BAUMATIC
BFD62W – DISHWASHER
60CM FULL HEIGHT DISHWASHER
INSTRUCTION MANUAL
CAREFULLY READING IT BEFORE USING THE DISHWASHER WILL HELP
YOU USE AND MAINTAIN THE DISHWASHER PROPERLY.
09/01/06
Advertisement
Table of Contents
Related Manuals for Baumatic BFD62W
Summary of Contents for Baumatic BFD62W
- Page 1 IMPORTANT! PLEASE READ THIS MANUAL AND KEEP IT FOR FUTURE REFERENCE! THIS MANUAL CONTAINS SECTIONS OF SAFETY INSTRUCTIONS, OPERATING INSTRUCTIONS & TROUBLESHOOTING TIPS, ETC. BAUMATIC BFD62W – DISHWASHER 60CM FULL HEIGHT DISHWASHER INSTRUCTION MANUAL CAREFULLY READING IT BEFORE USING THE DISHWASHER WILL HELP YOU USE AND MAINTAIN THE DISHWASHER PROPERLY.
-
Page 2: Table Of Contents
BAUMATIC BFD62W dishwasher user manual CONTENTS • SAFETY FIRST! SAFETY INFORMATION .……………..…………3 *Please read this before using your dishwasher! • KNOWING YOUR DISHWASHER BEFORE CALLING FOR SERVICE CONTROL PANEL ………………………..……..…4 DISHWASHER FEATURES …………..………….4 REVIEWING THE SECTION ON TROUBLESHOOTING TIPS WILL HELP YOU SOLVE SOME •... -
Page 3: Important Safety Information
COMPARTMENT OF YOUR OLD APPLIANCE BEFORE DISCARDING IT. • DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR AN AUTHORISED AGENT OF BAUMATIC SHOULD CARRY OUT REPAIRS ON THIS UNIT. • DO NOT USE IF THE SUPPLY CORD IS DAMAGED. •... -
Page 4: Control Panel
BAUMATIC BFD62W dishwasher user manual CONTROL PANEL STOP STOP STOP Power On light: Comes on when the ‘ON / OFF’ Button is pressed down. Rinse Aid Warning Light: Comes on when the rinse aid needs refilling. Salt Warning Light: Comes on when the softener needs refilling. -
Page 5: Loading Salt Into Salt Container
BAUMATIC BFD62W dishwasher user manual Note on chemicals used by the dishwasher • Your dishwasher is equipped with an adjustable rinse aid and salt container. Using individual detergents, rinse aid and salt will give the best possible results as this will give the correct dosage of each chemical to suit your needs. -
Page 6: Detergent
BAUMATIC BFD62W dishwasher user manual SETTING THE WATER SOFTENER LEVEL YOU CAN ADJUST THE AMOUNT OF SALT USED BY THE DISHWASHER TO SOFTEN WATER TO GET THE BEST WASHING RESULTS, BASED ON THE HARDNESS OF WATER IN YOUR AREA. THERE IS A RING ON THE NECK OF THE CONTAINER. -
Page 7: Rinse Aid
BAUMATIC BFD62W dishwasher user manual • THE RINSE AID IS RELEASED DURING THE RINSE AID FINAL RINSE TO PREVENT WATER FROM FORMING DROPLETS ON YOUR DISHES THAT CAN CAUSE SPOTS AND STREAKS. IT ALSO IMPROVES DRYING BY ALLOWING WATER TO FALL OFF THE DISHES. -
Page 8: Loading Your Dishwasher
BAUMATIC BFD62W dishwasher user manual LOADING NOTE: YOUR FOR BEST PERFORMANCE, FOLLOW THESE LOADING GUIDELINES. FEATURES AND DISHWASHER APPEARANCE OF RACKS & CUTLERY BASKETS MAY VARY FROM YOUR MODEL. BEFORE LOADING! • REMOVE ALL SCRAPS OF FOOD. • EMPTY DRINKS & LIQUIDS FROM CUPS. -
Page 9: Loading Guide (Upper Rack)
BAUMATIC BFD62W dishwasher user manual Note: Do not wash stainless steel and silver cutlery together. Iron objects can rust and stain other items. Aluminium tends to go black. Copper, pewter & brass stain. HOW TO USE THE UPPER RACK THE UPPER RACK IS FOR MORE DELICATE... -
Page 10: How To Load The Lower Rack
BAUMATIC BFD62W dishwasher user manual THERE ARE 4 (2 ON EACH SIDE). THESE CAN BE ADJUSTED INTO 2 POSITIONS = POSITION 1 (HIGH) AND POSITION 2 (LOW). TO MOVE THE FLAPS BETWEEN THESE POSITIONS, FIND THE LARGE HINGES CLASPING EACH FLAP TO THE UPPER RACK. -
Page 11: Cutlery Basket
BAUMATIC BFD62W dishwasher user manual CUTLERY BASKET CUTLERY SHOULD BE PLACED IN THE CUTLERY BASKET WITH HANDLES ALWAYS POINTING DOWNWARD (AT THE BOTTOM). VERY LONG UTENSILS (LADLES, etc.) SHOULD BE PLACED HORIZONTALLY AT THE FRONT OF THE UPPER RACK. Forks... -
Page 12: Starting A Wash Cycle
BAUMATIC BFD62W dishwasher user manual STARTING A WASH CYCLE STOP STOP STOP 1) MAKE SURE THAT THE PLUG OF THE APPLIANCE IS INSERTED INTO THE WALL SOCKET. 2) MAKE SURE THAT THE WATER SUPPLY IS TURNED ON TO FULL PRESSURE. - Page 13 This cycle uses a lower temperature (50°C) and has no drying phase. OVERFLOW PROTECTION YOUR BAUMATIC DISHWASHER HAS AN OVERFILL PROTECTION DEVICE WHICH AUTOMATICALLY SHUTS OFF THE INLET VALVE AND STARTS THE DRAIN PUMP IF THE WATER OVERFLOWS. IF THIS OCCURS THEN TURN OFF THE MAINS WATER SUPPLY BEFORE CALLING THE SERVICE DEPARTMENT.
-
Page 14: Unloading At The End Of A Cycle
BAUMATIC BFD62W dishwasher user manual FORGET TO ADD A DISH? A FORGOTTEN DISH CAN BE ADDED AT ANY TIME BEFORE THE DETERGENT DISPENSER OPENS. OPEN THE DOOR A LITTLE TO STOP THE WASHING. • WAIT ABOUT TEN SECONDS. AFTER THE SPRAY ARMS STOP WORKING, •... -
Page 15: Filtering System
BAUMATIC BFD62W dishwasher user manual FILTERING SYSTEM FOR YOUR CONVENIENCE, WE HAVE PLACED THE FILTERING SYSTEM WITHIN EASY REACH INSIDE THE TUB. THE FILTER REMOVES BITS OF FOOD TRAPPED IN THE FILTER FROM THE WASH WATER SO IT CAN BE RECIRCULATED DURING THE CYCLE. -
Page 16: Cleaning The Filters
BAUMATIC BFD62W dishwasher user manual CLEANING THE FILTERS • THE FILTER ASSEMBLY MUST BE KEPT CLEAN FOR BEST PERFORMANCE. You should remove the larger bits of food trapped in the filter after each wash cycle by rinsing the semicircular filter and cup under running water. -
Page 17: How To Keep Your Dishwasher In Shape
BAUMATIC BFD62W dishwasher user manual HOW TO KEEP YOUR DISHWASHER IN SHAPE , leave the door slightly ajar so that moisture and odours are not trapped FTER VERY inside. before cleaning or performing maintenance. Never run the risk of electric EMOVE THE shocks. -
Page 18: Troubleshooting
Drain Pump overflow. When it does, it shuts off • Overflow the circulation pump and turns on doesn’t stop! the drain pump. Call a Baumatic Ltd approved technician. • Sound from soft food shredding • Some audible sounds action and detergent cup opening. - Page 19 BAUMATIC BFD62W dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO • Use only special dishwasher Suds in the Tub! • Improper detergent detergent to avoid suds. • Always wipe up rinse agent spills • Spilled rinse agent immediately. Stained tub Interior! •...
- Page 20 BAUMATIC BFD62W dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO Cloudiness on • Combination of soft • Use less detergent if you have soft water and too much water and select a shorter cycle to glass! detergent clean the glassware.
-
Page 21: Dishwasher Leaks
BAUMATIC BFD62W dishwasher user manual PROBLEM POSSIBLE CAUSES WHAT TO DO Black or grey • Aluminium utensils • Use a mild abrasive cleaner to have rubbed against marks on dishes! eliminate those marks by hand. dishes Water standing in •... -
Page 22: Your Dishwasher
BAUMATIC BFD62W dishwasher user manual DISHWASHER CHARACTERISTICS The BAUMATIC BFD62 dishwasher model is based firmly on convenience. Apart from having the same general workings as other household dishwashers, it has several extra features. Performance of Adjustable upper Dishwasher - Your dishwasher... -
Page 23: How To Install
BAUMATIC BFD62W dishwasher user manual INSTALLATION INSTRUCTIONS NOTE: APPLIANCE SHOULD ONLY BE FITTED BY A TRAINED TECHNICIAN INSTALLING YOUR DISHWASHER Your dishwasher is with a freestanding feature, you only need to do following: 1 Levelling the Appliance(pls see the section “get your dishwasher... - Page 24 BAUMATIC BFD62W dishwasher user manual INSTALLING YOUR • REMEMBER THE DISHWASHER DIMENSIONS OF YOUR DISHWASHER! THESE INTO A CABINET ARE (measured in figure AREA in mm): • If dishwasher is to be installed at the corner of cabinet area, make sure you have enough space when the door is opened.
- Page 25 BAUMATIC BFD62W dishwasher user manual b) NEXT, CONNECT THE WATER INLET (SEE FIGURE BELOW): Connect the cold water supply hose to a threaded ¾ inch connector and make sure that it is fastened tightly in place. Attach tube C to the cold water supply A.
-
Page 26: Electrical Connection
BAUMATIC BFD62W dishwasher user manual d) NOW YOU ARE READY TO CONNECT THE POWER CORD. WARNING! ELECTRICITY CAN BE DANGEROUS. PLEASE READ THE FOLLOWING CAREFULLY: ELECTRICAL CONNECTION Electrical Requirements The dishwasher is designed for operation on an adequately wired individual 220-240V AC, 50Hz system. - Page 27 BAUMATIC BFD62W dishwasher user manual e) THEN, APPLY THE CONDENSATION STRIP. The Condensation Strip must be fitted to the underside of the worktop above your dishwasher to protect it against any moisture. Its purpose is to deflect steam rising from your appliance to protect your worktop’s underside.
-
Page 28: Final Checklist Before Starting
BAUMATIC BFD62W dishwasher user manual AT THE BOTTOM RIGHT DIAGRAM ON PAGE 24). IT’S IMPORTANT TO MAKE SURE THAT YOUR DISHWASHER IS LEVEL AGAIN, BECAUSE THE FLOOR SURFACE MAY BE DIFFERENT TO WHERE YOU HAD ADJUSTED IT BEFORE YOU MOVED... -
Page 29: Conditions Of Guarantee
In addition, your appliance is covered by a 5 year parts warranty. Baumatic Ltd will provide free of charge the parts required to repair the appliance, only if they are fitted by a Baumatic engineer, for any defect that arises due to faulty materials or workmanship within a period of 5 years from the original purchase date. -
Page 30: Contact Details
BAUMATIC BFD62W dishwasher user manual Baumatic Ltd Make-up for your kitchen Headquarters Baumatic Ltd. Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX, United Kingdom Sales Telephone +44 118 933 6900 Sales Fax +44 118 931 0035 Service Telephone +44 118 933 6911...
