environmental note Important safety information 5 – 7 Specifications 8 - 9 Product dimensions Product specifications Energy efficiency details Electrical details 8 - 9 Description of the appliance Control panel Using your dishwasher 10 - 18 Before first use Filling with dishwasher salt 10 - 11 Setting the water softener level...
This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the...
General Safety o Repairs to your appliance must only be carried out by a Baumatic engineer or one of its authorised service agents. Any attempt by an inexperienced person to repair the appliance, could result in injury or damage to your dishwasher.
Page 6
This appliance is only designed to wash normal domestic washloads. If you use your dishwasher in any other way or it is incorrectly used, then Baumatic accepts no liability for any damage that might be caused and any guarantee will be void.
Page 7
Child Safety o Your dishwasher should only be used by adults. You should not allow children in the area of the machine unsupervised. You should not let them touch the controls or play with the appliance. o It could be possible for a child or pet to gain access to the dishwasher if the door is left open.
Specifications Product dimensions Height: 850 - 855 mm Width: 450 mm Depth: 600 mm Product specifications o 8 Place settings o 8 programs: Normal Intensive Economy Rinse Glass Rapid Soak 3 in 1 o 4 Wash temperatures: 40°C, 45°C, 50°C, 60°C o 4 Rinse temperatures: 45°C, 60°C, 65°C, 70°C o Self-cleaning stainless steel microfilter o Anti-leak device...
Supply connection: 13 A (double pole switched fused outlet with 3 mm contact gap) Description of the appliance Upper basket Cup shelf Spray arms Cutlery basket Lower basket Coarse filter Water softener Rinse aid dispenser Main filter Drain pipe connector Detergent dispenser Inlet pipe connector Control panel...
Using your dishwasher Before first use o Install the appliance as per the installation instructions contained within this booklet. o Fill the water softener with 1 litre of tap water and then fill with specialist dishwasher salt. After this you should set the water softener level.
o It is perfectly normal for a small amount of water to come out of the water softener, whilst you are filling it with salt. This does not mean that the water softener is filled with the correct amount of salt. o Refit and fully tighten the water softener cap.
o IMPORTANT: If you are using 3 in 1 dishwasher tablets and live in a medium or hard water area, then you should still fill the water softener with salt. The water softener arrow should be turned to the minus setting. Filling with rinse aid The rinse aid is released during the final rinse and it helps to prevent water from forming droplets on your dishes.
o If you get water spots and poor drying performance, then you should turn the arrow anticlockwise and increase the setting to the next number. o You should continue to adjust the rinse aid level upwards until you get no water spots. o If you get cloudiness or streaking on your dishes, the rinse aid level is set too high and it is causing foaming during the wash cycle.
Loading the upper basket The upper basket is most suited to washing delicate and light dishware, such as glasses, coffee & tea cups, saucers, plates, bowls and shallow pans (that are not heavily soiled). Cups Small serving bowl Large serving bowl Glasses Saucers Dish...
Page 15
Lower position o If the upper wheels are placed in the guide supports, then the basket is in the lower position. o For accommodating additional tumblers, cups and mugs. You can also place small, espresso sized cups on top of the side racks. You should take care to ensure that there is enough clearance between the top of the cups placed on top of the side racks and the underneath of the dishwasher interior.
IMPORTANT: Care should be taken to make sure that the spray arms can move freely when items have been loaded into the baskets. Loading the lower basket The lower basket is most suited to washing larger and more heavily soiled items, such as saucepans, saucepan lids and serving dishes. You can also load bowls and a variety of plates into the lower basket.
o For the best washing performance, cutlery should be placed through the slots in the top of the cutlery basket. IMPORTANT: Do not allow items of cutlery to fall through the bottom of the cutlery basket, as this may cause damage to the spray arm and/or the cutlery.
Page 18
The following items are NOT suitable for washing inside a dishwasher:- o Cutlery with a handle of mother-of-pearl, wood, horn or china. o Plastic items that are not resistant to heat. o Cutlery that consists of glued parts that are not resistant to heat. o Cutlery items or crockery that are bonded.
Program table Program Program Description Detergent Water Program information of cycle pre/main consumption time* (litres) 3 in 1 For normally Pre-wash 3 in 1 14.7 soiled loads, Pre-wash tablets minutes such as pots, Wash plates, glasses (45°C) and lightly Rinse soiled pans.
* The wash program times that are quoted are intended as a guide only. Please note that factors external to the machine, e.g. the temperature of your water supply, your water pressure etc. can affect the time it takes for the wash program to complete. ** Normal is the testing program for EN 50242.
o Press the Start/Reset button and the program indicator light will start to blink next to the wash program that you have selected. o After a few seconds, you will hear the appliance begin to fill with water and the new wash program will start. o IMPORTANT: You should only change a wash program if the detergent has not been released into the machine;...
The 3 in 1 wash program Make sure that the water softener has been filled with salt and that the water softener has been set to its lowest setting. Make sure that the rinse aid dispenser has been set to an appropriate level.
Cleaning and maintenance IMPORTANT: The appliance should be disconnected from your mains supply before commencing any cleaning process. The filter system Your appliance is fitted with three levels of filtering; these are located in the base of the dishwasher for ease of access. Main filter Coarse filter Fine filter...
Cleaning the filters For best performance and results, the entire filter assembly should be thoroughly cleaned regularly (ideally after each wash cycle). 1. Turn coarse filter anti-clockwise and then lift it upwards. Rinse out this section under a tap remove food debris that remains in it.
Cleaning the spray arms The spray arms should be cleaned regularly, to prevent hard water deposits from clogging the spray arm jets and bearings. o IMPORTANT: Remove the lower basket before attempting to remove the lower spray arm. o To remove the spray arms, unscrew the nut and take out the washer that sits on top of the spray arms.
Cleaning the door o To clean the edge around the outside of the door, you should use a soft, damp cloth only. o To prevent water from penetrating the door lock or electrical components, DO NOT use a spray cleaner of any kind. o DO NOT use any abrasive cleaner or scouring pads on the inner or outer surfaces, as they may cause damage to them.
Page 27
Longer heating time than normal but appliance not reaching the required temperature. Malfunction of temperature sensor or of the heating element. Call Baumatic Customer Care Department. Strong and normal indicator light flickering o Failure of temperature sensor Short circuit or malfunction of temperature sensor.
Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the...
Page 29
Motor hums If the dishwasher is not going to be used for a period of time, then you should make sure that the appliance is set on a wash program once a week. Otherwise the seal around motor may dry out and cause noise. Suds in the Spilled rinse aid Always wipe up any excess rinse aid...
Installation IMPORTANT: THIS INSTALLATION MUST COMPLETED BY A SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION INSTALLATION GIVEN THIS INSTRUCTION MANUAL. SHOULD DISPOSE PACKAGING ENVIRONMENTALLY FRIENDLY MANNER. Positioning and leveling the appliance Remove all packaging from the outside and inside of the dishwasher.
Adjust each of the four feet until the appliance is level. IMPORTANT: When the dishwasher is positioned in the location where it will be used. Make sure that all four feet are resting firmly on the floor, by pressing down on each corner and checking that the appliance stands still.
Water outlet Secure the drain hose, so that it cannot move whilst the dishwasher is in use. Place the end of the drain hose on your drain pipe. Push it a short way down into your drain pipe. IMPORTANT: Do not insert the drain hose too deeply into the water pipe, as this may cause siphoning.
Consult the rating plate, located on the right hand side of the drop down door BEFORE making the electrical connections. Ensure that the voltage reaching the plug is the same as that on the rating plate. REMOVE RATING PLATE INFORMATION ON IT IS IMPORTANT. The moulded plug that is supplied with the appliance must be placed into an earthed and insulated socket.
